*** U-Boot Boot Menu ***
1. Startup system (Default)
2. Upgrade firmware
3. Upgrade ATF BL2
4. Upgrade ATF FIP
5. Upgrade single image
6. Load image
0. U-Boot console
Press UP/DOWN to move, ENTER to select, ESC/CTRL+C to quit
Hit any key to stop autoboot: 0
WARNINGS: This Uboot is for mtk_uartboot debrick only! Do not use in normal device!
Web failsafe UI started
URL: http://192.168.1.1/
Press Ctrl+C to exit
GET /
GET /style.css
GET /index.js
GET /favicon.ico
GET /version
GET /getmtdlayout
GET /uboot.html
GET /style.css
GET /index.js
GET /version
POST /upload
Content-Length: 247050
GET /flashing.html
GET /style.css
GET /index.js
GET /version
GET /result
GET /undefined
Erasing from 0x0 to 0x3ffff, size 0x40000 ... OK
Writing from 0x460000a4 to 0x0, size 0x3c428 ... OK
Verifying from 0x0 to 0x3c427, size 0x3c428 ... OK
resetting ...
F0: 102B 0000
FA: 1040 0000
FA: 1040 0000 [0200]
F9: 0000 0000
V0: 0000 0000 [0001]
00: 0000 0000
BP: 2400 0041 [0000]
G0: 1190 0000
EC: 0000 0000 [1000]
T0: 0000 024B [010F]
Jump to BL
NOTICE: BL2: v2.7(release):
NOTICE: BL2: Built : 19:15:29, Jul 17 2025
NOTICE: WDT: disabled
NOTICE: EMI: Using DDR3 settings
NOTICE: EMI: Detected DRAM size: 256MB
NOTICE: EMI: complex R/W mem test passed
NOTICE: CPU: MT7981 (1300MHz)
NOTICE: SPI_NAND parses attributes from parameter page.
NOTICE: SPI_NAND Detected ID 0xef
NOTICE: Page size 2048, Block size 131072, size 134217728
NOTICE: Initializing NMBM ...
NOTICE: Signature found at block 1023 [0x07fe0000]
NOTICE: First info table with writecount 0 found in block 960
NOTICE: Second info table with writecount 0 found in block 963
NOTICE: NMBM has been successfully attached in read-only mode
NOTICE: BL2: Booting BL31
INFO: Total CPU count: 2
INFO: MCUSYS: L2C share 256K --> 0K
INFO: Disable NETSYS SRAM remapping
INFO: SPMC: Changed to SPMC mode
NOTICE: BL31: v2.10.0 (release):20240123-47-g93101f0b
NOTICE: BL31: Built : 19:00:38, Sep 15 2024
INFO: GICv3 without legacy support detected.
INFO: ARM GICv3 driver initialized in EL3
INFO: Maximum SPI INTID supported: 671
INFO: BL31: Initializing runtime services
INFO: Secondary bootloader is AArch64
INFO: BL31: Preparing for EL3 exit to normal world
INFO: Entry point address = 0x41e00000
INFO: SPSR = 0x3c9
U-Boot 2022.07 (Sep 15 2024 - 19:00:33 +0800)
CPU: MediaTek MT7981
Model: mt7981-h3c_magic-nx30-pro
DRAM: 256 MiB
Core: 27 devices, 15 uclasses, devicetree: embed
Loading Environment from UBI... spi-nand: spi_nand spi_nand@0: Winbond SPI NAND was found.
spi-nand: spi_nand spi_nand@0: 128 MiB, block size: 128 KiB, page size: 2048, OOB size: 64
Read 126976 bytes from volume ubootenv to 000000004f7c1c80
Read 126976 bytes from volume ubootenv2 to 000000004f7e0cc0
OK
In: serial@11002000
Out: serial@11002000
Err: serial@11002000
Net: eth0: ethernet@15100000
*** U-Boot Boot Menu ***
1. Startup system (Default)
2. Upgrade firmware
3. Upgrade ATF BL2
4. Upgrade ATF FIP
5. Upgrade single image
6. Load image
0. U-Boot console
Press UP/DOWN to move, ENTER to select, ESC/CTRL+C to quit
Reading from volume 'kernel' to 0x46000000, size 0x0 ... OK
## Loading kernel from FIT Image at 46000000 ...
Using 'config-1' configuration
Trying 'kernel-1' kernel subimage
Description: ARM64 OpenWrt Linux-5.4.225
Type: Kernel Image
Compression: lzma compressed
Data Start: 0x460000e8
Data Size: 3095447 Bytes = 3 MiB
Architecture: AArch64
OS: Linux
Load Address: 0x48080000
Entry Point: 0x48080000
Hash algo: crc32
Hash value: d9e6c7f7
Hash algo: sha1
Hash value: 51c0906b260371a116de83e5e9babae42dbd088a
Verifying Hash Integrity ... crc32+ sha1+ OK
## Loading fdt from FIT Image at 46000000 ...
Using 'config-1' configuration
Trying 'fdt-1' fdt subimage
Description: ARM64 OpenWrt mt7981-spim-nand-rfb device tree blob
Type: Flat Device Tree
Compression: uncompressed
Data Start: 0x462f3dc4
Data Size: 18588 Bytes = 18.2 KiB
Architecture: AArch64
Hash algo: crc32
Hash value: 138a2d34
Hash algo: sha1
Hash value: 0b9ec6846020e11021ee42501d7a29efd7fac7f7
Verifying Hash Integrity ... crc32+ sha1+ OK
Booting using the fdt blob at 0x462f3dc4
Uncompressing Kernel Image
Loading Device Tree to 000000004f7f3000, end 000000004f7fa89b ... OK
Starting kernel ...
[ 0.000000] Booting Linux on physical CPU 0x0000000000 [0x410fd034]
[ 0.000000] Linux version 5.4.225 (l24235@ubuntu203-UIS-R390-G2) (gcc version 8.4.0 (OpenWrt GCC 8.4.0 r16802-295c612a4a)) #0 SMP Thu Jul 17 10:57:17 2025
[ 0.000000] Machine model: MediaTek MT7981 RFB
[ 0.000000] earlycon: uart8250 at MMIO32 0x0000000011002000 (options '')
[ 0.000000] printk: bootconsole [uart8250] enabled
[ 0.000000] On node 0 totalpages: 64592
[ 0.000000] DMA32 zone: 1024 pages used for memmap
[ 0.000000] DMA32 zone: 0 pages reserved
[ 0.000000] DMA32 zone: 64592 pages, LIFO batch:15
[ 0.000000] psci: probing for conduit method from DT.
[ 0.000000] psci: PSCIv1.1 detected in firmware.
[ 0.000000] psci: Using standard PSCI v0.2 function IDs
[ 0.000000] psci: MIGRATE_INFO_TYPE not supported.
[ 0.000000] psci: SMC Calling Convention v1.0
[ 0.000000] percpu: Embedded 20 pages/cpu s43992 r8192 d29736 u81920
[ 0.000000] pcpu-alloc: s43992 r8192 d29736 u81920 alloc=20*4096
[ 0.000000] pcpu-alloc: [0] 0 [0] 1
[ 0.000000] Detected VIPT I-cache on CPU0
[ 0.000000] CPU features: detected: GIC system register CPU interface
[ 0.000000] CPU features: kernel page table isolation disabled by kernel configuration
[ 0.000000] Built 1 zonelists, mobility grouping on. Total pages: 63568
[ 0.000000] Kernel command line: console=ttyS0,115200n1 loglevel=8 earlycon=uart8250,mmio32,0x11002000
[ 0.000000] Dentry cache hash table entries: 32768 (order: 6, 262144 bytes, linear)
[ 0.000000] Inode-cache hash table entries: 16384 (order: 5, 131072 bytes, linear)
[ 0.000000] mem auto-init: stack:off, heap alloc:off, heap free:off
[ 0.000000] Memory: 231400K/258368K available (6398K kernel code, 414K rwdata, 1820K rodata, 448K init, 282K bss, 26968K reserved, 0K cma-reserved)
[ 0.000000] SLUB: HWalign=64, Order=0-3, MinObjects=0, CPUs=2, Nodes=1
[ 0.000000] rcu: Hierarchical RCU implementation.
[ 0.000000] rcu: CONFIG_RCU_FANOUT set to non-default value of 32.
[ 0.000000] rcu: RCU calculated value of scheduler-enlistment delay is 25 jiffies.
[ 0.000000] NR_IRQS: 64, nr_irqs: 64, preallocated irqs: 0
[ 0.000000] GICv3: GIC: Using split EOI/Deactivate mode
[ 0.000000] GICv3: 640 SPIs implemented
[ 0.000000] GICv3: 0 Extended SPIs implemented
[ 0.000000] GICv3: Distributor has no Range Selector support
[ 0.000000] GICv3: 16 PPIs implemented
[ 0.000000] GICv3: no VLPI support, no direct LPI support
[ 0.000000] GICv3: CPU0: found redistributor 0 region 0:0x000000000c080000
[ 0.000000] arch_timer: cp15 timer(s) running at 13.00MHz (phys).
[ 0.000000] clocksource: arch_sys_counter: mask: 0xffffffffffffff max_cycles: 0x2ff89eacb, max_idle_ns: 440795202429 ns
[ 0.000003] sched_clock: 56 bits at 13MHz, resolution 76ns, wraps every 4398046511101ns
[ 0.008195] Calibrating delay loop (skipped), value calculated using timer frequency.. 26.00 BogoMIPS (lpj=52000)
[ 0.018514] pid_max: default: 32768 minimum: 301
[ 0.023231] Mount-cache hash table entries: 512 (order: 0, 4096 bytes, linear)
[ 0.030492] Mountpoint-cache hash table entries: 512 (order: 0, 4096 bytes, linear)
[ 0.039079] ASID allocator initialised with 65536 entries
[ 0.044583] rcu: Hierarchical SRCU implementation.
[ 0.049702] smp: Bringing up secondary CPUs ...
[ 0.054590] Detected VIPT I-cache on CPU1
[ 0.054610] GICv3: CPU1: found redistributor 1 region 0:0x000000000c0a0000
[ 0.054630] CPU1: Booted secondary processor 0x0000000001 [0x410fd034]
[ 0.054693] smp: Brought up 1 node, 2 CPUs
[ 0.076307] SMP: Total of 2 processors activated.
[ 0.081033] CPU features: detected: 32-bit EL0 Support
[ 0.086195] CPU features: detected: CRC32 instructions
[ 0.091461] CPU: All CPU(s) started at EL2
[ 0.095583] alternatives: patching kernel code
[ 0.102483] clocksource: jiffies: mask: 0xffffffff max_cycles: 0xffffffff, max_idle_ns: 7645041785100000 ns
[ 0.112295] futex hash table entries: 512 (order: 3, 32768 bytes, linear)
[ 0.119192] pinctrl core: initialized pinctrl subsystem
[ 0.125112] NET: Registered protocol family 16
[ 0.129787] DMA: preallocated 256 KiB pool for atomic allocations
[ 0.150999] SCSI subsystem initialized
[ 0.154942] libata version 3.00 loaded.
[ 0.159914] rbus 18000000.wbsys: PCI host bridge to bus 0000:00
[ 0.165887] pci_bus 0000:00: root bus resource [mem 0x18000000-0x18ffffff]
[ 0.172802] pci_bus 0000:00: root bus resource [bus 00-ff]
[ 0.178316] pci_bus 0000:00: scanning bus
[ 0.182358] pci 0000:00:00.0: [14c3:7981] type 00 class 0x000280
[ 0.188404] pci 0000:00:00.0: reg 0x10: [mem 0x18000000-0x1800000f 64bit]
[ 0.195228] pci 0000:00:00.0: reg 0x18: [mem 0x00000000-0x0000000f]
[ 0.201528] pci 0000:00:00.0: reg 0x1c: [mem 0x00000000-0x0000000f]
[ 0.207827] pci 0000:00:00.0: reg 0x20: [mem 0x00000000-0x0000000f]
[ 0.214126] pci 0000:00:00.0: reg 0x24: [mem 0x00000000-0x0000000f]
[ 0.221307] pci_bus 0000:00: fixups for bus
[ 0.225518] pci_bus 0000:00: bus scan returning with max=00
[ 0.231861] clocksource: Switched to clocksource arch_sys_counter
[ 0.238643] thermal_sys: Registered thermal governor 'fair_share'
[ 0.238649] thermal_sys: Registered thermal governor 'bang_bang'
[ 0.244790] thermal_sys: Registered thermal governor 'step_wise'
[ 0.250828] thermal_sys: Registered thermal governor 'user_space'
[ 0.256864] thermal_sys: Registered thermal governor 'power_allocator'
[ 0.263221] NET: Registered protocol family 2
[ 0.274259] IP idents hash table entries: 4096 (order: 3, 32768 bytes, linear)
[ 0.281791] tcp_listen_portaddr_hash hash table entries: 256 (order: 0, 4096 bytes, linear)
[ 0.290204] TCP established hash table entries: 2048 (order: 2, 16384 bytes, linear)
[ 0.298003] TCP bind hash table entries: 2048 (order: 3, 32768 bytes, linear)
[ 0.305197] TCP: Hash tables configured (established 2048 bind 2048)
[ 0.311639] UDP hash table entries: 256 (order: 1, 8192 bytes, linear)
[ 0.318212] UDP-Lite hash table entries: 256 (order: 1, 8192 bytes, linear)
[ 0.325303] NET: Registered protocol family 1
[ 0.329707] PCI: CLS 0 bytes, default 64
[ 0.334450] workingset: timestamp_bits=46 max_order=16 bucket_order=0
[ 0.343744] squashfs: version 4.0 (2009/01/31) Phillip Lougher
[ 0.349628] jffs2: version 2.2 (NAND) (SUMMARY) (LZMA) (RTIME) (CMODE_PRIORITY) (c) 2001-2006 Red Hat, Inc.
[ 0.359931] yaffs: yaffs Installing.
[ 0.376079] phy phy-usb-phy@11e10000.1: type_sw - reg 0x218, index 0
[ 0.392844] Serial: 8250/16550 driver, 3 ports, IRQ sharing disabled
[ 0.399969] printk: console [ttyS0] disabled
[ 0.424371] 11002000.serial: ttyS0 at MMIO 0x11002000 (irq = 12, base_baud = 2500000) is a ST16650V2
[ 0.433585] printk: console [ttyS0] enabled
[ 0.433585] printk: console [ttyS0] enabled
[ 0.441943] printk: bootconsole [uart8250] disabled
[ 0.441943] printk: bootconsole [uart8250] disabled
[ 0.452259] cacheinfo: Unable to detect cache hierarchy for CPU 0
[ 0.460599] loop: module loaded
[ 0.463880] mediatek,mt2701-ice_debug ice_debug: get dbg_sel clock fail: -2
[ 0.470845] mediatek,mt2701-ice_debug: probe of ice_debug failed with error -2
[ 0.478972] mt7981-pinctrl 11d00000.pinctrl: pin_config_set op failed for pin 19
[ 0.486368] mtk-spi 1100a000.spi: Error applying setting, reverse things back
[ 0.494091] spi-nand spi0.0: Winbond SPI NAND was found.
[ 0.499432] spi-nand spi0.0: 128 MiB, block size: 128 KiB, page size: 2048, OOB size: 64
[ 0.509711] tun: Universal TUN/TAP device driver, 1.6
[ 0.515180] [mtk_hw_init] reset_lock:0, force:0
[ 0.519738] [mtk_hw_init] execute fe cold reset
[ 0.535381] mtk_soc_eth 15100000.ethernet: MDC is running on 2500000 Hz
[ 0.572235] MediaTek MT7981 PHY mdio-bus:00: TX-VCM SW cal result: 0x2
[ 0.579927] mtk_soc_eth 15100000.ethernet: generated random MAC address 4a:74:da:12:14:aa
[ 0.588404] mtk_soc_eth 15100000.ethernet eth0: mediatek frame engine at 0xffffffc011800000, irq 75
[ 0.597487] mtk_soc_eth 15100000.ethernet: generated random MAC address b2:45:12:ca:43:ab
[ 0.605926] mtk_soc_eth 15100000.ethernet eth1: mediatek frame engine at 0xffffffc011800000, irq 75
[ 0.614971] (unnamed net_device) (dummy): netif_napi_add() called with weight 256
[ 0.622713] i2c /dev entries driver
[ 0.627098] mtk-wdt 1001c000.watchdog: Watchdog enabled (timeout=31 sec, nowayout=0)
[ 0.635096] device-mapper: ioctl: 4.41.0-ioctl (2019-09-16) initialised: dm-devel@redhat.com
[ 0.645766] NET: Registered protocol family 10
[ 0.650914] Segment Routing with IPv6
[ 0.654649] NET: Registered protocol family 17
[ 0.659137] Bridge firewalling registered
[ 0.663385] 8021q: 802.1Q VLAN Support v1.8
[ 0.676612] nmbm nmbm_spim_nand: Signature found at block 1023 [0x07fe0000]
[ 0.684319] nmbm nmbm_spim_nand: First info table with writecount 0 found in block 960
[ 0.694404] nmbm nmbm_spim_nand: Second info table with writecount 0 found in block 963
[ 0.702426] nmbm nmbm_spim_nand: NMBM has been successfully attached
[ 0.709046] 9 fixed-partitions partitions found on MTD device nmbm_spim_nand
[ 0.716095] Creating 9 MTD partitions on "nmbm_spim_nand":
[ 0.721574] 0x000000000000-0x000000100000 : "BL2"
[ 0.726794] 0x000000100000-0x000000180000 : "u-boot-env"
[ 0.732599] 0x000000180000-0x000000380000 : "Factory"
[ 0.738125] 0x000000380000-0x000000580000 : "FIP"
[ 0.743302] 0x000000580000-0x000004580000 : "ubi"
[ 0.748599] 0x000004580000-0x000004b80000 : "pdt_data"
[ 0.754215] 0x000004b80000-0x000005180000 : "pdt_data_1"
[ 0.760056] 0x000005180000-0x000005280000 : "exp"
[ 0.765235] 0x000005280000-0x000007800000 : "plugin"
[ 0.992711] mt7530 mdio-bus:1f lan1 (uninitialized): PHY [dsa-0.0:00] driver [MediaTek MT7531 PHY]
[ 1.012393] mt7530 mdio-bus:1f lan2 (uninitialized): PHY [dsa-0.0:01] driver [MediaTek MT7531 PHY]
[ 1.032056] mt7530 mdio-bus:1f lan3 (uninitialized): PHY [dsa-0.0:02] driver [MediaTek MT7531 PHY]
[ 1.041618] mt7530 mdio-bus:1f: configuring for fixed/2500base-x link mode
[ 1.048770] DSA: tree 0 setup
[ 1.049019] mt7530 mdio-bus:1f: Link is Up - 2.5Gbps/Full - flow control rx/tx
[ 1.051727] mt7530-nl: genl_register_family_with_ops
[ 1.064374] UBI: auto-attach mtd5
[ 1.067686] ubi0: attaching mtd5
[ 1.252713] ubi0: scanning is finished
[ 1.261408] ubi0: attached mtd5 (name "ubi", size 64 MiB)
[ 1.266813] ubi0: PEB size: 131072 bytes (128 KiB), LEB size: 126976 bytes
[ 1.273682] ubi0: min./max. I/O unit sizes: 2048/2048, sub-page size 2048
[ 1.280460] ubi0: VID header offset: 2048 (aligned 2048), data offset: 4096
[ 1.287411] ubi0: good PEBs: 512, bad PEBs: 0, corrupted PEBs: 0
[ 1.293407] ubi0: user volume: 8, internal volumes: 1, max. volumes count: 128
[ 1.300618] ubi0: max/mean erase counter: 8/1, WL threshold: 4096, image sequence number: 1330213901
[ 1.309737] ubi0: available PEBs: 67, total reserved PEBs: 445, PEBs reserved for bad PEB handling: 19
[ 1.319035] ubi0: background thread "ubi_bgt0d" started, PID 654
[ 1.325594] block ubiblock0_1: created from ubi0:1(rootfs)
[ 1.331098] ubiblock: device ubiblock0_1 (rootfs) set to be root filesystem
[ 1.338055] hctosys: unable to open rtc device (rtc0)
[ 1.346236] VFS: Mounted root (squashfs filesystem) readonly on device 253:0.
[ 1.353607] Freeing unused kernel memory: 448K
[ 1.371894] Run /sbin/init as init process
[ 1.548782] init: Console is alive
[ 1.552288] init: - watchdog -
[ 1.827771] kmodloader: loading kernel modules from /etc/modules-boot.d/*
[ 1.853959] h3c_drv_procfs_init()
[ 1.858875] conninfra@(mtk_conninfra_drv_init:644) Before platform_driver_register
[ 1.866569] Get Index(0-TOP_MISC_BASE) phy_addr(0x11d10000) vir_addr=(0xffffffc010a1d000) size=(0x1000)
[ 1.875958] Get Index(1-TOPRGU_BASE) phy_addr(0x1001c000) vir_addr=(0xffffffc010a25000) size=(0x1000)
[ 1.885166] Get Index(2-GPIO_BASE) phy_addr(0x11d00000) vir_addr=(0xffffffc010a2d000) size=(0x1000)
[ 1.894200] Get Index(3-IOCFG_TR_BASE) phy_addr(0x11f00000) vir_addr=(0xffffffc010a35000) size=(0x1000)
[ 1.903581] Get Index(4-IOCFG_TL_BASE) phy_addr(0x11f10000) vir_addr=(0xffffffc010a3d000) size=(0x1000)
[ 1.912962] Get Index(5-INFRACFG_AO_BASE) phy_addr(0x10003000) vir_addr=(0xffffffc010a45000) size=(0x1000)
[ 1.922603] Get Index(6-CONN_INFRA_CFG_BASE) phy_addr(0x18001000) vir_addr=(0xffffffc010a4d000) size=(0x1000)
[ 1.932505] Get Index(7-CONN_INFRA_SYSRAM_BASE) phy_addr(0x18050000) vir_addr=(0xffffffc010a55000) size=(0x1000)
[ 1.942665] Get Index(8-CONN_INFRA_CLKGEN_ON_TOP_BASE) phy_addr(0x18009000) vir_addr=(0xffffffc010a57000) size=(0x1000)
[ 1.953434] Get Index(9-CONN_HOST_CSR_TOP_BASE) phy_addr(0x18060000) vir_addr=(0xffffffc010a59000) size=(0x1000)
[ 1.963596] Get Index(10-CONN_INFRA_BUS_CR_BASE) phy_addr(0x1800e000) vir_addr=(0xffffffc010a5b000) size=(0x1000)
[ 1.973844] Get Index(11-CONN_INFRA_RGU_BASE) phy_addr(0x18000000) vir_addr=(0xffffffc010a5d000) size=(0x1000)
[ 1.983832] Get Index(12-CONN_WT_SLP_CTL_REG_BASE) phy_addr(0x18005000) vir_addr=(0xffffffc010a65000) size=(0x1000)
[ 1.994254] Get Index(13-INST2_CONN_WT_SLP_CTL_REG_BASE) phy_addr(0x18085000) vir_addr=(0xffffffc010a67000) size=(0x1000)
[ 2.005195] Get Index(14-CONN_RF_SPI_MST_REG_BASE) phy_addr(0x18004000) vir_addr=(0xffffffc010a69000) size=(0x1000)
[ 2.015616] Get Index(15-INST2_CONN_RF_SPI_MST_REG_BASE) phy_addr(0x18084000) vir_addr=(0xffffffc010a6b000) size=(0x1000)
[ 2.026559] Get Index(16-CONN_SEMAPHORE_BASE) phy_addr(0x18070000) vir_addr=(0xffffffc010b00000) size=(0x10000)
[ 2.036634] Get Index(17-CONN_AFE_CTL_BASE) phy_addr(0x18003000) vir_addr=(0xffffffc010a6d000) size=(0x1000)
[ 2.046449] Get Index(18-CONN_AFE_CTL_2ND_BASE) phy_addr(0x18083000) vir_addr=(0xffffffc010ab6000) size=(0x1000)
[ 2.056611] Get Index(19-WF_TOP_SLPPROT_ON_BASE) phy_addr(0x184c0000) vir_addr=(0xffffffc010b20000) size=(0x10000)
[ 2.066951] Get Index(20-WF_TOP_CFG_BASE) phy_addr(0x184b0000) vir_addr=(0xffffffc010ab8000) size=(0x1000)
[ 2.076592] Get Index(21-WF_MCU_CONFIG_LS_BASE) phy_addr(0x184f0000) vir_addr=(0xffffffc010aba000) size=(0x1000)
[ 2.086753] Get Index(22-WF_MCU_BUS_CR_BASE) phy_addr(0x18400000) vir_addr=(0xffffffc010abc000) size=(0x1000)
[ 2.096654] Get Index(23-WF_MCUSYS_INFRA_BUS_FULL_U_DEBUG_CTRL_AO_BASE) phy_addr(0x18500000) vir_addr=(0xffffffc010abe000) size=(0x1000)
[ 2.108897] Get Index(24-WF_TOP_CFG_ON_BASE) phy_addr(0x184c0000) vir_addr=(0xffffffc010b40000) size=(0x10000)
[ 2.118884] conninfra@(consys_plt_hw_init:162) adie_cfg_type = 1, one_adie_dbdc = 1
[ 2.126534] [emi_mng_init] gConEmiPhyBase = [0x47c80000] size = [0x100000] fw size = [0x100000] ops=[(____ptrval____)]
[ 2.137306] conninfra@(mtk_conninfra_drv_init:650) After platform_driver_register
[ 2.145178] ConnInfra Dev: init (0)
[ 2.150131] conninfra@(_consys_polling_chipid_int:306) Read CONNSYS HW IP version successfully! (0x02090000)
[ 2.159961] conninfra@(connsys_d_die_cfg:365) D-die efuse: 0x00000000
[ 2.167419] conninfra@(_connsys_a_die_cfg_7976:919) adie_idx[0], A-die CHIP ID = 0x7976, HW Version = 0x8b00
[ 2.178239] conninfra@(consys_spi_write_nolock:501) addr=0x0a00, val=0xffffffff
[ 2.186542] conninfra@(consys_spi_write_nolock:501) addr=0x04ac, val=0x0000001c
[ 2.194846] conninfra@(consys_spi_write_nolock:501) addr=0x0144, val=0x00000002
[ 2.204157] conninfra@(consys_spi_write_nolock:501) addr=0x0148, val=0x00000000
[ 2.213468] conninfra@(consys_spi_write_nolock:501) addr=0x0148, val=0x43a60000
[ 2.226808] conninfra@(connsys_a_die_efuse_read_nolock:737) efuse = [0x00000001, 0x00c40000, 0x008600b8, 0x00000000]
[ 2.238321] conninfra@(consys_spi_write_nolock:501) addr=0x0144, val=0x00000002
[ 2.247631] conninfra@(consys_spi_write_nolock:501) addr=0x0148, val=0x23a6003a
[ 2.256943] conninfra@(consys_spi_write_nolock:501) addr=0x0148, val=0x63a7003a
[ 2.270283] conninfra@(connsys_a_die_efuse_read_nolock:737) efuse = [0x00000001, 0x00c40000, 0x008600b8, 0x00000000]
[ 2.281796] conninfra@(consys_spi_write_nolock:501) addr=0x0144, val=0x00000002
[ 2.291106] conninfra@(consys_spi_write_nolock:501) addr=0x0148, val=0x23a7003a
[ 2.300416] conninfra@(consys_spi_write_nolock:501) addr=0x0148, val=0x63ac003a
[ 2.313756] conninfra@(connsys_a_die_efuse_read_nolock:737) efuse = [0x00000001, 0x00c40000, 0x008600b8, 0x00000000]
[ 2.325268] conninfra@(consys_spi_write_nolock:501) addr=0x0038, val=0x4a563b00
[ 2.333572] conninfra@(consys_spi_write_nolock:501) addr=0x065c, val=0x1d59080f
[ 2.341875] conninfra@(consys_spi_write_nolock:501) addr=0x0664, val=0x34c00fe0
[ 2.350180] conninfra@(consys_spi_write_nolock:501) addr=0x0070, val=0x88888005
[ 2.359445] conninfra@(consys_spi_write_nolock:501) addr=0x0070, val=0x00000005
[ 2.367681] conninfra@(_consys_polling_chipid_int:306) Read CONNSYS HW IP version successfully! (0x02090000)
[ 2.377494] conninfra@(_consys_hw_conninfra_wakeup:470) conninfra_wakeup refcnt=[0]->[1] wakeup!!
[ 2.386358] conninfra@(_consys_hw_conninfra_sleep:490) conninfra_sleep refcnt=[1]->[0] sleep!!
[ 2.394957] conninfra@(opfunc_power_on_internal:241) [Conninfra Pwr On] BT=[0] FM=[0] GPS=[0] WF=[0] CONNINFRA=[1]
[ 2.408267] mediatek_soc_hnat 15100000.hnat: wan = eth1
[ 2.413503] mediatek_soc_hnat 15100000.hnat: lan = lan
[ 2.418635] mediatek_soc_hnat 15100000.hnat: lan2 = eth2
[ 2.423940] mediatek_soc_hnat 15100000.hnat: ppd = eth0
[ 2.429157] mediatek_soc_hnat 15100000.hnat: gmac num = 2
[ 2.434548] mediatek_soc_hnat 15100000.hnat: ppe num = 1
[ 2.440338] mediatek_soc_hnat 15100000.hnat: PPE0 entry number = 8192
[ 2.457121] mediatek_soc_hnat 15100000.hnat: PPE0 hwnat start
[ 2.462915] hnat roaming work enable
[ 2.469517] warp_module_init(): module init and register callback for warp
[ 2.476437] create warp_ctrl ok!!!
[ 2.479879] wed_get_slot_map(): assign slot_id:0 for entry: 0!
[ 2.485715] wed_get_slot_map(): assign slot_id:1 for entry: 1!
[ 2.492141] cpu_usage: module license 'unspecified' taints kernel.
[ 2.498323] Disabling lock debugging due to kernel taint
[ 2.551338] get size=1048576, 131072
[ 2.554933] iExpSize=0x100000, iExpEraseSize=0x20000
[ 2.559897] iExpWriteSize=0x800,NandFlash
[ 2.564270] *puiVal=0x55aa55aa
[ 2.567998] InitException, iExpSize=0x100000, iExpEraseSize=0x20000, iExpWriteSize=0x800, g_expWriteOffset=0x800
[ 2.578387] kmodloader: done loading kernel modules from /etc/modules-boot.d/*
[ 2.588368] init: - preinit -
[ 2.906900] mtk_soc_eth 15100000.ethernet eth0: configuring for fixed/2500base-x link mode
[ 2.915247] mtk_soc_eth 15100000.ethernet eth0: Link is Up - 2.5Gbps/Full - flow control rx/tx
[ 2.923344] mt7530 mdio-bus:1f lan1: configuring for phy/gmii link mode
[ 2.931014] 8021q: adding VLAN 0 to HW filter on device lan1
Before mount_root
Before do_h3c_mount_root
flashtype is nand
[ 2.992594] yaffs: dev is 32505862 name is "mtdblock6" rw
[ 2.998021] yaffs: passed flags ""
[ 3.001417] yaffs: yaffs: Attempting MTD mount of 31.6,"mtdblock6"
[ 3.009650] yaffs: yaffs_read_super: is_checkpointed 1
[ 3.024623] yaffs: dev is 32505863 name is "mtdblock7" rw
[ 3.030037] yaffs: passed flags ""
[ 3.033432] yaffs: yaffs: Attempting MTD mount of 31.7,"mtdblock7"
[ 3.041331] yaffs: yaffs_read_super: is_checkpointed 1
[ 3.699897] random: crng init done
no /mnt/config/etc/config/upper
After do_h3c_mou[ 3.736115] urandom-seed: Seed file not found (/etc/urandom.seed)
nt_root
After mount_root
/etc/preinit: line 1: blkid: not found
[ 3.877972] procd: - early -
[ 3.880916] procd: - watchdog -
[ 4.418171] procd: - watchdog -
[ 4.432124] procd: - ubus -
[ 4.487809] procd: - init -
Please press Enter to activate this console.
[ 4.730775] urngd: v1.0.2 started.
[ 4.846481] kmodloader: loading kernel modules from /etc/modules.d/*
[ 4.871608] l2tp_core: L2TP core driver, V2.0
[ 4.876896] l2tp_netlink: L2TP netlink interface
[ 4.882369] gre: GRE over IPv4 demultiplexor driver
[ 4.888064] ip_gre: GRE over IPv4 tunneling driver
[ 4.921892] Current mapfilter version v3.0.1.2
[ 6.035509] conninfra@(conninfra_pwr_on:120) [conninfra_pwr_on] drv=[3]
[ 6.043092] conninfra@(_consys_polling_chipid_int:306) Read CONNSYS HW IP version successfully! (0x02090000)
[ 6.060952] Adie Type: 0x7976
[ 6.060954] SKU Type: 3000
[ 6.064873] conninfra@(opfunc_power_on_internal:241) [Conninfra Pwr On] BT=[0] FM=[0] GPS=[0] WF=[1] CONNINFRA=[1]
[ 6.078970] WiFi@C12L1,get_dbg_setting_by_profile() 4575: debug level setting=INDEX0_debug_level not found!!
[ 6.088806] WiFi@C12L1,get_dbg_setting_by_profile() 4598: debug option setting=INDEX0_debug_option not found!!
[ 6.098854] mt_rbus 0000:00:00.0: runtime IRQ mapping not provided by arch
[ 6.113004] mt7981_init()-->
[ 6.115906] Use the default iPAiLNA bin image!
[ 6.120383] <--mt7981_init()
[ 6.123274] RtmpRaDevCtrlInit(): MCS_LUT not used becasue MacTb size(288) > 128!
[ 6.130784] WiFi@C12L1,match_index_by_chipname() 566: not find chip name INDEX1
[ 6.138104] WiFi@C12L1,match_index_by_chipname() 566: not find chip name INDEX2
[ 6.145422] WiFi@C12L1,match_index_by_chipname() 566: not find chip name INDEX3
[ 6.152739] WiFi@C12L1,match_index_by_chipname() 566: not find chip name INDEX4
[ 6.160055] WiFi@C12L1,match_index_by_chipname() 566: not find chip name INDEX5
[ 6.167370] WiFi@C12L1,match_index_by_chipname() 566: not find chip name INDEX6
[ 6.174686] WiFi@C12L1,match_index_by_chipname() 566: not find chip name INDEX7
[ 6.182011] WiFi@C12L1,match_index_by_chipname() 566: not find chip name INDEX8
[ 6.189327] WiFi@C12L1,match_index_by_chipname() 566: not find chip name INDEX9
[ 6.196626] WiFi@C12L2,match_index_by_chipname() 571: Not find slot id, back to old rule.
[ 6.204909] msta_ifname not found
[ 6.217589] -->mtfwd_init(ver:2.0)
[ 6.217633] <--
[ 6.221502] mtk_warp_proxy: module uses symbols from proprietary module mt_wifi, inheriting taint.
[ 6.233540] -->mtqos_init(), mtqos ver:1.0
[ 6.233591] <--
[ 6.275023] xt_time: kernel timezone is -0000
[ 6.283049] PPP generic driver version 2.4.2
[ 6.288200] PPP MPPE Compression module registered
[ 6.293932] NET: Registered protocol family 24
[ 6.299434] PPTP driver version 0.8.5
[ 6.304705] l2tp_ppp: PPPoL2TP kernel driver, V2.0
[ 6.311150] kmodloader: done loading kernel modules from /etc/modules.d/*
this is routermode
[ 7.236199] mtk_soc_eth 15100000.ethernet eth0: TX vlan offload cannot be enabled when dsa is attached.
[ 7.246441] mtk_soc_eth 15100000.ethernet eth0: TX vlan offload cannot be enabled when dsa is attached.
H3C_MESH_DEBUG: mediatek,mt7981-spim-snand-rfb
[ 9.065066] mtk_soc_eth 15100000.ethernet eth0: Link is Down
[ 9.083126] mtk_soc_eth 15100000.ethernet eth0: configuring for fixed/2500base-x link mode
[ 9.091463] mtk_soc_eth 15100000.ethernet eth0: Link is Up - 2.5Gbps/Full - flow control rx/tx
[ 9.097808] device eth0 entered promiscuous mode
[ 9.105287] mt7530 mdio-bus:1f lan1: configuring for phy/gmii link mode
[ 9.112586] 8021q: adding VLAN 0 to HW filter on device lan1
[ 9.120412] IPv6: ADDRCONF(NETDEV_CHANGE): eth0: link becomes ready
[ 9.130640] mt7530 mdio-bus:1f lan2: configuring for phy/gmii link mode
[ 9.137816] 8021q: adding VLAN 0 to HW filter on device lan2
[ 9.140158] mt7530 mdio-bus:1f lan2: Link is Up - 1Gbps/Full - flow control off
[ 9.150840] IPv6: ADDRCONF(NETDEV_CHANGE): lan2: link becomes ready
[ 9.157920] mt7530 mdio-bus:1f lan3: configuring for phy/gmii link mode
[ 9.165050] 8021q: adding VLAN 0 to HW filter on device lan3
---------iptv load data---------
[IF_GetPortNameByLport.1717]: Err: uci_lookup_section
**band2g******/etc/wireless/mediatek/mt7981.dbdc.b0.dat** start uci2dat
**band5g******/etc/wireless/mediatek/mt7981.dbdc.b1.dat** start uci2dat
[ 9.905144] mtk_soc_eth 15100000.ethernet eth0: Link is Down
[ 9.920001] mtk_soc_eth 15100000.ethernet eth0: configuring for fixed/2500base-x link mode
[ 9.928350] mtk_soc_eth 15100000.ethernet eth0: Link is Up - 2.5Gbps/Full - flow control rx/tx
[ 9.934933] mt7530 mdio-bus:1f lan1: configuring for phy/gmii link mode
[ 9.945878] 8021q: adding VLAN 0 to HW filter on device lan1
[ 9.958380] IPv6: ADDRCONF(NETDEV_CHANGE): eth0: link becomes ready
[ 9.966730] br-lan: port 1(lan1) entered blocking state
[ 9.972008] br-lan: port 1(lan1) entered disabled state
[ 9.987704] device lan1 entered promiscuous mode
[ 10.008053] mt7530 mdio-bus:1f lan2: Link is Down
[ 10.020684] mt7530 mdio-bus:1f lan2: configuring for phy/gmii link mode
[ 10.030364] 8021q: adding VLAN 0 to HW filter on device lan2
[ 10.041091] br-lan: port 2(lan2) entered blocking state
[ 10.046345] br-lan: port 2(lan2) entered disabled state
[ 10.052653] device lan2 entered promiscuous mode
[ 10.062444] br-lan: port 2(lan2) entered blocking state
[ 10.067716] br-lan: port 2(lan2) entered forwarding state
[ 10.074236] IPv6: ADDRCONF(NETDEV_CHANGE): br-lan: link becomes ready
[ 10.082131] br-lan: port 2(lan2) entered disabled state
[ 10.095817] mt7530 mdio-bus:1f lan3: configuring for phy/gmii link mode
[ 10.106028] 8021q: adding VLAN 0 to HW filter on device lan3
[ 10.114724] br-lan: port 3(lan3) entered blocking state
[ 10.119991] br-lan: port 3(lan3) entered disabled state
[ 10.129077] device lan3 entered promiscuous mode
[ 10.160169] mtk_soc_eth 15100000.ethernet eth1: PHY [mdio-bus:00] driver [MediaTek MT7981 PHY]
[ 10.168811] mtk_soc_eth 15100000.ethernet eth1: configuring for phy/gmii link mode
**band2g******/etc/wireless/mediatek/mt7981.dbdc.b0.dat** start uci2dat
**band5g******/etc/wireless/mediatek/mt7981.dbdc.b1.dat** start uci2dat
################---pre_mtkwifi----################
H3C_MESH_DEBUG: mediatek,mt7981-spim-snand-rfb
H3C_MESH_DEBUG: mediatek,mt7981-spim-snand-rfb
H3C_MESH_DEBUG: H3C EasyMesh Role:pre_wifi
H3C_MESH_DEBUG: controlelr reboot
H3C_MESH_DEBUG: *** mesh cmd end ***
disable_mtkwifi(band2g,,,)
disable_mtkwifi(band2g,,,) done
disable_mtkwifi(band5g,,,)
disable_mtkwifi(band5g,,,) done
**band2g******/etc/wireless/mediatek/mt7981.dbdc.b0.dat** start uci2dat
**band5g******/etc/wireless/mediatek/mt7981.dbdc.b1.dat** start uci2dat
[ 11.084722] 7981@C01L2,RTMP_COM_IoctlHandle() 1514: -> CMD_RTPRIV_IOCTL_VIRTUAL_INF_INIT
[ 11.095800] msta_ifname not found
[ 11.100056] client_get_axi_slot_id(): wrong BUS_TYPE
[ 11.105031] warp_cap_support(): chip_id=7981 is in WHNAT support list
[ 11.111478] warp_entry_acquire(): bus slot:0, hook to WARP, entry id=0, entry: 00000000585b5880
[ 11.120180] client_hif_specific_get(): hw->base_phy_addr 0x18000000!!
[ 11.126625] client_chip_specific_get(): 0x7981 chip id 0x7981!!
[ 11.132635] warp_entry_get_by_pdev(): return entry[0]
[ 11.153603] warp_msg_register():warp,pid,4063,id,0,wed_idx,0
[ 11.159286] warp_dev0 15010000.wed: Using 32bit DMA for streaming map
[ 11.165741] warp_dev0 15010000.wed: Using 32bit DMA for coherent map
[ 11.172137] wed_init(0): res_start = 0x15010000, size = 1000, irq=7,base_addr=0xffffffc015365000
[ 11.181423] wed_ring_init(): wed tx ring init result = 0
[ 11.186944] wed_ring_init(): wed rx ring init result = 0
[ 11.214778] create wed ok!!!
[ 11.217726] wdma_init(): wdma(0) base_addr=0xffffffc015509800, base_phy_addr=0x15104800
[ 11.226687] warp_woif_bus_init_hw(): bus:00000000e9242a99, txring: 20, pa: 0x0000000045ac8000, 0x0000000045ac8000, 24, 28, 3c
[ 11.238021] warp_woif_bus_init_hw(): bus:00000000e9242a99, rxring: 50, pa: 0x0000000045aca000, 0x0000000045aca000, 54, 58, 6c
[ 11.249383] get_region_info(): wed_idx = 0, base_addr = 0x00000000538bc827, size = 0x40000, res.start = 0x47d80000, shared:0
[ 11.260636] get_region_info(): wed_idx = 0, base_addr = 0x000000005677b3b4, size = 0x8000, res.start = 0x151e0000, shared:0
[ 11.271841] get_region_info(): wed_idx = 0, base_addr = 0x0000000004a9d0f8, size = 0x240000, res.start = 0x47dc0000, shared:1
[ 11.283197] get_region_info(): wed_idx = 0, base_addr = 0x00000000e7d9df34, size = 0x1000, res.start = 0x15194000, shared:0
[ 11.294391] warp_fwdl_mcu_mode(): mcu mode, need fwdl
[ 11.370646] ########## WO Firmware ##########
[ 11.375033] Chip ID: 0x0000
[ 11.377862] ECO version:0
[ 11.380502] Version: DEV_000000
[ 11.383639] Build date: 20240613172119
[ 11.387417] Total region:3
[ 11.390148] #################################
[ 11.394526] Parsing tailer region 0
[ 11.398038] Target address: 0x151e0000
[ 11.401885] Download size: 22112
[ 11.405233] Parsing tailer region 1
[ 11.408726] Target address: 0x47d80000
[ 11.412558] Download size: 86960
[ 11.415944] Parsing tailer region 2
[ 11.419421] Target address: 0x47dc0000
[ 11.423271] Download size: 2345040
[ 11.492333] warp_fwdl_ready_check_mcu_mode(): waiting for wocpu
[ 11.498280] warp_fwdl_ready_check_mcu_mode(): wocpu is ready
[ 11.520128] warp_woctrl_init_state(), wo_state: WO_STATE_ENABLE
[ 11.526082] wo_proc_init done 000000003b8130c7
[ 11.530641] wo_exep_proc_init done 000000003b8130c7
[ 11.535652] wo_exception_init(0): exp log= 0x00000000dcae8755, phy_addr= 0x00000000455e8000 size= 32768
[ 11.598721] 7981@C00L1,hc_init_ChCtrl() 2165: Clear ChCtrl Band[0] (caller:UserCfgInit+0x6c8/0x1928 [mt_wifi])
[ 11.609000] 7981@C00L1,hc_init_ChCtrl() 2165: Clear ChCtrl Band[1] (caller:UserCfgInit+0x6c8/0x1928 [mt_wifi])
[ 11.735834] 7981@C08L2,profile_wds_reg() 1329: WdsEnable is unknow(0;0;0;0;0;0)
[ 11.743178] 7981@C08L2,profile_wds_reg() 1329: WdsEnable is unknow(0;0;0;0;0;0)
[ 11.786610] 7981@C00L1,hc_init_ChCtrl() 2165: Clear ChCtrl Band[0] (caller:RTMPSetProfileParameters+0x8c/0x11008 [mt_wifi])
[ 11.798074] 7981@C00L1,hc_init_ChCtrl() 2165: Clear ChCtrl Band[1] (caller:RTMPSetProfileParameters+0x8c/0x11008 [mt_wifi])
[ 11.815415] 7981@C12L1,RTMPWirelessModeCfg() 610: Init: BSS0 PhyMode=78
[ 11.822041] 7981@C12L1,RTMPWirelessModeCfg() 610: Init: BSS1 PhyMode=78
[ 11.828673] 7981@C12L1,RTMPWirelessModeCfg() 610: Init: BSS2 PhyMode=78
[ 11.835315] 7981@C12L1,RTMPWirelessModeCfg() 610: Init: BSS3 PhyMode=14
[ 11.841952] 7981@C12L1,RTMPWirelessModeCfg() 610: Init: BSS4 PhyMode=78
[ 11.848591] 7981@C12L1,RTMPWirelessModeCfg() 610: Init: BSS5 PhyMode=78
[ 11.855229] 7981@C12L1,RTMPWirelessModeCfg() 610: Init: BSS6 PhyMode=177
[ 11.861959] 7981@C12L1,RTMPWirelessModeCfg() 610: Init: BSS7 PhyMode=177
[ 11.868688] 7981@C12L1,RTMPWirelessModeCfg() 610: Init: BSS8 PhyMode=177
[ 11.875414] 7981@C12L1,RTMPWirelessModeCfg() 610: Init: BSS9 PhyMode=49
[ 11.882036] 7981@C12L1,RTMPWirelessModeCfg() 610: Init: BSS10 PhyMode=177
[ 11.888833] 7981@C12L1,RTMPWirelessModeCfg() 610: Init: BSS11 PhyMode=177
[ 11.896030] 7981@C23L3,auto_ch_select_set_cfg() 3470: BandIdx0, AutoChannelAtBootup=1, AutoChannelAlg = 3
[ 11.905603] 7981@C23L3,auto_ch_select_set_cfg() 3470: BandIdx1, AutoChannelAtBootup=1, AutoChannelAlg = 3
[ 11.994768] 7981@C15L1,Set_PMFMFPC_Proc() 1722: [PMF] :: apidx=0, Desired MFPC=0
[ 12.002176] WiFi@C15L1,Set_PMFMFPC_Proc() 1722: [PMF] :: apidx=1, Desired MFPC=0
[ 12.009587] WiFi@C15L1,Set_PMFMFPC_Proc() 1722: [PMF] :: apidx=2, Desired MFPC=0
[ 12.016998] WiFi@C15L1,Set_PMFMFPC_Proc() 1722: [PMF] :: apidx=3, Desired MFPC=0
[ 12.024403] WiFi@C15L1,Set_PMFMFPC_Proc() 1722: [PMF] :: apidx=4, Desired MFPC=0
[ 12.031859] WiFi@C15L1,Set_PMFMFPC_Proc() 1722: [PMF] :: apidx=5, Desired MFPC=0
[ 12.039262] WiFi@C15L1,Set_PMFMFPC_Proc() 1722: [PMF] :: apidx=6, Desired MFPC=0
[ 12.046676] WiFi@C15L1,Set_PMFMFPC_Proc() 1722: [PMF] :: apidx=7, Desired MFPC=0
[ 12.054083] WiFi@C15L1,Set_PMFMFPC_Proc() 1722: [PMF] :: apidx=8, Desired MFPC=0
[ 12.061487] WiFi@C15L1,Set_PMFMFPC_Proc() 1722: [PMF] :: apidx=9, Desired MFPC=0
[ 12.068898] WiFi@C15L1,Set_PMFMFPC_Proc() 1722: [PMF] :: apidx=10, Desired MFPC=0
[ 12.076408] WiFi@C15L1,Set_PMFMFPC_Proc() 1722: [PMF] :: apidx=11, Desired MFPC=0
[ 12.086031] WiFi@C12L1,RTMPSetProfileParameters() 8658: ra0, QoSMgmtCapa=0
[ 12.092967] WiFi@C12L1,RTMPSetProfileParameters() 8658: (null), QoSMgmtCapa=0
[ 12.100119] WiFi@C12L1,RTMPSetProfileParameters() 8658: (null), QoSMgmtCapa=0
[ 12.107271] WiFi@C12L1,RTMPSetProfileParameters() 8658: (null), QoSMgmtCapa=0
[ 12.114426] WiFi@C12L1,RTMPSetProfileParameters() 8658: (null), QoSMgmtCapa=0
[ 12.121582] WiFi@C12L1,RTMPSetProfileParameters() 8658: (null), QoSMgmtCapa=0
[ 12.128746] WiFi@C12L1,RTMPSetProfileParameters() 8658: (null), QoSMgmtCapa=0
[ 12.135902] WiFi@C12L1,RTMPSetProfileParameters() 8658: (null), QoSMgmtCapa=0
[ 12.143054] WiFi@C12L1,RTMPSetProfileParameters() 8658: (null), QoSMgmtCapa=0
[ 12.150211] WiFi@C12L1,RTMPSetProfileParameters() 8658: (null), QoSMgmtCapa=0
[ 12.157372] WiFi@C12L1,RTMPSetProfileParameters() 8658: (null), QoSMgmtCapa=0
[ 12.164531] WiFi@C12L1,RTMPSetProfileParameters() 8658: (null), QoSMgmtCapa=0
[ 12.181611] WiFi@C12L1,rtmp_read_ap_client_from_file() 1638: APCLI[0] ApCliMuMimoDlEnable = 0
[ 12.190166] WiFi@C12L1,rtmp_read_ap_client_from_file() 1638: APCLI[1] ApCliMuMimoDlEnable = 0
[ 12.198943] WiFi@C12L1,rtmp_read_ap_client_from_file() 1657: APCLI[0] ApCliMuMimoUlEnable = 0
[ 12.207498] WiFi@C12L1,rtmp_read_ap_client_from_file() 1657: APCLI[1] ApCliMuMimoUlEnable = 0
[ 12.218492] WiFi@C03L1,AndesSendCmdMsg() 754: Could not send in band command due to diablefRTMP_ADAPTER_MCU_SEND_IN_BAND_CMD
[ 12.229739] WiFi@C03L2,AndesSendCmdMsg() 765: Command type = ed, Extension command type = 48
[ 12.238236] WiFi@C03L1,AndesSendCmdMsg() 754: Could not send in band command due to diablefRTMP_ADAPTER_MCU_SEND_IN_BAND_CMD
[ 12.249491] WiFi@C03L2,AndesSendCmdMsg() 765: Command type = ed, Extension command type = 48
[ 12.354198] wdma_dma_ctrl(): WDMA_GLO_CFG=50404e70, txrx = 0
[ 12.365527] wdma_dma_ctrl(): WDMA_GLO_CFG=40404e70, txrx = 0
[ 12.381587] warp_tx_ring_init_hw(): configure ring 0 setting
[ 12.387313] warp_tx_ring_init_hw(): wed:000000002c8324e2 wifi:00000000c5701fe9: 24420=4d098000,24424=2048,24428=0
[ 12.397601] warp_tx_ring_init_hw(): configure ring 1 setting
[ 12.403284] warp_tx_ring_init_hw(): wed:000000002c8324e2 wifi:00000000c5701fe9: 24430=4d1a8000,24434=2048,24438=0
[ 12.413680] set_rrocfg,0
[ 12.440655] wdma_dma_ctrl(): WDMA_GLO_CFG=40404e74, txrx = 3
[ 12.446374] using E1 ROM patch
[ 12.449481] using E1 RAM
[ 12.452039] current sync CR = 0x1
[ 12.455350] Built date: 20240613171533a
[ 12.459310] Platform: ALPS
[ 12.462141] HW/SW version: 0x8a108a10
[ 12.465910] Patch version: 0xffffffff
[ 12.491352] current sync CR = 0x1
[ 12.494733] Chip ID: 0x14
[ 12.497467] Eco version: 0x00
[ 12.500534] Region number: 0x0b
[ 12.503755] Format version: 0x02
[ 12.507082] Format flag: 0x01
[ 12.510146] Ram version: ____000000
[ 12.513761] Built date: 20240613171549
[ 12.517618] Common crc: 0x421943b9
[ 12.521107] Release info: header tag = 0, total length = 80
[ 12.526780] tag 1, padding length = 1, tag length = 75
[ 12.532014] payload: t-neptune-main-2111-7981-imp-MT7981_E1_ASIC_ROM_RAM_REBB_IMP-20240613171459
[ 12.570528] Chip ID: 0x00
[ 12.573294] Eco version: 0x00
[ 12.576372] Region number: 0x03
[ 12.579595] Format version: 0x02
[ 12.582917] Format flag: 0x01
[ 12.585972] Ram version: DEV_000000
[ 12.589553] Built date: 20240613172044
[ 12.593395] Common crc: 0xd9caeeb6
[ 12.596883] Release info: header tag = 0, total length = 0
[ 12.732004] current sync CR = 0x7
[ 12.735394] efuse_probe: efuse = deaddead
[ 12.748861] WiFi@C02L1,is_cal_free_ic() 831: [a-die version:1]
[ 13.410093] mt7530 mdio-bus:1f lan2: Link is Up - 1Gbps/Full - flow control off
[ 15.199908] WiFi@C17L1,RTMPReadTxPwrPerRate() 450: (450): Don't Support this now!
[ 15.207597] WiFi@C01L1,AntCfgInit() 3127: Not support for HIF_MT yet!
[main.1569]: flacct
[parse_cmd.1541]: QosAcctEn = 0
[FLACCT_Init_Port_Info.1[ 15.245307] ch_switch_monitor_state_machine_init:: enter
490]: LAN1, LAN1[ 15.250759] ch_switch_monitor_cfg_reset:: enter
, eth0, switch0,[ 15.256688] ch_switch_monitor_cfg_reset:: enter
0 iRet=0
[FLACCT_Init_Port_Info.1490]: LAN2, LAN2, eth0, switch0, 1 iRet=0
[FLACCT_Init_Port_Info.1490]: LAN3, LAN3, eth0, switch0, 2 iRet=0
[FLACCT_Init_Port_Info.1490]: WAN1, WAN, eth1, switch1, 0 iRet=0
[main.1629]: flacct I[ 15.283323] WiFi@C17L1,tx_pwr_comp_init() 641: NotSupportYet!
nit ok.
[mai[ 15.289250] WiFi@C12L1,SCS_init() 880: INIT SCSEnable [0]= 1
n.1636]: create [ 15.296276] WiFi@C12L1,SCS_init() 887: INIT SCSEnable [1]= 0
flacct ubus proc ok.
[main.1569]: flacct
[parse_cmd.1541]: QosAcctEn = 0
[FLACCT_Init_Port_[ 15.311881] WiFi@C03L1,MtCmdSetMacTxRx() 10296: (ret = 0)
Info.1490]: LAN1, LAN1, eth0, switch0, 0 iRet=0
[FLACCT_Init_Port_Info.1490]: LAN2, LAN2, eth0, switch0, 1 iRet=0
[FLACCT_[ 15.327882] WiFi@C03L1,MtCmdSetMacTxRx() 10296: (ret = 0)
Init_Port_Info.1[ 15.334913] WiFi@C14L1,IPMacTable_init() 348: IPMacTable already inited!
490]: LAN3, LAN3, eth0, switch0, 2 iRet=0
[FLACCT_Init_Port_Info.1490]: WAN1, WAN, eth1, switch1, 0 iRet=0
[main.1629]: flacct Init ok.
[main.1636]: create flacct ubus proc ok.
[ 15.362998] wdma_dma_ctrl(): WDMA_GLO_CFG=50804e75, txrx = 3
[ 15.381950] WiFi@C03L1,MtCmdSetMacTxRx() 10296: (ret = 0)
[ 15.388545] WiFi@C03L1,MtCmdSetMacTxRx() 10296: (ret = 0)
[ 15.394114] WiFi@C00L1,set_ack_timeout_mode_byband() 13447: CTS/ACK Timeout Range should between [0xFFFF:0]!!
[ 15.404056] WiFi@C00L1,set_datcfg_ack_cts_timeout() 13535: DAT config band(0) cck_timeout Fail!
[ 15.412757] WiFi@C00L1,set_ack_timeout_mode_byband() 13447: CTS/ACK Timeout Range should between [0xFFFF:0]!!
[ 15.422703] WiFi@C00L1,set_datcfg_ack_cts_timeout() 13546: DAT config band(0) ofdm_timeout Fail!
[ 15.431512] WiFi@C00L1,set_ack_timeout_mode_byband() 13447: CTS/ACK Timeout Range should between [0xFFFF:0]!!
[ 15.441428] WiFi@C00L1,set_datcfg_ack_cts_timeout() 13557: DAT config band(0) ofdma_timeout Fail!
[ 15.450297] WiFi@C00L1,set_ack_timeout_mode_byband() 13447: CTS/ACK Timeout Range should between [0xFFFF:0]!!
[ 15.460201] WiFi@C00L1,set_datcfg_ack_cts_timeout() 13535: DAT config band(1) cck_timeout Fail!
[ 15.468889] WiFi@C00L1,set_ack_timeout_mode_byband() 13447: CTS/ACK Timeout Range should between [0xFFFF:0]!!
[ 15.478791] WiFi@C00L1,set_datcfg_ack_cts_timeout() 13546: DAT config band(1) ofdm_timeout Fail!
[ 15.487588] WiFi@C00L1,set_ack_timeout_mode_byband() 13447: CTS/ACK Timeout Range should between [0xFFFF:0]!!
[ 15.497519] WiFi@C00L1,set_datcfg_ack_cts_timeout() 13557: DAT config band(1) ofdma_timeout Fail!
[ 15.572941] WiFi@C00L2,dump_ht_cap() 29: Caller: dump_ht_cap+0x10/0x20 [mt_wifi]
[ 15.671166] WiFi@C00L2,dump_ht_cap() 29: Caller: dump_ht_cap+0x10/0x20 [mt_wifi]
[ 16.102257] :(op = 0)
[ 16.104618] 7981@C00L2,red_tail_drop_init() 83: red_tail_drop_init: available token:8192, whnat_en:1
[ 16.113816] 7981@C00L1,MtCmdCr4RedSet() 914: MtCmdCr4RedSet: (ret = 0)
[ 16.120364] 7981@C00L1,SendRedCmd() 1049: SendRedCmd:(ret = 1)
[ 16.126439] 7981@C01L2,RTMP_COM_IoctlHandle() 1491: -> CMD_RTPRIV_IOCTL_VIRTUAL_INF_UP
[ 16.134475] WiFi@C01L3,wifi_sys_open() 856: wdev idx = 0
[ 16.140117] 7981@C18L3,BuildChannelList() 497:
[ 16.144683] 7981@C00L3,BuildChannelList() 527: BandIdx = 0, PhyMode = 78, ChListNum = 13:
[ 16.152886] 7981@C14L1,vht80_channel_group() 1943: invalid ch_band 0
[ 16.159264] 7981@C14L1,vht160_channel_group() 2014: invalid ch_band 0
[ 16.165717] 7981@C14L1,vht80_channel_group() 1943: invalid ch_band 0
[ 16.172084] 7981@C14L1,vht160_channel_group() 2014: invalid ch_band 0
[ 16.178541] 7981@C14L1,vht80_channel_group() 1943: invalid ch_band 0
[ 16.184912] 7981@C14L1,vht160_channel_group() 2014: invalid ch_band 0
[ 16.191371] 7981@C14L1,vht80_channel_group() 1943: invalid ch_band 0
[ 16.197743] 7981@C14L1,vht160_channel_group() 2014: invalid ch_band 0
[ 16.204191] 7981@C14L1,vht80_channel_group() 1943: invalid ch_band 0
[ 16.210544] 7981@C14L1,vht160_channel_group() 2014: invalid ch_band 0
[ 16.216985] 7981@C14L1,vht80_channel_group() 1943: invalid ch_band 0
[ 16.223341] 7981@C14L1,vht160_channel_group() 2014: invalid ch_band 0
[ 16.229828] 7981@C14L1,vht80_channel_group() 1943: invalid ch_band 0
[ 16.236199] 7981@C14L1,vht160_channel_group() 2014: invalid ch_band 0
[ 16.242669] 7981@C14L1,vht80_channel_group() 1943: invalid ch_band 0
[ 16.249050] 7981@C14L1,vht160_channel_group() 2014: invalid ch_band 0
[ 16.255505] 7981@C14L1,vht80_channel_group() 1943: invalid ch_band 0
[ 16.261874] 7981@C14L1,vht160_channel_group() 2014: invalid ch_band 0
[ 16.268343] 7981@C14L1,vht80_channel_group() 1943: invalid ch_band 0
[ 16.274729] 7981@C14L1,vht160_channel_group() 2014: invalid ch_band 0
[ 16.281194] 7981@C14L1,vht80_channel_group() 1943: invalid ch_band 0
[ 16.287570] 7981@C14L1,vht160_channel_group() 2014: invalid ch_band 0
[ 16.294042] 7981@C14L1,vht80_channel_group() 1943: invalid ch_band 0
[ 16.300401] 7981@C14L1,vht160_channel_group() 2014: invalid ch_band 0
[ 16.306863] 7981@C14L1,vht80_channel_group() 1943: invalid ch_band 0
[ 16.313245] 7981@C14L1,vht160_channel_group() 2014: invalid ch_band 0
[ 16.319691] 7981@C23L1,DfsBuildChannelList() 3873: [RDM]: wdev is not 5G.
[ 16.326548] 7981@C23L3,RadarStateCheck() 256: Bw160 Zero Wait State: 0, phy_bw=0, band_bw[band_idx]=0
[ 16.335790] 7981@C23L3,DfsRadarChannelCheck() 3254: [DfsRadarChannelCheck]: wdev is not 5G
[ 16.344078] 7981@C23L3,operate_loader_phy() 360: oper_cfg: prim_ch(0), ht_bw(0), extcha(3), vht_bw(0), cen_ch_2(0), PhyMode=78!
[ 16.355569] phy_freq_adjust : no prim_ch value for adjust!
[ 16.361180] 7981@C23L1,operate_loader_phy() 364: phy_freq_adjust failed!WiFi@C00L2,dump_ht_cap() 29: Caller: wlan_operate_init+0xa4/0x148 [mt_wifi]
[ 16.374851] wdev_attr_update(): wdevId0 = 70:2a:d7:be:c2:20
[ 16.380513] WiFi@C12L1,wifi_sys_open() 907: wifi_sys_open():band0 group_idx[0]=0, bw_grp=16 omac=0
[ 16.389515] 7981@C08L3,hw_ctrl_flow_v2_open() 13: wdev_idx=0
[ 16.393695] sh (5337): drop_caches: 3
[ 16.399717] 7981@C23L1,HcGetBandByChannel() 1234: No hdev parking on channel:0, just return a default band_idx 0!
[ 16.410058] 7981@C02L2,AsicRadioOnOffCtrl() 2355: DbdcIdx=0 RadioOn
[ 16.416998] 7981@C00L2,ApAutoChannelAtBootUp() 335: ----------------->
[ 16.424503] 7981@C03L1,MtCmdSetMacTxRx() 10296: (ret = 0)
[ 16.430065] 7981@C03L1,MtCmdSetMacTxRx() 10296: (ret = 0)
[ 16.435863] 7981@C08L1,UpdateBeaconHandler() 1908: wdev(0) bss not ready (state:0, caller:MTAPAutoSelectChannel+0x108/0x418 [mt_wifi])!!
[ 16.448147] 7981@C08L1,AsicSwitchChannel() 334: AsicSwitchChannel::bandIdx:0 ch_band:0 htbw:0 vht_bw:0 bw:0 extcha:0
[ 16.458671] 7981@C08L1,AsicSwitchChannel() 339: AsicSwitchChannel::primch:1 cench1:1 cench2:0 rxstream:0 ap_bw:0 apCenCh:0 Scan:1
[ 16.470435] 7981@C00L1,mt7981_apply_dpd_flatness_data() 624: eeprom 0x19a bit 0 is 0, do runtime cal
[ 16.479652] 7981@C03L3,MtCmdChannelSwitch() 2541: ctrl_chl=1, ctrl_ch2=0, cent_ch=1 DBDCIdx=0, ChBand=0, BW=0, TXStream=2, RXStream=2, scan(1)
[ 16.548051] 7981@C03L3,MtCmdSetTxRxPath() 2803: ctrl_chl=1, ctrl_ch2=0, cent_ch=1, RxPath=3, BandIdx=0, ChBand=0, BW=0,TXStream=2, RXStream=3, scan(1)
[ 16.907897] 7981@C08L1,AsicSwitchChannel() 334: AsicSwitchChannel::bandIdx:0 ch_band:0 htbw:0 vht_bw:0 bw:0 extcha:0
[ 16.918463] 7981@C08L1,AsicSwitchChannel() 339: AsicSwitchChannel::primch:2 cench1:2 cench2:0 rxstream:0 ap_bw:0 apCenCh:0 Scan:1
[ 16.930187] 7981@C00L1,mt7981_apply_dpd_flatness_data() 624: eeprom 0x19a bit 0 is 0, do runtime cal
[ 16.939341] 7981@C03L3,MtCmdChannelSwitch() 2541: ctrl_chl=2, ctrl_ch2=0, cent_ch=2 DBDCIdx=0, ChBand=0, BW=0, TXStream=2, RXStream=2, scan(1)
[ 16.995900] 7981@C03L3,MtCmdSetTxRxPath() 2803: ctrl_chl=2, ctrl_ch2=0, cent_ch=2, RxPath=3, BandIdx=0, ChBand=0, BW=0,TXStream=2, RXStream=3, scan(1)
[ 17.368217] 7981@C08L1,AsicSwitchChannel() 334: AsicSwitchChannel::bandIdx:0 ch_band:0 htbw:0 vht_bw:0 bw:0 extcha:0
[ 17.378770] 7981@C08L1,AsicSwitchChannel() 339: AsicSwitchChannel::primch:3 cench1:3 cench2:0 rxstream:0 ap_bw:0 apCenCh:0 Scan:1
[ 17.390529] 7981@C00L1,mt7981_apply_dpd_flatness_data() 624: eeprom 0x19a bit 0 is 0, do runtime cal
[ 17.399695] 7981@C03L3,MtCmdChannelSwitch() 2541: ctrl_chl=3, ctrl_ch2=0, cent_ch=3 DBDCIdx=0, ChBand=0, BW=0, TXStream=2, RXStream=2, scan(1)
[ 17.451890] 7981@C03L3,MtCmdSetTxRxPath() 2803: ctrl_chl=3, ctrl_ch2=0, cent_ch=3, RxPath=3, BandIdx=0, ChBand=0, BW=0,TXStream=2, RXStream=3, scan(1)
[ 17.808239] 7981@C08L1,AsicSwitchChannel() 334: AsicSwitchChannel::bandIdx:0 ch_band:0 htbw:0 vht_bw:0 bw:0 extcha:0
[ 17.818798] 7981@C08L1,AsicSwitchChannel() 339: AsicSwitchChannel::primch:4 cench1:4 cench2:0 rxstream:0 ap_bw:0 apCenCh:0 Scan:1
[ 17.830549] 7981@C00L1,mt7981_apply_dpd_flatness_data() 624: eeprom 0x19a bit 0 is 0, do runtime cal
[ 17.839715] 7981@C03L3,MtCmdChannelSwitch() 2541: ctrl_chl=4, ctrl_ch2=0, cent_ch=4 DBDCIdx=0, ChBand=0, BW=0, TXStream=2, RXStream=2, scan(1)
[ 17.890105] 7981@C03L3,MtCmdSetTxRxPath() 2803: ctrl_chl=4, ctrl_ch2=0, cent_ch=4, RxPath=3, BandIdx=0, ChBand=0, BW=0,TXStream=2, RXStream=3, scan(1)
[ 18.244212] 7981@C08L1,AsicSwitchChannel() 334: AsicSwitchChannel::bandIdx:0 ch_band:0 htbw:0 vht_bw:0 bw:0 extcha:0
[ 18.254772] 7981@C08L1,AsicSwitchChannel() 339: AsicSwitchChannel::primch:5 cench1:5 cench2:0 rxstream:0 ap_bw:0 apCenCh:0 Scan:1
[ 18.266565] 7981@C00L1,mt7981_apply_dpd_flatness_data() 624: eeprom 0x19a bit 0 is 0, do runtime cal
[ 18.275731] 7981@C03L3,MtCmdChannelSwitch() 2541: ctrl_chl=5, ctrl_ch2=0, cent_ch=5 DBDCIdx=0, ChBand=0, BW=0, TXStream=2, RXStream=2, scan(1)
[ 18.323913] 7981@C03L3,MtCmdSetTxRxPath() 2803: ctrl_chl=5, ctrl_ch2=0, cent_ch=5, RxPath=3, BandIdx=0, ChBand=0, BW=0,TXStream=2, RXStream=3, scan(1)
[ 18.684219] 7981@C08L1,AsicSwitchChannel() 334: AsicSwitchChannel::bandIdx:0 ch_band:0 htbw:0 vht_bw:0 bw:0 extcha:0
[ 18.694770] 7981@C08L1,AsicSwitchChannel() 339: AsicSwitchChannel::primch:6 cench1:6 cench2:0 rxstream:0 ap_bw:0 apCenCh:0 Scan:1
[ 18.706539] 7981@C00L1,mt7981_apply_dpd_flatness_data() 624: eeprom 0x19a bit 0 is 0, do runtime cal
[ 18.715697] 7981@C03L3,MtCmdChannelSwitch() 2541: ctrl_chl=6, ctrl_ch2=0, cent_ch=6 DBDCIdx=0, ChBand=0, BW=0, TXStream=2, RXStream=2, scan(1)
[ 18.780213] 7981@C03L3,MtCmdSetTxRxPath() 2803: ctrl_chl=6, ctrl_ch2=0, cent_ch=6, RxPath=3, BandIdx=0, ChBand=0, BW=0,TXStream=2, RXStream=3, scan(1)
[ 19.136686] 7981@C08L1,AsicSwitchChannel() 334: AsicSwitchChannel::bandIdx:0 ch_band:0 htbw:0 vht_bw:0 bw:0 extcha:0
[ 19.147274] 7981@C08L1,AsicSwitchChannel() 339: AsicSwitchChannel::primch:7 cench1:7 cench2:0 rxstream:0 ap_bw:0 apCenCh:0 Scan:1
[ 19.159134] 7981@C00L1,mt7981_apply_dpd_flatness_data() 624: eeprom 0x19a bit 0 is 0, do runtime cal
[ 19.168282] 7981@C03L3,MtCmdChannelSwitch() 2541: ctrl_chl=7, ctrl_ch2=0, cent_ch=7 DBDCIdx=0, ChBand=0, BW=0, TXStream=2, RXStream=2, scan(1)
[ 19.210631] 7981@C03L3,MtCmdSetTxRxPath() 2803: ctrl_chl=7, ctrl_ch2=0, cent_ch=7, RxPath=3, BandIdx=0, ChBand=0, BW=0,TXStream=2, RXStream=3, scan(1)
[ 19.568482] 7981@C08L1,AsicSwitchChannel() 334: AsicSwitchChannel::bandIdx:0 ch_band:0 htbw:0 vht_bw:0 bw:0 extcha:0
[ 19.579128] 7981@C08L1,AsicSwitchChannel() 339: AsicSwitchChannel::primch:8 cench1:8 cench2:0 rxstream:0 ap_bw:0 apCenCh:0 Scan:1
[ 19.591026] 7981@C00L1,mt7981_apply_dpd_flatness_data() 624: eeprom 0x19a bit 0 is 0, do runtime cal
[ 19.600169] 7981@C03L3,MtCmdChannelSwitch() 2541: ctrl_chl=8, ctrl_ch2=0, cent_ch=8 DBDCIdx=0, ChBand=0, BW=0, TXStream=2, RXStream=2, scan(1)
[ 19.642250] 7981@C03L3,MtCmdSetTxRxPath() 2803: ctrl_chl=8, ctrl_ch2=0, cent_ch=8, RxPath=3, BandIdx=0, ChBand=0, BW=0,TXStream=2, RXStream=3, scan(1)
[ 20.004233] 7981@C08L1,AsicSwitchChannel() 334: AsicSwitchChannel::bandIdx:0 ch_band:0 htbw:0 vht_bw:0 bw:0 extcha:0
[ 20.014795] 7981@C08L1,AsicSwitchChannel() 339: AsicSwitchChannel::primch:9 cench1:9 cench2:0 rxstream:0 ap_bw:0 apCenCh:0 Scan:1
[ 20.026554] 7981@C00L1,mt7981_apply_dpd_flatness_data() 624: eeprom 0x19a bit 0 is 0, do runtime cal
[ 20.035735] 7981@C03L3,MtCmdChannelSwitch() 2541: ctrl_chl=9, ctrl_ch2=0, cent_ch=9 DBDCIdx=0, ChBand=0, BW=0, TXStream=2, RXStream=2, scan(1)
[ 20.092189] 7981@C03L3,MtCmdSetTxRxPath() 2803: ctrl_chl=9, ctrl_ch2=0, cent_ch=9, RxPath=3, BandIdx=0, ChBand=0, BW=0,TXStream=2, RXStream=3, scan(1)
[ 20.448470] 7981@C08L1,AsicSwitchChannel() 334: AsicSwitchChannel::bandIdx:0 ch_band:0 htbw:0 vht_bw:0 bw:0 extcha:0
[ 20.459092] 7981@C08L1,AsicSwitchChannel() 339: AsicSwitchChannel::primch:10 cench1:10 cench2:0 rxstream:0 ap_bw:0 apCenCh:0 Scan:1
[ 20.471042] 7981@C00L1,mt7981_apply_dpd_flatness_data() 624: eeprom 0x19a bit 0 is 0, do runtime cal
[ 20.480206] 7981@C03L3,MtCmdChannelSwitch() 2541: ctrl_chl=10, ctrl_ch2=0, cent_ch=10 DBDCIdx=0, ChBand=0, BW=0, TXStream=2, RXStream=2, scan(1)
[ 20.532949] Per-port-per-queue mode is going to be enabled!
[ 20.538568] PPPQ use qid 0~5 (scheduler 0).
[ 20.543916] 7981@C03L3,MtCmdSetTxRxPath() 2803: ctrl_chl=10, ctrl_ch2=0, cent_ch=10, RxPath=3, BandIdx=0, ChBand=0, BW=0,TXStream=2, RXStream=3, scan(1)
[ 20.556085] Binding Threshold =1
[ 20.562952] tcp_life = 80
[ 20.575989] udp_life = 80
[ 20.900256] 7981@C08L1,AsicSwitchChannel() 334: AsicSwitchChannel::bandIdx:0 ch_band:0 htbw:0 vht_bw:0 bw:0 extcha:0
[ 20.910835] 7981@C08L1,AsicSwitchChannel() 339: AsicSwitchChannel::primch:11 cench1:11 cench2:0 rxstream:0 ap_bw:0 apCenCh:0 Scan:1
[ 20.922842] 7981@C00L1,mt7981_apply_dpd_flatness_data() 624: eeprom 0x19a bit 0 is 0, do runtime cal
[ 20.932116] 7981@C03L3,MtCmdChannelSwitch() 2541: ctrl_chl=11, ctrl_ch2=0, cent_ch=11 DBDCIdx=0, ChBand=0, BW=0, TXStream=2, RXStream=2, scan(1)
[ 21.003925] 7981@C03L3,MtCmdSetTxRxPath() 2803: ctrl_chl=11, ctrl_ch2=0, cent_ch=11, RxPath=3, BandIdx=0, ChBand=0, BW=0,TXStream=2, RXStream=3, scan(1)
[ 21.356185] 7981@C08L1,UpdateBeaconHandler() 1908: wdev(0) bss not ready (state:0, caller:update_ap_qload_to_bcn+0xa0/0xc8 [mt_wifi])!!
[ 21.372216] 7981@C08L1,AsicSwitchChannel() 334: AsicSwitchChannel::bandIdx:0 ch_band:0 htbw:0 vht_bw:0 bw:0 extcha:0
[ 21.382811] 7981@C08L1,AsicSwitchChannel() 339: AsicSwitchChannel::primch:12 cench1:12 cench2:0 rxstream:0 ap_bw:0 apCenCh:0 Scan:1
[ 21.394800] 7981@C00L1,mt7981_apply_dpd_flatness_data() 624: eeprom 0x19a bit 0 is 0, do runtime cal
[ 21.404068] 7981@C03L3,MtCmdChannelSwitch() 2541: ctrl_chl=12, ctrl_ch2=0, cent_ch=12 DBDCIdx=0, ChBand=0, BW=0, TXStream=2, RXStream=2, scan(1)
[ 21.489280] 7981@C03L3,MtCmdSetTxRxPath() 2803: ctrl_chl=12, ctrl_ch2=0, cent_ch=12, RxPath=3, BandIdx=0, ChBand=0, BW=0,TXStream=2, RXStream=3, scan(1)
[ddnsd_client_ubus_init.1150]: connected as e4d3ed93
[ 21.811926] Per-port-per-queue mode is going to be enabled!
[ 21.817515] PPPQ use qid 0~5 (scheduler 0).
[ 21.844385] 7981@C08L1,AsicSwitchChannel() 334: AsicSwitchChannel::bandIdx:0 ch_band:0 htbw:0 vht_bw:0 bw:0 extcha:0
[ 21.855017] 7981@C08L1,AsicSwitchChannel() 339: AsicSwitchChannel::primch:13 cench1:13 cench2:0 rxstream:0 ap_bw:0 apCenCh:0 Scan:1
[ 21.867190] 7981@C00L1,mt7981_apply_dpd_flatness_data() 624: eeprom 0x19a bit 0 is 0, do runtime cal
[ 21.876342] 7981@C03L3,MtCmdChannelSwitch() 2541: ctrl_chl=13, ctrl_ch2=0, cent_ch=13 DBDCIdx=0, ChBand=0, BW=0, TXStream=2, RXStream=2, scan(1)
[ 21.919080] 7981@C03L3,MtCmdSetTxRxPath() 2803: ctrl_chl=13, ctrl_ch2=0, cent_ch=13, RxPath=3, BandIdx=0, ChBand=0, BW=0,TXStream=2, RXStream=3, scan(1)
[ 22.288427] 7981@C08L1,UpdateBeaconHandler() 1908: wdev(0) bss not ready (state:0, caller:MTAPAutoSelectChannel+0x258/0x418 [mt_wifi])!!
[ 22.300712] 7981@C23L3,SelectClearChannelBusyTime() 1900: ====================================================================
[ 22.312135] 7981@C23L3,SelectClearChannelBusyTime() 1906: Channel 1 : Busy Time = 13265, Skip Channel = FALSE, BwCap = TRUE
[ 22.323543] 7981@C23L3,SelectClearChannelBusyTime() 1906: Channel 2 : Busy Time = 6302, Skip Channel = FALSE, BwCap = TRUE
[ 22.334923] 7981@C23L3,SelectClearChannelBusyTime() 1906: Channel 3 : Busy Time = 737, Skip Channel = FALSE, BwCap = TRUE
[ 22.346300] 7981@C23L3,SelectClearChannelBusyTime() 1906: Channel 4 : Busy Time = 3235, Skip Channel = FALSE, BwCap = TRUE
[ 22.357687] 7981@C23L3,SelectClearChannelBusyTime() 1906: Channel 5 : Busy Time = 3068, Skip Channel = FALSE, BwCap = TRUE
[ 22.369066] 7981@C23L3,SelectClearChannelBusyTime() 1906: Channel 6 : Busy Time = 7774, Skip Channel = FALSE, BwCap = TRUE
[ 22.380442] 7981@C23L3,SelectClearChannelBusyTime() 1906: Channel 7 : Busy Time = 4791, Skip Channel = FALSE, BwCap = TRUE
[ 22.391819] 7981@C23L3,SelectClearChannelBusyTime() 1906: Channel 8 : Busy Time = 6538, Skip Channel = FALSE, BwCap = TRUE
[ 22.403197] 7981@C23L3,SelectClearChannelBusyTime() 1906: Channel 9 : Busy Time = 1148, Skip Channel = FALSE, BwCap = TRUE
[ 22.414640] 7981@C23L3,SelectClearChannelBusyTime() 1906: Channel 10 : Busy Time = 8352, Skip Channel = FALSE, BwCap = TRUE
[ 22.426056] 7981@C23L3,SelectClearChannelBusyTime() 1906: Channel 11 : Busy Time = 15730, Skip Channel = FALSE, BwCap = TRUE
[ 22.437436] 7981@C23L3,SelectClearChannelBusyTime() 1906: Channel 12 : Busy Time = 4270, Skip Channel = FALSE, BwCap = TRUE
[ 22.448813] 7981@C23L3,SelectClearChannelBusyTime() 1906: Channel 13 : Busy Time = 0, Skip Channel = FALSE, BwCap = TRUE
[ 22.460188] 7981@C23L3,SelectClearChannelBusyTime() 1909: ====================================================================
[ 22.471588] 7981@C23L3,SelectClearChannelBusyTime() 2145: Rule 3 Channel Busy time value : Select Primary Channel 13
[ 22.482122] 7981@C23L3,SelectClearChannelBusyTime() 2147: Rule 3 Channel Busy time value : Min Channel Busy = 0
[ 22.492221] 7981@C23L3,SelectClearChannelBusyTime() 2152: Rule 3 Channel Busy time value : BW = 20
[ 22.501180] 7981@C23L3,SelectClearChannelBusyTime() 2186: [SelectClearChannelBusyTime] - band0 END
[ 22.510191] 7981@C23L3,operate_loader_phy() 360: oper_cfg: prim_ch(13), ht_bw(0), extcha(3), vht_bw(0), cen_ch_2(0), PhyMode=78!
[ 22.521759] 7981@C23L3,operate_loader_phy() 374: oper_dev after adjust: bw(0), prim_ch(13), cen_ch_1(13), cen_ch_2(0),ext_cha(0)!
[ 22.533411] 7981@C23L3,operate_loader_phy() 393: oper_dev after decision: bw(0), prim_ch(13), cen_ch_1(13), cen_ch_2(0)!
[ 22.544300] 7981@C23L3,DfsRadarChannelCheck() 3254: [DfsRadarChannelCheck]: wdev is not 5G
[ 22.552577] 7981@C08L1,AsicSwitchChannel() 334: AsicSwitchChannel::bandIdx:0 ch_band:0 htbw:0 vht_bw:0 bw:0 extcha:0
[ 22.563105] 7981@C08L1,AsicSwitchChannel() 339: AsicSwitchChannel::primch:13 cench1:13 cench2:0 rxstream:2 ap_bw:0 apCenCh:0 Scan:0
[ 22.575114] 7981@C00L1,mt7981_apply_dpd_flatness_data() 624: eeprom 0x19a bit 0 is 0, do runtime cal
[ 22.584262] 7981@C03L3,MtCmdChannelSwitch() 2541: ctrl_chl=13, ctrl_ch2=0, cent_ch=13 DBDCIdx=0, ChBand=0, BW=0, TXStream=2, RXStream=2, scan(0)
[ 23.004136] 7981@C03L3,MtCmdSetTxRxPath() 2803: ctrl_chl=13, ctrl_ch2=0, cent_ch=13, RxPath=3, BandIdx=0, ChBand=0, BW=0,TXStream=2, RXStream=3, scan(0)
[ 23.035900] 7981@C12L1,EDCCAInit() 22144: EDCCA compensation: uni_compensation=0, bw_compensation=0, final compensation=0
[ 23.046959] 7981@C23L3,DfsCacNormalStart() 3748: wdev is not 5G
[ 23.052894] 7981@C23L3,DfsRadarChannelCheck() 3254: [DfsRadarChannelCheck]: wdev is not 5G
[ 23.061184] WiFi@C12L1,wlan_operate_set_vht_bw() 83: wlan_operate_set_vht_bw(): new vht_bw:255 > cap_vht_bw: 0, correct to cap_vht_bw
[ 23.073175] 7981@C23L3,operate_loader_phy() 360: oper_cfg: prim_ch(13), ht_bw(0), extcha(3), vht_bw(2), cen_ch_2(0), PhyMode=78!
[ 23.084769] 7981@C23L3,operate_loader_phy() 374: oper_dev after adjust: bw(0), prim_ch(13), cen_ch_1(13), cen_ch_2(0),ext_cha(0)!
[ 23.096420] 7981@C23L3,operate_loader_phy() 393: oper_dev after decision: bw(0), prim_ch(13), cen_ch_1(13), cen_ch_2(0)!
[ 23.107288] 7981@C23L3,DfsRadarChannelCheck() 3254: [DfsRadarChannelCheck]: wdev is not 5G
[ 23.115550] 7981@C23L3,DfsCacNormalStart() 3748: wdev is not 5G
[ 23.121477] 7981@C23L3,DfsRadarChannelCheck() 3254: [DfsRadarChannelCheck]: wdev is not 5G
[ 23.129748] 7981@C23L1,DfsBuildChannelList() 3873: [RDM]: wdev is not 5G.
[ 23.136549] 7981@C23L3,zero_wait_dfs_switch_ch() 1048: outband ch 0, ch_stat 0
[ 23.143993] 7981@C08L2,APStartUpForMbss() 997: ===>(caller:ap_inf_open+0x140/0x520 [mt_wifi]), mbss_idx:0, CfgMode:0
[ 23.154542] 7981@C15L2,APPMFInit() 133: [PMF] apidx=0, MFPC=0, MFPR=0, SHA256=0
[ 23.161920] 7981@C18L3,BuildChannelList() 497:
[ 23.166750] WiFi@C00L2,dump_ht_cap() 29: Caller: dump_ht_cap+0x10/0x20 [mt_wifi]
[ 23.174426] WiFi@C08L2,ap_link_up() 7190: (caller:wdev_do_linkup+0x20/0x38 [mt_wifi]), wdev(0)
[ 23.183088] 7981@C01L3,wifi_sys_linkup() 1231: wdev idx = 0
[ 23.259100] 7981@C00L3,wtc_acquire_groupkey_wcid() 84: Found a non-occupied wtbl_idx:287 for WDEV_TYPE:1
[ 23.259100] LinkToOmacIdx = 0, LinkToWdevType = 1
[ 23.273523] 7981@C08L3,hw_ctrl_flow_v2_link_up() 72: wdev_idx=0
[ 23.288491] 7981@C08L3,UpdateBeaconHandler() 1928: BCN_UPDATE_INIT, OmacIdx = 0 (ra0)
[ 23.296342] 7981@C08L3,UpdateBeaconHandler() 1941: Band0 BcnInitedRnd = 68
[ 23.352540] 7981@C00L1,TxCCKStreamCtrl() 21606: set wrong parameters
[ 23.369238] PrintSrCmd:
[ 23.369238] u1CmdSubId = 1, u1ArgNum = 0, u1DbdcIdx = 0, u1Status = 0
[ 23.369238] u1DropTaIdx = 0, u1StaIdx = 0, u4Value = 0
[ 23.383352] PrintSrCmd:
[ 23.383352] u1CmdSubId = 5, u1ArgNum = 0, u1DbdcIdx = 0, u1Status = 0
[ 23.383352] u1DropTaIdx = 0, u1StaIdx = 0, u4Value = 0
[ 23.397407] PrintSrCmd:
[ 23.397407] u1CmdSubId = 3, u1ArgNum = 0, u1DbdcIdx = 0, u1Status = 0
[ 23.397407] u1DropTaIdx = 0, u1StaIdx = 0, u4Value = 1
[ 23.411399] PrintSrCmd:
[ 23.411399] u1CmdSubId = 23, u1ArgNum = 0, u1DbdcIdx = 0, u1Status = 0
[ 23.411399] u1DropTaIdx = 0, u1StaIdx = 0, u4Value = 0
[ 23.425475] PrintSrCmd:
[ 23.425475] u1CmdSubId = 31, u1ArgNum = 0, u1DbdcIdx = 0, u1Status = 0
[ 23.425475] u1DropTaIdx = 0, u1StaIdx = 0, u4Value = 0
[ 23.439548] PrintSrCmd:
[ 23.439548] u1CmdSubId = 33, u1ArgNum = 0, u1DbdcIdx = 0, u1Status = 0
[ 23.439548] u1DropTaIdx = 0, u1StaIdx = 0, u4Value = 0
[ 23.453671] 7981@C12L1,EDCCAInit() 22144: EDCCA compensation: uni_compensation=0, bw_compensation=0, final compensation=0
[ 23.464688] 7981@C03L3,MtCmdTxPwrShowInfo() 13800: ucTxPowerInfoCatg: 2, BandIdx: 0
[ 23.472442] 7981@C03L3,MtCmdTxPwrShowInfo() 13829: (ret = 0)
[ 23.472558] [mtf_txpower_all_rate_info] band_idx:0 pwr:50 ChBand:2G ePAGain:0
[ 23.478112] mtk_ppe_dev_register_hook : ineterface ra0 register (1)
[ 23.492534] br-lan: port 2(lan2) entered blocking state
[ 23.497806] br-lan: port 2(lan2) entered forwarding state
[ 23.507644] 7981@C12L1,rt28xx_ap_ioctl() 833: interface is down, cmd [8be1] return!!!
[ 23.591426] 7981@C12L1,rt28xx_ap_ioctl() 833: interface is down, cmd [8be1] return!!!
[ 23.625891] 7981@C12L1,rt28xx_ap_ioctl() 833: interface is down, cmd [8be1] return!!!
[ 23.640533] nf_unregister_hooks()
[ 24.011888] BcnCheck start after 4300 ms (ra0)
[ 24.026302] 7981@C12L1,rt28xx_ap_ioctl() 833: interface is down, cmd [8be1] return!!!
[ 24.062256] 7981@C12L1,rt28xx_ap_ioctl() 833: interface is down, cmd [8be1] return!!!
[ 24.085301] 7981@C12L1,rt28xx_ap_ioctl() 833: interface is down, cmd [8be1] return!!!
[ 24.115828] 7981@C12L1,rt28xx_ap_ioctl() 833: interface is down, cmd [8be1] return!!!
start service
[ 24.174748] 7981@C12L1,rt28xx_ap_ioctl() 833: interface is down, cmd [8be1] return!!!
[ 24.206012] 7981@C12L1,rt28xx_ap_ioctl() 833: interface is down, cmd [8be1] return!!!
[ 24.241093] 7981@C12L1,rt28xx_ap_ioctl() 833: interface is down, cmd [8be1] return!!!
[ 24.271131] 7981@C12L1,rt28xx_ap_ioctl() 833: interface is down, cmd [8be1] return!!!
[ 24.293813] 7981@C12L1,rt28xx_ap_ioctl() 833: interface is down, cmd [8be1] return!!!
[ 24.531711] br-lan: port 4(ra0) entered blocking state
[ 24.537161] br-lan: port 4(ra0) entered disabled state
[ 24.542555] device ra0 entered promiscuous mode
[ 24.547180] br-lan: port 4(ra0) entered blocking state
[ 24.552346] br-lan: port 4(ra0) entered forwarding state
enable_mtkwifi(band2g,,,)
[ 24.626646] 7981@C08L2,mbss_virtual_if_open() 135: ===> ra1
[ 24.632341] 7981@C01L2,RTMP_COM_IoctlHandle() 1514: -> CMD_RTPRIV_IOCTL_VIRTUAL_INF_INIT
[ 24.640492] 7981@C01L2,RTMP_COM_IoctlHandle() 1491: -> CMD_RTPRIV_IOCTL_VIRTUAL_INF_UP
[ 24.648516] WiFi@C01L3,wifi_sys_open() 856: wdev idx = 1
[ 24.654175] 7981@C18L3,BuildChannelList() 497:
[ 24.658795] 7981@C23L3,operate_loader_phy() 360: oper_cfg: prim_ch(13), ht_bw(0), extcha(3), vht_bw(0), cen_ch_2(0), PhyMode=78!
[ 24.670403] 7981@C23L3,operate_loader_phy() 374: oper_dev after adjust: bw(0), prim_ch(13), cen_ch_1(13), cen_ch_2(0),ext_cha(0)!
[ 24.682075] 7981@C23L3,operate_loader_phy() 393: oper_dev after decision: bw(0), prim_ch(13), cen_ch_1(13), cen_ch_2(0)!
[ 24.692960] 7981@C23L3,DfsRadarChannelCheck() 3254: [DfsRadarChannelCheck]: wdev is not 5G
[ 24.701253] 7981@C23L3,DfsCacNormalStart() 3748: wdev is not 5G
[ 24.707196] 7981@C23L3,DfsRadarChannelCheck() 3254: [DfsRadarChannelCheck]: wdev is not 5G
[ 24.715709] WiFi@C00L2,dump_ht_cap() 29: Caller: wlan_operate_init+0xa4/0x148 [mt_wifi]
[ 24.723760] wdev_attr_update(): wdevId1 = 74:2a:d7:be:c2:20
[ 24.729389] WiFi@C12L1,wifi_sys_open() 907: wifi_sys_open():band0 group_idx[1]=9, bw_grp=16 omac=17
[ 24.742947] 7981@C08L3,hw_ctrl_flow_v2_open() 13: wdev_idx=1
[ 24.761103] 7981@C02L2,AsicRadioOnOffCtrl() 2355: DbdcIdx=0 RadioOn
[ 24.768305] 7981@C00L2,ApAutoChannelAtBootUp() 335: ----------------->
[ 24.783902] 7981@C03L1,MtCmdSetMacTxRx() 10296: (ret = 0)
[ 24.794445] 7981@C03L1,MtCmdSetMacTxRx() 10296: (ret = 0)
[ 24.799897] 7981@C00L1,ApAutoChannelAtBootUp() 503: not A band
[ 24.805765] 7981@C08L1,ap_run_at_boot() 637: ACS is disable !!
[ 24.812641] 7981@C08L2,APStartUpForMbss() 997: ===>(caller:ap_inf_open+0x140/0x520 [mt_wifi]), mbss_idx:1, CfgMode:0
[ 24.823212] 7981@C15L2,APPMFInit() 133: [PMF] apidx=1, MFPC=0, MFPR=0, SHA256=0
[ 24.830731] 7981@C18L3,BuildChannelList() 497:
[ 24.835603] WiFi@C00L2,dump_ht_cap() 29: Caller: dump_ht_cap+0x10/0x20 [mt_wifi]
[ 24.843440] WiFi@C08L2,ap_link_up() 7190: (caller:wdev_do_linkup+0x20/0x38 [mt_wifi]), wdev(1)
[ 24.852095] 7981@C01L3,wifi_sys_linkup() 1231: wdev idx = 1
[ 24.930658] 7981@C00L3,wtc_acquire_groupkey_wcid() 84: Found a non-occupied wtbl_idx:286 for WDEV_TYPE:1
[ 24.930658] LinkToOmacIdx = 11, LinkToWdevType = 1
[ 24.945299] 7981@C08L3,hw_ctrl_flow_v2_link_up() 72: wdev_idx=1
[ 24.959547] 7981@C08L3,UpdateBeaconHandler() 1928: BCN_UPDATE_INIT, OmacIdx = 11 (ra1)
[ 24.987348] 7981@C00L1,TxCCKStreamCtrl() 21606: set wrong parameters
[ 25.004125] PrintSrCmd:
[ 25.004125] u1CmdSubId = 1, u1ArgNum = 0, u1DbdcIdx = 0, u1Status = 0
[ 25.004125] u1DropTaIdx = 0, u1StaIdx = 0, u4Value = 0
[ 25.018203] PrintSrCmd:
[ 25.018203] u1CmdSubId = 5, u1ArgNum = 0, u1DbdcIdx = 0, u1Status = 0
[ 25.018203] u1DropTaIdx = 0, u1StaIdx = 0, u4Value = 0
[ 25.018219] PrintSrCmd:
[ 25.018219] u1CmdSubId = 3, u1ArgNum = 0, u1DbdcIdx = 0, u1Status = 0
[ 25.018219] u1DropTaIdx = 0, u1StaIdx = 0, u4Value = 1
[ 25.018229] PrintSrCmd:
[ 25.018229] u1CmdSubId = 23, u1ArgNum = 0, u1DbdcIdx = 0, u1Status = 0
[ 25.018229] u1DropTaIdx = 0, u1StaIdx = 0, u4Value = 0
[ 25.018237] PrintSrCmd:
[ 25.018237] u1CmdSubId = 31, u1ArgNum = 0, u1DbdcIdx = 0, u1Status = 0
[ 25.018237] u1DropTaIdx = 0, u1StaIdx = 0, u4Value = 0
[ 25.018246] PrintSrCmd:
[ 25.018246] u1CmdSubId = 33, u1ArgNum = 0, u1DbdcIdx = 0, u1Status = 0
[ 25.018246] u1DropTaIdx = 0, u1StaIdx = 0, u4Value = 0
[ 25.018285] 7981@C12L1,EDCCAInit() 22144: EDCCA compensation: uni_compensation=0, bw_compensation=0, final compensation=0
[ 25.099476] 7981@C03L3,MtCmdTxPwrShowInfo() 13800: ucTxPowerInfoCatg: 2, BandIdx: 0
[ 25.107563] 7981@C03L3,MtCmdTxPwrShowInfo() 13829: (ret = 0)
[ 25.107674] [mtf_txpower_all_rate_info] band_idx:0 pwr:50 ChBand:2G ePAGain:0
[ 25.113241] mtk_ppe_dev_register_hook : ineterface ra1 register (2)
[Switch_Print_Usage.1374]: magicswitch dumpfile
[ 25.170886] br-lan: port 5(ra1) entered blocking state
[ 25.176086] br-lan: port 5(ra1) entered disabled state
[ 25.181496] device ra1 entered promiscuous mode
[ 25.186192] br-lan: port 5(ra1) entered blocking state
[ 25.191380] br-lan: port 5(ra1) entered forwarding state
enable_mtkwifi(band2g,,,) done
[ 25.271353] 7981@C12L1,rt28xx_ap_ioctl() 833: interface is down, cmd [8be1] return!!!
[ 25.327319] 7981@C12L1,rt28xx_ap_ioctl() 833: interface is down, cmd [8be1] return!!!
[ 25.356592] 7981@C12L1,rt28xx_ap_ioctl() 833: interface is down, cmd [8be1] return!!!
[ 25.366063] 7981@C08L2,mbss_virtual_if_open() 135: ===> rax0
[ 25.371855] 7981@C01L2,RTMP_COM_IoctlHandle() 1514: -> CMD_RTPRIV_IOCTL_VIRTUAL_INF_INIT
[ 25.380275] 7981@C01L2,RTMP_COM_IoctlHandle() 1491: -> CMD_RTPRIV_IOCTL_VIRTUAL_INF_UP
[ 25.388307] WiFi@C01L3,wifi_sys_open() 856: wdev idx = 6
[ 25.393923] 7981@C18L3,BuildChannelList() 497:
[ 25.398499] 7981@C00L3,BuildChannelList() 527: BandIdx = 1, PhyMode = 177, ChListNum = 13:
[ 25.406826] 7981@C23L3,DfsBuildChannelList() 3918: Done
[ 25.412085] 7981@C23L3,RadarStateCheck() 256: Bw160 Zero Wait State: 0, phy_bw=3, band_bw[band_idx]=0
[ 25.421378] 7981@C23L3,RadarStateCheck() 315: RD_NORMAL_MODE
[ 25.428226] 7981@C23L3,operate_loader_phy() 360: oper_cfg: prim_ch(0), ht_bw(1), extcha(3), vht_bw(2), cen_ch_2(0), PhyMode=177!
[ 25.439789] phy_freq_adjust : no prim_ch value for adjust!
[ 25.445292] 7981@C23L1,operate_loader_phy() 364: phy_freq_adjust failed!WiFi@C00L2,dump_ht_cap() 29: Caller: wlan_operate_init+0xa4/0x148 [mt_wifi]
[ 25.458755] wdev_attr_update(): wdevId6 = 70:2a:d7:be:c2:21
[ 25.464415] WiFi@C12L1,wifi_sys_open() 907: wifi_sys_open():band1 group_idx[6]=4, bw_grp=16 omac=0
[ 25.473692] 7981@C08L3,hw_ctrl_flow_v2_open() 13: wdev_idx=6
[ 25.750011] 7981@C23L1,HcGetBandByChannel() 1234: No hdev parking on channel:0, just return a default band_idx 0!
[ 25.761789] 7981@C02L2,AsicRadioOnOffCtrl() 2355: DbdcIdx=0 RadioOn
[ 25.804084] 7981@C00L2,ApAutoChannelAtBootUp() 335: ----------------->
[ 25.818360] 7981@C03L1,MtCmdSetMacTxRx() 10296: (ret = 0)
[ 25.858948] 7981@C03L1,MtCmdSetMacTxRx() 10296: (ret = 0)
[ 25.864397] 7981@C23L2,build_acs_scan_ch_list_by_bw() 2721: ChListNum56G = 13
[ 25.871614] 7981@C23L3,build_acs_scan_ch_list_by_bw() 2833: PrimChannel= 36, CenChannel= 50, BW=3, BwCap=1, SkipChannel=0, BuildDone=1
[ 25.883741] 7981@C23L3,build_acs_scan_ch_list_by_bw() 2833: PrimChannel= 40, CenChannel= 50, BW=3, BwCap=1, SkipChannel=0, BuildDone=1
[ 25.895860] 7981@C23L3,build_acs_scan_ch_list_by_bw() 2833: PrimChannel= 44, CenChannel= 50, BW=3, BwCap=1, SkipChannel=0, BuildDone=1
[ 25.907951] 7981@C23L3,build_acs_scan_ch_list_by_bw() 2833: PrimChannel= 48, CenChannel= 50, BW=3, BwCap=1, SkipChannel=0, BuildDone=1
[ 25.920046] 7981@C23L3,build_acs_scan_ch_list_by_bw() 2833: PrimChannel= 52, CenChannel= 50, BW=3, BwCap=1, SkipChannel=1, BuildDone=1
[ 25.932131] 7981@C23L3,build_acs_scan_ch_list_by_bw() 2833: PrimChannel= 56, CenChannel= 50, BW=3, BwCap=1, SkipChannel=1, BuildDone=1
[ 25.944233] 7981@C23L3,build_acs_scan_ch_list_by_bw() 2833: PrimChannel= 60, CenChannel= 50, BW=3, BwCap=1, SkipChannel=1, BuildDone=1
[ 25.956318] 7981@C23L3,build_acs_scan_ch_list_by_bw() 2833: PrimChannel= 64, CenChannel= 50, BW=3, BwCap=1, SkipChannel=1, BuildDone=1
[ 25.968406] 7981@C23L3,build_acs_scan_ch_list_by_bw() 2833: PrimChannel=149, CenChannel=149, BW=3, BwCap=0, SkipChannel=0, BuildDone=0
[ 25.980495] 7981@C23L3,build_acs_scan_ch_list_by_bw() 2833: PrimChannel=153, CenChannel=153, BW=3, BwCap=0, SkipChannel=0, BuildDone=0
[ 25.992589] 7981@C23L3,build_acs_scan_ch_list_by_bw() 2833: PrimChannel=157, CenChannel=157, BW=3, BwCap=0, SkipChannel=0, BuildDone=0
[ 26.004674] 7981@C23L3,build_acs_scan_ch_list_by_bw() 2833: PrimChannel=161, CenChannel=161, BW=3, BwCap=0, SkipChannel=0, BuildDone=0
[ 26.016759] 7981@C23L3,build_acs_scan_ch_list_by_bw() 2833: PrimChannel=165, CenChannel=165, BW=3, BwCap=0, SkipChannel=0, BuildDone=0
[ 26.028866] 7981@C23L3,build_acs_scan_ch_list_by_bw() 2874: ACSChListNum = 4, ACSChBW = 3
[ 26.037285] 7981@C08L1,UpdateBeaconHandler() 1908: wdev(6) bss not ready (state:0, caller:MTAPAutoSelectChannel+0x108/0x418 [mt_wifi])!!
[ 26.049567] 7981@C08L1,AsicSwitchChannel() 334: AsicSwitchChannel::bandIdx:1 ch_band:1 htbw:0 vht_bw:0 bw:0 extcha:0
[ 26.060114] 7981@C08L1,AsicSwitchChannel() 339: AsicSwitchChannel::primch:36 cench1:36 cench2:0 rxstream:0 ap_bw:0 apCenCh:0 Scan:1
[ 26.072046] 7981@C00L1,mt7981_apply_dpd_flatness_data() 624: eeprom 0x19a bit 0 is 0, do runtime cal
[ 26.081221] 7981@C03L3,MtCmdChannelSwitch() 2541: ctrl_chl=36, ctrl_ch2=0, cent_ch=36 DBDCIdx=1, ChBand=1, BW=0, TXStream=3, RXStream=3, scan(1)
[ 26.636361] 7981@C03L3,MtCmdSetTxRxPath() 2803: ctrl_chl=36, ctrl_ch2=0, cent_ch=36, RxPath=7, BandIdx=1, ChBand=1, BW=0,TXStream=3, RXStream=7, scan(1)
[ 26.767910] BcnCheck start after 1800 ms (ra0)
[ 26.772753] 7981@C08L1,UpdateBeaconHandler() 1908: wdev(6) bss not ready (state:0, caller:update_ap_qload_to_bcn+0xa0/0xc8 [mt_wifi])!!
[ 26.788618] mt7530 mdio-bus:1f lan2: Link is Down
[ 27.276241] 7981@C08L1,AsicSwitchChannel() 334: AsicSwitchChannel::bandIdx:1 ch_band:1 htbw:0 vht_bw:0 bw:0 extcha:0
[ 27.286807] 7981@C08L1,AsicSwitchChannel() 339: AsicSwitchChannel::primch:40 cench1:40 cench2:0 rxstream:0 ap_bw:0 apCenCh:0 Scan:1
[ 27.298857] 7981@C00L1,mt7981_apply_dpd_flatness_data() 624: eeprom 0x19a bit 0 is 0, do runtime cal
[ 27.308110] 7981@C03L3,MtCmdChannelSwitch() 2541: ctrl_chl=40, ctrl_ch2=0, cent_ch=40 DBDCIdx=1, ChBand=1, BW=0, TXStream=3, RXStream=3, scan(1)
[ 27.413369] 7981@C03L3,MtCmdSetTxRxPath() 2803: ctrl_chl=40, ctrl_ch2=0, cent_ch=40, RxPath=7, BandIdx=1, ChBand=1, BW=0,TXStream=3, RXStream=7, scan(1)
[ 27.880196] 7981@C08L1,AsicSwitchChannel() 334: AsicSwitchChannel::bandIdx:1 ch_band:1 htbw:0 vht_bw:0 bw:0 extcha:0
[ 27.890772] 7981@C08L1,AsicSwitchChannel() 339: AsicSwitchChannel::primch:44 cench1:44 cench2:0 rxstream:0 ap_bw:0 apCenCh:0 Scan:1
[ 27.902704] 7981@C00L1,mt7981_apply_dpd_flatness_data() 624: eeprom 0x19a bit 0 is 0, do runtime cal
[ 27.911856] 7981@C03L3,MtCmdChannelSwitch() 2541: ctrl_chl=44, ctrl_ch2=0, cent_ch=44 DBDCIdx=1, ChBand=1, BW=0, TXStream=3, RXStream=3, scan(1)
[ 27.977006] 7981@C03L3,MtCmdSetTxRxPath() 2803: ctrl_chl=44, ctrl_ch2=0, cent_ch=44, RxPath=7, BandIdx=1, ChBand=1, BW=0,TXStream=3, RXStream=7, scan(1)
[ 28.432258] 7981@C08L1,AsicSwitchChannel() 334: AsicSwitchChannel::bandIdx:1 ch_band:1 htbw:0 vht_bw:0 bw:0 extcha:0
[ 28.442818] 7981@C08L1,AsicSwitchChannel() 339: AsicSwitchChannel::primch:48 cench1:48 cench2:0 rxstream:0 ap_bw:0 apCenCh:0 Scan:1
[ 28.454843] 7981@C00L1,mt7981_apply_dpd_flatness_data() 624: eeprom 0x19a bit 0 is 0, do runtime cal
[ 28.464013] 7981@C03L3,MtCmdChannelSwitch() 2541: ctrl_chl=48, ctrl_ch2=0, cent_ch=48 DBDCIdx=1, ChBand=1, BW=0, TXStream=3, RXStream=3, scan(1)
[ 28.530009] 7981@C03L3,MtCmdSetTxRxPath() 2803: ctrl_chl=48, ctrl_ch2=0, cent_ch=48, RxPath=7, BandIdx=1, ChBand=1, BW=0,TXStream=3, RXStream=7, scan(1)
[ 28.988622] 7981@C08L1,UpdateBeaconHandler() 1908: wdev(6) bss not ready (state:0, caller:MTAPAutoSelectChannel+0x258/0x418 [mt_wifi])!!
[ 29.000950] 7981@C23L3,SelectClearChannelBusyTime() 1900: ====================================================================
[ 29.012362] 7981@C23L3,SelectClearChannelBusyTime() 1906: Channel 36 : Busy Time = 221, Skip Channel = FALSE, BwCap = TRUE
[ 29.023764] 7981@C23L3,SelectClearChannelBusyTime() 1906: Channel 40 : Busy Time = 0, Skip Channel = FALSE, BwCap = TRUE
[ 29.035160] 7981@C23L3,SelectClearChannelBusyTime() 1906: Channel 44 : Busy Time = 451, Skip Channel = FALSE, BwCap = TRUE
[ 29.046550] 7981@C23L3,SelectClearChannelBusyTime() 1906: Channel 48 : Busy Time = 696, Skip Channel = FALSE, BwCap = TRUE
[ 29.057940] 7981@C23L3,SelectClearChannelBusyTime() 1909: ====================================================================
[ 29.069342] 7981@C23L3,SelectClearChannelBusyTime() 2145: Rule 3 Channel Busy time value : Select Primary Channel 40
[ 29.079876] 7981@C23L3,SelectClearChannelBusyTime() 2147: Rule 3 Channel Busy time value : Min Channel Busy = 696
[ 29.090164] 7981@C23L3,SelectClearChannelBusyTime() 2152: Rule 3 Channel Busy time value : BW = 160
[ 29.099216] 7981@C23L3,SelectClearChannelBusyTime() 2186: [SelectClearChannelBusyTime] - band1 END
[ 29.108193] 7981@C23L3,RadarStateCheck() 256: Bw160 Zero Wait State: 0, phy_bw=3, band_bw[band_idx]=0
[ 29.117429] 7981@C23L3,DfsGetSysParameters() 1515: Get before pDfsParam->PrimCh(0) band(0) band_bw(0), outbw(0)
[ 29.127527] 7981@C23L3,DfsGetSysParameters() 1561: Get after pDfsParam->PrimCh(40) band(1) band_bw(3), outbw(0)
[ 29.137613] 7981@C23L3,RadarStateCheck() 276: cac_not_req 0
[ 29.144352] 7981@C23L3,operate_loader_phy() 360: oper_cfg: prim_ch(40), ht_bw(1), extcha(3), vht_bw(2), cen_ch_2(0), PhyMode=177!
[ 29.156017] 7981@C23L3,operate_loader_phy() 374: oper_dev after adjust: bw(3), prim_ch(40), cen_ch_1(50), cen_ch_2(0),ext_cha(3)!
[ 29.167672] 7981@C23L3,operate_loader_phy() 393: oper_dev after decision: bw(3), prim_ch(40), cen_ch_1(50), cen_ch_2(0)!
[ 29.178550] 7981@C23L3,DfsGetSysParameters() 1515: Get before pDfsParam->PrimCh(40) band(1) band_bw(3), outbw(0)
[ 29.188771] 7981@C23L3,DfsGetSysParameters() 1561: Get after pDfsParam->PrimCh(40) band(1) band_bw(3), outbw(0)
[ 29.198865] 7981@C23L3,DfsCacNormalStart() 3784: [RDM] CAC 0 seconds start . Disable MAC TX
[ 29.207269] 7981@C08L1,AsicSwitchChannel() 334: AsicSwitchChannel::bandIdx:1 ch_band:1 htbw:1 vht_bw:2 bw:3 extcha:3
[ 29.217809] 7981@C08L1,AsicSwitchChannel() 339: AsicSwitchChannel::primch:40 cench1:50 cench2:0 rxstream:2 ap_bw:0 apCenCh:0 Scan:0
[ 29.229652] 7981@C23L3,DfsSwitchCheck() 4074: DFS ByPass TX calibration.
[ 29.236405] 7981@C00L1,mt7981_apply_dpd_flatness_data() 624: eeprom 0x19a bit 0 is 0, do runtime cal
[ 29.245575] 7981@C03L3,MtCmdChannelSwitch() 2541: ctrl_chl=40, ctrl_ch2=0, cent_ch=50 DBDCIdx=1, ChBand=1, BW=3, TXStream=3, RXStream=3, scan(0)
[ 29.527919] 7981@C03L3,MtCmdSetTxRxPath() 2803: ctrl_chl=40, ctrl_ch2=0, cent_ch=50, RxPath=7, BandIdx=1, ChBand=1, BW=3,TXStream=3, RXStream=7, scan(0)
[ 29.551892] 7981@C12L1,EDCCAInit() 22144: EDCCA compensation: uni_compensation=0, bw_compensation=0, final compensation=0
[ 29.562897] 7981@C23L3,DfsGetSysParameters() 1515: Get before pDfsParam->PrimCh(40) band(1) band_bw(3), outbw(0)
[ 29.573080] 7981@C23L3,DfsGetSysParameters() 1561: Get after pDfsParam->PrimCh(40) band(1) band_bw(3), outbw(0)
[ 29.583250] 7981@C23L3,DfsBuildChannelList() 3918: Done
[ 29.588505] 7981@C23L3,zero_wait_dfs_switch_ch() 1048: outband ch 0, ch_stat 0
[ 29.595736] 7981@C23L3,zero_wait_dfs_switch_ch() 1055: bDedicatedZeroWaitDefault == 0
[ 29.603773] 7981@C08L2,APStartUpForMbss() 997: ===>(caller:ap_inf_open+0x140/0x520 [mt_wifi]), mbss_idx:6, CfgMode:0
[ 29.614339] 7981@C15L2,APPMFInit() 133: [PMF] apidx=6, MFPC=0, MFPR=0, SHA256=0
[ 29.621732] 7981@C18L3,BuildChannelList() 497:
[ 29.626597] WiFi@C00L2,dump_ht_cap() 29: Caller: dump_ht_cap+0x10/0x20 [mt_wifi]
[ 29.634283] WiFi@C08L2,ap_link_up() 7190: (caller:wdev_do_linkup+0x20/0x38 [mt_wifi]), wdev(6)
[ 29.642965] 7981@C01L3,wifi_sys_linkup() 1231: wdev idx = 6
[ 29.722697] 7981@C00L3,wtc_acquire_groupkey_wcid() 84: Found a non-occupied wtbl_idx:285 for WDEV_TYPE:1
[ 29.722697] LinkToOmacIdx = 0, LinkToWdevType = 1
[ 29.737155] 7981@C08L3,hw_ctrl_flow_v2_link_up() 72: wdev_idx=6
[ 29.757447] 7981@C08L3,UpdateBeaconHandler() 1928: BCN_UPDATE_INIT, OmacIdx = 0 (rax0)
[ 29.765390] 7981@C08L3,UpdateBeaconHandler() 1941: Band1 BcnInitedRnd = 128
[ 29.952503] 7981@C23L3,DfsCacEndUpdate() 3338: [RDM] CAC end. Enable MAC TX.
[ 29.959623] 7981@C12L1,EDCCAInit() 22144: EDCCA compensation: uni_compensation=0, bw_compensation=0, final compensation=0
[ 30.199783] PrintSrCmd:
[ 30.199783] u1CmdSubId = 1, u1ArgNum = 0, u1DbdcIdx = 1, u1Status = 0
[ 30.199783] u1DropTaIdx = 0, u1StaIdx = 0, u4Value = 0
[ 30.213811] PrintSrCmd:
[ 30.213811] u1CmdSubId = 5, u1ArgNum = 0, u1DbdcIdx = 1, u1Status = 0
[ 30.213811] u1DropTaIdx = 0, u1StaIdx = 0, u4Value = 0
[ 30.227813] PrintSrCmd:
[ 30.227813] u1CmdSubId = 3, u1ArgNum = 0, u1DbdcIdx = 1, u1Status = 0
[ 30.227813] u1DropTaIdx = 0, u1StaIdx = 0, u4Value = 1
[ 30.241801] PrintSrCmd:
[ 30.241801] u1CmdSubId = 23, u1ArgNum = 0, u1DbdcIdx = 1, u1Status = 0
[ 30.241801] u1DropTaIdx = 0, u1StaIdx = 0, u4Value = 0
[ 30.255874] PrintSrCmd:
[ 30.255874] u1CmdSubId = 31, u1ArgNum = 0, u1DbdcIdx = 1, u1Status = 0
[ 30.255874] u1DropTaIdx = 0, u1StaIdx = 0, u4Value = 0
[ 30.269957] PrintSrCmd:
[ 30.269957] u1CmdSubId = 33, u1ArgNum = 0, u1DbdcIdx = 1, u1Status = 0
[ 30.269957] u1DropTaIdx = 0, u1StaIdx = 0, u4Value = 0
[ 30.284049] 7981@C12L1,EDCCAInit() 22144: EDCCA compensation: uni_compensation=0, bw_compensation=0, final compensation=0
[ 30.295057] 7981@C03L3,MtCmdTxPwrShowInfo() 13800: ucTxPowerInfoCatg: 2, BandIdx: 1
[ 30.302819] 7981@C03L3,MtCmdTxPwrShowInfo() 13829: (ret = 0)
[ 30.302933] [mtf_txpower_all_rate_info] band_idx:1 pwr:48 ChBand:5G ePAGain:0
[ 30.308490] mtk_ppe_dev_register_hook : ineterface rax0 register (3)
[ 30.323771] 7981@C12L1,rt28xx_ap_ioctl() 833: interface is down, cmd [8be1] return!!!
[ 30.332818] br-lan: port 2(lan2) entered disabled state
[ 30.344226] 7981@C12L1,rt28xx_ap_ioctl() 833: interface is down, cmd [8be1] return!!!
[ 30.352806] 7981@C12L1,rt28xx_ap_ioctl() 833: interface is down, cmd [8be1] return!!!
[ 30.362868] 7981@C12L1,rt28xx_ap_ioctl() 833: interface is down, cmd [8be1] return!!!
[ 30.374962] 7981@C12L1,rt28xx_ap_ioctl() 833: interface is down, cmd [8be1] return!!!
[ 30.383498] 7981@C12L1,rt28xx_ap_ioctl() 833: interface is down, cmd [8be1] return!!!
[ 30.482044] 7981@C12L1,rt28xx_ap_ioctl() 833: interface is down, cmd [8be1] return!!!
[ 30.489946] 7981@C12L1,rt28xx_ap_ioctl() 833: interface is down, cmd [8be1] return!!!
[ 30.509218] 7981@C12L1,rt28xx_ap_ioctl() 833: interface is down, cmd [8be1] return!!!
[ 30.518070] 7981@C12L1,rt28xx_ap_ioctl() 833: interface is down, cmd [8be1] return!!!
[ 30.532194] 7981@C12L1,rt28xx_ap_ioctl() 833: interface is down, cmd [8be1] return!!!
[ 30.570103] 7981@C12L1,rt28xx_ap_ioctl() 833: interface is down, cmd [8be1] return!!!
[ 30.580373] 7981@C12L1,rt28xx_ap_ioctl() 833: interface is down, cmd [8be1] return!!!
[ 30.588705] 7981@C12L1,rt28xx_ap_ioctl() 833: interface is down, cmd [8be1] return!!!
[ 30.634425] 7981@C12L1,rt28xx_ap_ioctl() 833: interface is down, cmd [8be1] return!!!
[ 30.653043] 7981@C12L1,rt28xx_ap_ioctl() 833: interface is down, cmd [8be1] return!!!
[ 30.681430] 7981@C12L1,rt28xx_ap_ioctl() 833: interface is down, cmd [8be1] return!!!
[ 30.689738] 7981@C12L1,rt28xx_ap_ioctl() 833: interface is down, cmd [8be1] return!!!
H3C_MESH_DEBUG: mediatek,mt7981-spim-snand-rfb
[ 30.701730] 7981@C12L1,rt28xx_ap_ioctl() 833: interface is down, cmd [8be1] return!!!
[ 30.724205] 7981@C12L1,rt28xx_ap_ioctl() 833: interface is down, cmd [8be1] return!!!
[ 30.733337] 7981@C12L1,rt28xx_ap_ioctl() 833: interface is down, cmd [8be1] return!!!
[ 30.743136] 7981@C12L1,rt28xx_ap_ioctl() 833: interface is down, cmd [8be1] return!!!
mapdrestart touch /etc/config/map_network
mapdrestart update map network
update map network
[ 30.878151] mt7530 mdio-bus:1f lan2: Link is Up - 1Gbps/Full - flow control off
[ 30.885573] br-lan: port 2(lan2) entered blocking state
[ 30.890840] br-lan: port 2(lan2) entered forwarding state
[ 31.090888] 7981@C14L1,set_wapp_param() 3528: Unknown Parameter:8
[ 31.105110] 7981@C14L1,set_wapp_param() 3528: Unknown Parameter:0
[ 31.116541] 7981@C14L1,set_wapp_param() 3528: Unknown Parameter:1
[ 31.128458] 7981@C14L1,set_wapp_param() 3528: Unknown Parameter:2
[ 31.136827] 7981@C14L1,set_wapp_param() 3528: Unknown Parameter:3
[ 31.147485] Per-port-per-queue mode is going to be enabled!
[ 31.152140] 7981@C12L1,Set_AP_VENDOR_SPECIFIC_IE() 3776: Unknown OUIType = 16
[ 31.153102] PPPQ use qid 0~5 (scheduler 0).
[ 31.160424] 7981@C12L1,Set_AP_VENDOR_SPECIFIC_IE() 3776: Unknown OUIType = 9
[ 31.176152] 7981@C12L1,set_wapp_cmm_ie() 3672: Unknown IE(EID = 111)
[ 31.182945] 7981@C12L1,set_wapp_cmm_ie() 3672: Unknown IE(EID = 110)
[ 31.213705] Set_Fh_Bss_Proc rax0 wdev->MAPCfg.DevOwnRole 0x0
[ 31.235674] Set_Fh_Bss_Proc rax0 wdev->MAPCfg.DevOwnRole 0x20
[ 31.253133] Set_Fh_Bss_Proc ra0 wdev->MAPCfg.DevOwnRole 0x0
[ 31.271830] Set_Fh_Bss_Proc ra0 wdev->MAPCfg.DevOwnRole 0x20
[ 31.294096] Set_Fh_Bss_Proc ra1 wdev->MAPCfg.DevOwnRole 0x0
[ 31.313371] Set_Fh_Bss_Proc ra1 wdev->MAPCfg.DevOwnRole 0x20
[ 31.351485] br-lan: port 6(rax0) entered blocking state
[ 31.356840] br-lan: port 6(rax0) entered disabled state
[ 31.362398] device rax0 entered promiscuous mode
[ 31.367132] br-lan: port 6(rax0) entered blocking state
[ 31.372396] br-lan: port 6(rax0) entered forwarding state
enable_mtkwifi(band5g,,,)
[ 31.402567] 7981@C08L2,mbss_virtual_if_open() 135: ===> rax1
[ 31.408356] 7981@C01L2,RTMP_COM_IoctlHandle() 1514: -> CMD_RTPRIV_IOCTL_VIRTUAL_INF_INIT
[ 31.416520] 7981@C01L2,RTMP_COM_IoctlHandle() 1491: -> CMD_RTPRIV_IOCTL_VIRTUAL_INF_UP
[ 31.424556] WiFi@C01L3,wifi_sys_open() 856: wdev idx = 7
[ 31.430162] 7981@C18L3,BuildChannelList() 497:
[ 31.434861] 7981@C23L3,operate_loader_phy() 360: oper_cfg: prim_ch(40), ht_bw(1), extcha(3), vht_bw(2), cen_ch_2(0), PhyMode=177!
[ 31.446558] 7981@C23L3,operate_loader_phy() 374: oper_dev after adjust: bw(3), prim_ch(40), cen_ch_1(50), cen_ch_2(0),ext_cha(3)!
[ 31.458227] 7981@C23L3,operate_loader_phy() 393: oper_dev after decision: bw(3), prim_ch(40), cen_ch_1(50), cen_ch_2(0)!
[ 31.469123] 7981@C23L3,DfsGetSysParameters() 1515: Get before pDfsParam->PrimCh(40) band(1) band_bw(3), outbw(0)
[ 31.479323] 7981@C23L3,DfsGetSysParameters() 1561: Get after pDfsParam->PrimCh(40) band(1) band_bw(3), outbw(0)
[ 31.489443] 7981@C08L1,AsicSwitchChannel() 334: AsicSwitchChannel::bandIdx:1 ch_band:1 htbw:1 vht_bw:2 bw:3 extcha:3
[ 31.499980] 7981@C08L1,AsicSwitchChannel() 339: AsicSwitchChannel::primch:40 cench1:50 cench2:0 rxstream:2 ap_bw:0 apCenCh:0 Scan:0
[ 31.511946] 7981@C00L1,mt7981_apply_dpd_flatness_data() 624: eeprom 0x19a bit 0 is 0, do runtime cal
[ 31.521161] 7981@C03L3,MtCmdChannelSwitch() 2541: ctrl_chl=40, ctrl_ch2=0, cent_ch=50 DBDCIdx=1, ChBand=1, BW=3, TXStream=3, RXStream=3, scan(0)
[ 31.545862] 7981@C03L3,MtCmdSetTxRxPath() 2803: ctrl_chl=40, ctrl_ch2=0, cent_ch=50, RxPath=7, BandIdx=1, ChBand=1, BW=3,TXStream=3, RXStream=7, scan(0)
[ 31.566216] 7981@C12L1,EDCCAInit() 22144: EDCCA compensation: uni_compensation=0, bw_compensation=0, final compensation=0
[ 31.577275] 7981@C23L3,DfsCacNormalStart() 3789: [RDM] Normal start. Enable MAC TX
[ 31.584918] 7981@C23L3,DfsGetSysParameters() 1515: Get before pDfsParam->PrimCh(40) band(1) band_bw(3), outbw(0)
[ 31.595120] 7981@C23L3,DfsGetSysParameters() 1561: Get after pDfsParam->PrimCh(40) band(1) band_bw(3), outbw(0)
[ 31.605480] WiFi@C00L2,dump_ht_cap() 29: Caller: wlan_operate_init+0xa4/0x148 [mt_wifi]
[ 31.613523] wdev_attr_update(): wdevId7 = 74:2a:d7:be:c2:21
[ 31.619153] WiFi@C12L1,wifi_sys_open() 907: wifi_sys_open():band1 group_idx[7]=25, bw_grp=16 omac=17
[ 31.628499] 7981@C08L3,hw_ctrl_flow_v2_open() 13: wdev_idx=7
[ 31.639254] 7981@C02L2,AsicRadioOnOffCtrl() 2355: DbdcIdx=1 RadioOn
[ 31.646629] 7981@C00L2,ApAutoChannelAtBootUp() 335: ----------------->
[ 31.655448] 7981@C03L1,MtCmdSetMacTxRx() 10296: (ret = 0)
[ 31.661082] 7981@C03L1,MtCmdSetMacTxRx() 10296: (ret = 0)
[ 31.666517] 7981@C00L1,ApAutoChannelAtBootUp() 497: zero-wait DFS is not enabled
[ 31.673939] 7981@C08L1,ap_run_at_boot() 637: ACS is disable !!
[ 31.680798] 7981@C08L2,APStartUpForMbss() 997: ===>(caller:ap_inf_open+0x140/0x520 [mt_wifi]), mbss_idx:7, CfgMode:0
[ 31.691356] 7981@C15L2,APPMFInit() 133: [PMF] apidx=7, MFPC=0, MFPR=0, SHA256=0
[ 31.698717] 7981@C18L3,BuildChannelList() 497:
[ 31.703825] WiFi@C00L2,dump_ht_cap() 29: Caller: dump_ht_cap+0x10/0x20 [mt_wifi]
[ 31.711524] WiFi@C08L2,ap_link_up() 7190: (caller:wdev_do_linkup+0x20/0x38 [mt_wifi]), wdev(7)
[ 31.720172] 7981@C01L3,wifi_sys_linkup() 1231: wdev idx = 7
[ 31.795869] 7981@C00L3,wtc_acquire_groupkey_wcid() 84: Found a non-occupied wtbl_idx:284 for WDEV_TYPE:1
[ 31.795869] LinkToOmacIdx = 11, LinkToWdevType = 1
[ 31.811031] 7981@C08L3,hw_ctrl_flow_v2_link_up() 72: wdev_idx=7
[ 31.825339] 7981@C08L3,UpdateBeaconHandler() 1928: BCN_UPDATE_INIT, OmacIdx = 11 (rax1)
[ 31.991986] PrintSrCmd:
[ 31.991986] u1CmdSubId = 1, u1ArgNum = 0, u1DbdcIdx = 1, u1Status = 0
[ 31.991986] u1DropTaIdx = 0, u1StaIdx = 0, u4Value = 0
[ 32.006184] PrintSrCmd:
[ 32.006184] u1CmdSubId = 5, u1ArgNum = 0, u1DbdcIdx = 1, u1Status = 0
[ 32.006184] u1DropTaIdx = 0, u1StaIdx = 0, u4Value = 0
[ 32.020363] PrintSrCmd:
[ 32.020363] u1CmdSubId = 3, u1ArgNum = 0, u1DbdcIdx = 1, u1Status = 0
[ 32.020363] u1DropTaIdx = 0, u1StaIdx = 0, u4Value = 1
[ 32.034758] PrintSrCmd:
[ 32.034758] u1CmdSubId = 23, u1ArgNum = 0, u1DbdcIdx = 1, u1Status = 0
[ 32.034758] u1DropTaIdx = 0, u1StaIdx = 0, u4Value = 0
[ 32.048904] BcnCheck start after 2800 ms (ra0)
[ 32.055748] PrintSrCmd:
[ 32.055748] u1CmdSubId = 31, u1ArgNum = 0, u1DbdcIdx = 1, u1Status = 0
[ 32.055748] u1DropTaIdx = 0, u1StaIdx = 0, u4Value = 0
[ 32.070022] PrintSrCmd:
[ 32.070022] u1CmdSubId = 33, u1ArgNum = 0, u1DbdcIdx = 1, u1Status = 0
[ 32.070022] u1DropTaIdx = 0, u1StaIdx = 0, u4Value = 0
[ 32.084195] 7981@C12L1,EDCCAInit() 22144: EDCCA compensation: uni_compensation=0, bw_compensation=0, final compensation=0
[ 32.095189] 7981@C03L3,MtCmdTxPwrShowInfo() 13800: ucTxPowerInfoCatg: 2, BandIdx: 1
[ 32.102974] 7981@C03L3,MtCmdTxPwrShowInfo() 13829: (ret = 0)
[ 32.103078] [mtf_txpower_all_rate_info] band_idx:1 pwr:48 ChBand:5G ePAGain:0
[ 32.108649] mtk_ppe_dev_register_hook : ineterface rax1 register (4)
[ 32.128485] br-lan: port 7(rax1) entered blocking state
[ 32.133752] br-lan: port 7(rax1) entered disabled state
[ 32.139228] device rax1 entered promiscuous mode
[ 32.143981] br-lan: port 7(rax1) entered blocking state
[ 32.149233] br-lan: port 7(rax1) entered forwarding state
[ 32.171155] 7981@C08L2,mbss_virtual_if_open() 135: ===> rax2
[ 32.176947] 7981@C01L2,RTMP_COM_IoctlHandle() 1514: -> CMD_RTPRIV_IOCTL_VIRTUAL_INF_INIT
[ 32.185075] 7981@C01L2,RTMP_COM_IoctlHandle() 1491: -> CMD_RTPRIV_IOCTL_VIRTUAL_INF_UP
[ 32.193114] WiFi@C01L3,wifi_sys_open() 856: wdev idx = 8
[ 32.198745] 7981@C18L3,BuildChannelList() 497:
[ 32.203338] 7981@C23L3,operate_loader_phy() 360: oper_cfg: prim_ch(40), ht_bw(1), extcha(3), vht_bw(2), cen_ch_2(0), PhyMode=177!
[ 32.215043] 7981@C23L3,operate_loader_phy() 374: oper_dev after adjust: bw(3), prim_ch(40), cen_ch_1(50), cen_ch_2(0),ext_cha(3)!
[ 32.226715] 7981@C23L3,operate_loader_phy() 393: oper_dev after decision: bw(3), prim_ch(40), cen_ch_1(50), cen_ch_2(0)!
[ 32.237602] 7981@C23L3,DfsGetSysParameters() 1515: Get before pDfsParam->PrimCh(40) band(1) band_bw(3), outbw(0)
[ 32.247786] 7981@C23L3,DfsGetSysParameters() 1561: Get after pDfsParam->PrimCh(40) band(1) band_bw(3), outbw(0)
[ 32.257904] 7981@C08L1,AsicSwitchChannel() 334: AsicSwitchChannel::bandIdx:1 ch_band:1 htbw:1 vht_bw:2 bw:3 extcha:3
[ 32.268443] 7981@C08L1,AsicSwitchChannel() 339: AsicSwitchChannel::primch:40 cench1:50 cench2:0 rxstream:2 ap_bw:0 apCenCh:0 Scan:0
[ 32.280400] 7981@C00L1,mt7981_apply_dpd_flatness_data() 624: eeprom 0x19a bit 0 is 0, do runtime cal
[ 32.289627] 7981@C03L3,MtCmdChannelSwitch() 2541: ctrl_chl=40, ctrl_ch2=0, cent_ch=50 DBDCIdx=1, ChBand=1, BW=3, TXStream=3, RXStream=3, scan(0)
[ 32.312425] 7981@C03L3,MtCmdSetTxRxPath() 2803: ctrl_chl=40, ctrl_ch2=0, cent_ch=50, RxPath=7, BandIdx=1, ChBand=1, BW=3,TXStream=3, RXStream=7, scan(0)
[ 32.331397] 7981@C12L1,EDCCAInit() 22144: EDCCA compensation: uni_compensation=0, bw_compensation=0, final compensation=0
[ 32.342640] 7981@C23L3,DfsCacNormalStart() 3789: [RDM] Normal start. Enable MAC TX
[ 32.350467] 7981@C23L3,DfsGetSysParameters() 1515: Get before pDfsParam->PrimCh(40) band(1) band_bw(3), outbw(0)
[ 32.360726] 7981@C23L3,DfsGetSysParameters() 1561: Get after pDfsParam->PrimCh(40) band(1) band_bw(3), outbw(0)
[ 32.371034] WiFi@C00L2,dump_ht_cap() 29: Caller: wlan_operate_init+0xa4/0x148 [mt_wifi]
[ 32.379048] wdev_attr_update(): wdevId8 = 78:2a:d7:be:c2:21
[ 32.384707] WiFi@C12L1,wifi_sys_open() 907: wifi_sys_open():band1 group_idx[8]=26, bw_grp=16 omac=18
[ 32.393880] 7981@C08L3,hw_ctrl_flow_v2_open() 13: wdev_idx=8
[ 32.403021] 7981@C02L2,AsicRadioOnOffCtrl() 2355: DbdcIdx=1 RadioOn
[ 32.410019] 7981@C00L2,ApAutoChannelAtBootUp() 335: ----------------->
[ 32.417840] 7981@C03L1,MtCmdSetMacTxRx() 10296: (ret = 0)
[ 32.423944] 7981@C03L1,MtCmdSetMacTxRx() 10296: (ret = 0)
[ 32.429383] 7981@C00L1,ApAutoChannelAtBootUp() 497: zero-wait DFS is not enabled
[ 32.436821] 7981@C08L1,ap_run_at_boot() 637: ACS is disable !!
[ 32.443935] 7981@C08L2,APStartUpForMbss() 997: ===>(caller:ap_inf_open+0x140/0x520 [mt_wifi]), mbss_idx:8, CfgMode:0
[ 32.454503] 7981@C15L2,APPMFInit() 133: [PMF] apidx=8, MFPC=0, MFPR=0, SHA256=0
[ 32.461880] 7981@C18L3,BuildChannelList() 497:
[ 32.466926] WiFi@C00L2,dump_ht_cap() 29: Caller: dump_ht_cap+0x10/0x20 [mt_wifi]
[ 32.474884] WiFi@C08L2,ap_link_up() 7190: (caller:wdev_do_linkup+0x20/0x38 [mt_wifi]), wdev(8)
[ 32.483556] 7981@C01L3,wifi_sys_linkup() 1231: wdev idx = 8
[ 32.559343] 7981@C00L3,wtc_acquire_groupkey_wcid() 84: Found a non-occupied wtbl_idx:283 for WDEV_TYPE:1
[ 32.559343] LinkToOmacIdx = 12, LinkToWdevType = 1
[ 32.574308] 7981@C08L3,hw_ctrl_flow_v2_link_up() 72: wdev_idx=8
[ 32.589611] 7981@C08L3,UpdateBeaconHandler() 1928: BCN_UPDATE_INIT, OmacIdx = 12 (rax2)
[main.85]: smartnet start init
[ 32.836933] PrintSrCmd:
[ 32.836933] u1CmdSubId = 1, u1ArgNum = 0, u1DbdcIdx = 1, u1Status = 0
[ 32.836933] u1DropTaIdx = 0, u1StaIdx = 0, u4Value = 0
[ 32.850991] PrintSrCmd:
[ 32.850991] u1CmdSubId = 5, u1ArgNum = 0, u1DbdcIdx = 1, u1Status = 0
[ 32.850991] u1DropTaIdx = 0, u1StaIdx = 0, u4Value = 0
[ 32.865039] PrintSrCmd:
[ 32.865039] u1CmdSubId = 3, u1ArgNum = 0, u1DbdcIdx = 1, u1Status = 0
[ 32.865039] u1DropTaIdx = 0, u1StaIdx = 0, u4Value = 1
[ 32.879081] PrintSrCmd:
[ 32.879081] u1CmdSubId = 23, u1ArgNum = 0, u1DbdcIdx = 1, u1Status = 0
[ 32.879081] u1DropTaIdx = 0, u1StaIdx = 0, u4Value = 0
[ 32.893231] PrintSrCmd:
[ 32.893231] u1CmdSubId = 31, u1ArgNum = 0, u1DbdcIdx = 1, u1Status = 0
[ 32.893231] u1DropTaIdx = 0, u1StaIdx = 0, u4Value = 0
[ 32.907372] PrintSrCmd:
[ 32.907372] u1CmdSubId = 33, u1ArgNum = 0, u1DbdcIdx = 1, u1Status = 0
[ 32.907372] u1DropTaIdx = 0, u1StaIdx = 0, u4Value = 0
[ 32.921537] 7981@C12L1,EDCCAInit() 22144: EDCCA compensation: uni_compensation=0, bw_compensation=0, final compensation=0
[ 32.932563] 7981@C03L3,MtCmdTxPwrShowInfo() 13800: ucTxPowerInfoCatg: 2, BandIdx: 1
[ 32.940368] 7981@C03L3,MtCmdTxPwrShowInfo() 13829: (ret = 0)
[ 32.946085] [mtf_txpower_all_rate_info] band_idx:1 pwr:48 ChBand:5G ePAGain:0
[ 32.953263] mtk_ppe_dev_register_hook : ineterface rax2 register (5)
[ 32.978172] br-lan: port 8(rax2) entered blocking state
[ 32.983455] br-lan: port 8(rax2) entered disabled state
[ 32.988929] device rax2 entered promiscuous mode
[ 32.993678] br-lan: port 8(rax2) entered blocking state
[ 32.998937] br-lan: port 8(rax2) entered forwarding state
enable_mtkwifi(band5g,,,) done
start userfilter
device_band:,ssidindex:
################---post_mtkwifi----################
H3C_MESH_DEBUG: mediatek,mt7981-spim-snand-rfb
H3C_MESH_DEBUG: mediatek,mt7981-spim-snand-rfb
H3C_MESH_DEBUG: H3C EasyMesh Role:post_wifi
[ 33.362180] -->update_qos_map()
[ 34.436848] module exit
H3C_MESH_DEBUG: H3C EasyMesh Clean
H3C_MESH_DEBUG: get_switch_arch
H3C_MESH_DEBUG: get bit 4 - bit 7: [2]
H3C_MESH_DEBUG: SWITCH_ARCH is DSA
[ 34.647886] BcnCheck start after 300 ms (ra0)
H3C_MESH_DEBUG: No card
H3C_MESH_DEBUG: No card
H3C_MESH_DEBUG: prepare_ifname_ lan_iface :lan1 lan2 lan3
H3C_MESH_DEBUG: No card
H3C_MESH_DEBUG: No card
H3C_MESH_DEBUG: is6G 0 card_wireless_num 17 isAX7800 0 active_cards 2
H3C_MESH_DEBUG: prepare_mapd_config
H3C_MESH_DEBUG: Make mapd_strng.conf
H3C_MESH_DEBUG: prepare 1905 config
[ 35.155270] Set_MapR2_Proc MAP R2 is already disabled
H3C_MESH_DEBUG: disable_R2_conf[ 35.162019] Set_MapTS_Proc MAP TS is already disabled
ig
[ 35.175008] Set_MapR2_Proc MAP R2 is already disabled
[ 35.181674] Set_MapTS_Proc MAP TS is already disabled
H3C_MESH_DEBUG: disable_R3_config
[ 35.194987] Set_Enable_Dpp_Proc DPP is already disabled
[ 35.201722] Set_MapTS_Proc MAP TS is already disabled
[ 35.214023] Set_Enable_Dpp_Proc DPP is already disabled
[ 35.220674] Set_MapTS_Proc MAP TS is already disabled
H3C_MESH_DEBUG: kill fwdd daemon and remove mtfwd module
H3C_MESH_DEBUG: TurnKeyMode
H3C_MESH_DEBUG: Disable QoSR1
[ 36.241393] -->mtfwd_exit()
[ 36.241437] <--mtfwd_exit()
[ 36.264669] Current mapfilter version v3.0.1.2
[ 36.299320] 7981@C01L2,RTMP_COM_IoctlHandle() 1514: -> CMD_RTPRIV_IOCTL_VIRTUAL_INF_INIT
[ 36.307441] 7981@C01L2,RTMP_COM_IoctlHandle() 1491: -> CMD_RTPRIV_IOCTL_VIRTUAL_INF_UP
[ 36.315470] WiFi@C01L3,wifi_sys_open() 856: wdev idx = 13
[ 36.321131] 7981@C18L3,BuildChannelList() 497:
[ 36.325704] 7981@C23L3,operate_loader_phy() 360: oper_cfg: prim_ch(40), ht_bw(1), extcha(3), vht_bw(2), cen_ch_2(0), PhyMode=177!
[ 36.337361] 7981@C23L3,operate_loader_phy() 374: oper_dev after adjust: bw(3), prim_ch(40), cen_ch_1(50), cen_ch_2(0),ext_cha(3)!
[ 36.349013] 7981@C23L3,operate_loader_phy() 393: oper_dev after decision: bw(3), prim_ch(40), cen_ch_1(50), cen_ch_2(0)!
[ 36.359884] 7981@C23L3,DfsGetSysParameters() 1515: Get before pDfsParam->PrimCh(40) band(1) band_bw(3), outbw(0)
[ 36.370054] 7981@C23L3,DfsGetSysParameters() 1561: Get after pDfsParam->PrimCh(40) band(1) band_bw(3), outbw(0)
[ 36.380146] 7981@C08L1,AsicSwitchChannel() 334: AsicSwitchChannel::bandIdx:1 ch_band:1 htbw:1 vht_bw:2 bw:3 extcha:3
[ 36.390662] 7981@C08L1,AsicSwitchChannel() 339: AsicSwitchChannel::primch:40 cench1:50 cench2:0 rxstream:2 ap_bw:0 apCenCh:0 Scan:0
[ 36.402617] 7981@C00L1,mt7981_apply_dpd_flatness_data() 624: eeprom 0x19a bit 0 is 0, do runtime cal
[ 36.411788] 7981@C03L3,MtCmdChannelSwitch() 2541: ctrl_chl=40, ctrl_ch2=0, cent_ch=50 DBDCIdx=1, ChBand=1, BW=3, TXStream=3, RXStream=3, scan(0)
[ 36.429912] 7981@C03L3,MtCmdSetTxRxPath() 2803: ctrl_chl=40, ctrl_ch2=0, cent_ch=50, RxPath=7, BandIdx=1, ChBand=1, BW=3,TXStream=3, RXStream=7, scan(0)
[ 36.448763] 7981@C12L1,EDCCAInit() 22144: EDCCA compensation: uni_compensation=0, bw_compensation=0, final compensation=0
[ 36.459750] 7981@C23L3,DfsCacNormalStart() 3789: [RDM] Normal start. Enable MAC TX
[ 36.467334] 7981@C23L3,DfsGetSysParameters() 1515: Get before pDfsParam->PrimCh(40) band(1) band_bw(3), outbw(0)
[ 36.477522] 7981@C23L3,DfsGetSysParameters() 1561: Get after pDfsParam->PrimCh(40) band(1) band_bw(3), outbw(0)
[ 36.487825] WiFi@C00L2,dump_ht_cap() 29: Caller: wlan_operate_init+0xa4/0x148 [mt_wifi]
[ 36.543475] wdev_attr_update(): wdevId13 = a4:2a:d7:be:c2:21
[ 36.549203] 7981@C08L3,hw_ctrl_flow_v2_open() 13: wdev_idx=13
[ 36.556396] WiFi@C00L2,dump_ht_cap() 29: Caller: dump_ht_cap+0x10/0x20 [mt_wifi]
[ 36.563836] mtk_ppe_dev_register_hook : ineterface apclix0 register (6)
[ 36.572922] br-lan: port 9(apclix0) entered blocking state
[ 36.578429] br-lan: port 9(apclix0) entered disabled state
[ 36.584124] device apclix0 entered promiscuous mode
[ 36.592357] Set_Map_Proc current MAP MODE is 1
[ 36.598276] SetApCliEnableByWdev: I/F(apcli1) (enable = 0)
[ 36.606705] 7981@C01L2,RTMP_COM_IoctlHandle() 1502: -> CMD_RTPRIV_IOCTL_VIRTUAL_INF_DOWN
[ 36.615180] mtwf_dbg_prt: vsnprintf error
[ 36.619225] 7981@C09L3,sync_fsm_reset() 2721: (caller : rt28xx_sta_ioctl+0xadc/0x1ed8 [mt_wifi]) SYNC[apclix0, Band:1]: [IDLE] =========================================> [
[ 36.619507] WiFi@C01L3,wifi_sys_close() 945: wdev idx = 13
[ 36.640581] 7981@C08L3,hw_ctrl_flow_v2_close() 41: wdev_idx=13
[ 36.646701] 7981@C01L2,RTMP_COM_IoctlHandle() 1525: -> CMD_RTPRIV_IOCTL_VIRTUAL_INF_DEINIT
[ 36.654973] extif_put_dev(apclix0)
[ 36.658381] mtk_ppe_dev_unregister_hook : ineterface apclix0 set null (6)
[ 36.665324] br-lan: port 9(apclix0) entered disabled state
[ 36.673255] device apclix0 left promiscuous mode
[ 36.678002] br-lan: port 9(apclix0) entered disabled state
H3C_MESH_DEBUG: MAP version 1.0
[ 37.711681] Set_MapR2_Proc MAP R2 is already disabled
[ 37.718173] Set_MapTS_Proc MAP TS is already disabled
[ 37.728221] Set_MapR2_Proc MAP R2 is already disabled
[ 37.734666] Set_MapTS_Proc MAP TS is already disabled
H3C_MESH_DEBUG: start wapp.
[ 38.752926] 7981@C12L1,rt28xx_ap_ioctl() 833: interface is down, cmd [8be1] return!!!
[ 38.964840] 7981@C14L1,set_wapp_param() 3528: Unknown Parameter:8
[ 38.971001] 7981@C14L1,set_wapp_param() 3528: Unknown Parameter:0
[ 38.977150] 7981@C14L1,set_wapp_param() 3528: Unknown Parameter:1
[ 38.983311] 7981@C14L1,set_wapp_param() 3528: Unknown Parameter:2
[ 38.989462] 7981@C14L1,set_wapp_param() 3528: Unknown Parameter:3
[ 38.995624] 7981@C12L1,Set_AP_VENDOR_SPECIFIC_IE() 3776: Unknown OUIType = 16
[ 39.002777] 7981@C12L1,Set_AP_VENDOR_SPECIFIC_IE() 3776: Unknown OUIType = 9
[ 39.009877] 7981@C12L1,set_wapp_cmm_ie() 3672: Unknown IE(EID = 111)
[ 39.016275] 7981@C12L1,set_wapp_cmm_ie() 3672: Unknown IE(EID = 110)
[ 39.028284] Set_Fh_Bss_Proc ra1 wdev->MAPCfg.DevOwnRole 0x0
[ 39.035845] Set_Fh_Bss_Proc ra1 wdev->MAPCfg.DevOwnRole 0x20
[ 39.044311] Set_Fh_Bss_Proc rax1 wdev->MAPCfg.DevOwnRole 0x0
[ 39.052005] Set_Fh_Bss_Proc rax1 wdev->MAPCfg.DevOwnRole 0x20
[ 39.060586] Set_Fh_Bss_Proc rax2 wdev->MAPCfg.DevOwnRole 0x0
[ 39.068324] Set_Fh_Bss_Proc rax2 wdev->MAPCfg.DevOwnRole 0x20
H3C_MESH_DEBUG: startWAPP 2
H3C_MESH_DEBUG: start wapp ok.
H3C_MESH_DEBUG: StartMapProcess Role is
H3C_MESH_DEBUG: Controller Mode
[ 39.927891] do_map_set_ctl==>cmd(1905)
[ 39.931635] do_map_set_ctl==>almac(70:2a:d7:be:c2:1f)
[ 39.936702] sp update own almac to70:2a:d7:be:c2:1f
[ 39.952420] traffic separation is off
[ 39.992329] handle_ts_default_8021q vid=4095, pcp=0
[ 39.997265] ts policy number=0
[ 41.076065] do_map_set_ctl==>cmd(1905)
[ 41.079810] do_map_set_ctl==>almac(74:2a:d7:be:c2:20)
[ 41.084878] sp update own almac to74:2a:d7:be:c2:20
[ 42.101510] Set_Bh_Bss_Proc ra1 bandIdx = 0 ,DevOwnRole 0x20
[ 42.109287] Set_Fh_Bss_Proc ra1 wdev->MAPCfg.DevOwnRole 0x20
[ 42.117125] Set_Bh_Bss_Proc rax2 bandIdx = 1 ,DevOwnRole 0x20
[ 42.124927] Set_Fh_Bss_Proc rax2 wdev->MAPCfg.DevOwnRole 0x20
[ 42.132829] Set_Bh_Bss_Proc rax1 bandIdx = 1 ,DevOwnRole 0x20
[ 42.140641] Set_Fh_Bss_Proc rax1 wdev->MAPCfg.DevOwnRole 0x20
[ 42.149089] dynamic load balance is off
[ 42.152993] mapfilter: Stop drop the specific ip packets now !!
[ 42.152993]
[ 42.153557] mapfilter: Stop drop the specific ip packets now !!
[ 42.153557]
[ 42.156208] Set_Bh_Bss_Proc ra1 bandIdx = 0 ,DevOwnRole 0x20
H3C_MESH_DEBUG: *** mesh cmd end[ 42.177040] ----->free map device rcu 00000000b00a495e
***
[ 42.177221] Set_Fh_Bss_Proc ra1 wdev->MAPCfg.DevOwnRole 0x20
[ 42.182317] ----->free map device rcu 00000000ecb3f6b2
[ 42.193644] ----->free map device rcu 0000000099940b2c
[ 42.284782] Set_Bh_Bss_Proc rax1 bandIdx = 1 ,DevOwnRole 0x20
[ 42.292982] Set_Fh_Bss_Proc rax1 wdev->MAPCfg.DevOwnRole 0x20
[ 42.312934] Set_Fh_Bss_Proc rax2 wdev->MAPCfg.DevOwnRole 0x0
[ 42.321081] Set_Bh_Bss_Proc rax2 bandIdx = 1 ,DevOwnRole 0x0
[ 42.326844] set_no_bcn(): Set no beacon as:1
[ 42.331260] Set_Bh_Bss_Proc rax2 bandIdx = 1 ,DevOwnRole 0x40
[ 42.338400] MacAddr=0x420d14, MacValue=0x20101, IsRemap=0
[ 42.343958] 7981@C12L2,Set_DisConnectAllSta_Proc() 22697: [PMF]Set_DisConnectAllSta_Proc:: apidx=8
[ 42.409294] set_no_bcn(): Set no beacon as:1
[ 42.416315] MacAddr=0x420d14, MacValue=0x20101, IsRemap=0
[ 44.951865] BcnCheck start after 2500 ms (ra0)
[ 44.956314] BcnCheck start after 2500 ms (ra0)
[ 47.304924] set_no_bcn(): Set no beacon as:1
[ 47.311797] MacAddr=0x420d14, MacValue=0x20101, IsRemap=0
[ 47.323085] SetThermalProtectDisable(): band_idx: 1, protection_type: 1, trigger_type: 1
[ 47.332652] SetThermalProtectDisable(): band_idx: 0, protection_type: 1, trigger_type: 1
F0: 102B 0000
FA: 1040 0000
FA: 1040 0000 [0200]
F9: 0000 0000
V0: 0000 0000 [0001]
00: 0000 0000
BP: 2400 0041 [0000]
G0: 1190 0000
EC: 0000 0000 [1000]
T0: 0000 024B [010F]
Jump to BL
NOTICE: BL2: v2.7(release):
NOTICE: BL2: Built : 19:15:29, Jul 17 2025
NOTICE: WDT: disabled
NOTICE: EMI: Using DDR3 settings
NOTICE: EMI: Detected DRAM size: 256MB
NOTICE: EMI: complex R/W mem test passed
NOTICE: CPU: MT7981 (1300MHz)
NOTICE: SPI_NAND parses attributes from parameter page.
NOTICE: SPI_NAND Detected ID 0xef
NOTICE: Page size 2048, Block size 131072, size 134217728
NOTICE: Initializing NMBM ...
NOTICE: Signature found at block 1023 [0x07fe0000]
NOTICE: First info table with writecount 0 found in block 960
NOTICE: Second info table with writecount 0 found in block 963
NOTICE: NMBM has been successfully attached in read-only mode
NOTICE: BL2: Booting BL31
INFO: Total CPU count: 2
INFO: MCUSYS: L2C share 256K --> 0K
INFO: Disable NETSYS SRAM remapping
INFO: SPMC: Changed to SPMC mode
NOTICE: BL31: v2.10.0 (release):20240123-47-g93101f0b
NOTICE: BL31: Built : 19:00:38, Sep 15 2024
INFO: GICv3 without legacy support detected.
INFO: ARM GICv3 driver initialized in EL3
INFO: Maximum SPI INTID supported: 671
INFO: BL31: Initializing runtime services
INFO: Secondary bootloader is AArch64
INFO: BL31: Preparing for EL3 exit to normal world
INFO: Entry point address = 0x41e00000
INFO: SPSR = 0x3c9
U-Boot 2022.07 (Sep 15 2024 - 19:00:33 +0800)
CPU: MediaTek MT7981
Model: mt7981-h3c_magic-nx30-pro
DRAM: 256 MiB
Core: 27 devices, 15 uclasses, devicetree: embed
Loading Environment from UBI... spi-nand: spi_nand spi_nand@0: Winbond SPI NAND was found.
spi-nand: spi_nand spi_nand@0: 128 MiB, block size: 128 KiB, page size: 2048, OOB size: 64
Read 126976 bytes from volume ubootenv to 000000004f7c1c80
Read 126976 bytes from volume ubootenv2 to 000000004f7e0cc0
OK
In: serial@11002000
Out: serial@11002000
Err: serial@11002000
Net: eth0: ethernet@15100000
RESET button is pressed for: 3 second(s)
Web failsafe UI started
URL: http://192.168.1.1/
Press Ctrl+C to exit
GET /
GET /style.css
GET /index.js
GET /version
GET /getmtdlayout
POST /upload
Content-Length: 61473062
GET /flashing.html
GET /style.css
GET /index.js
GET /version
GET /result
GET /undefined
Erasing from 0x0 to 0x3a9ffff, size 0x3aa0000 ... OK
Writing from 0x460000e8 to 0x0, size 0x3aa0000 ... OK
Verifying from 0x0 to 0x3a9ffff, size 0x3aa0000 ... OK
resetting ...
F0: 102B 0000
FA: 1040 0000
FA: 1040 0000 [0200]
F9: 0000 0000
V0: 0000 0000 [0001]
00: 0000 0000
BP: 2400 0041 [0000]
G0: 1190 0000
EC: 0000 0000 [1000]
T0: 0000 024B [010F]
Jump to BL
NOTICE: BL2: v2.7(release):
NOTICE: BL2: Built : 19:15:29, Jul 17 2025
NOTICE: WDT: disabled
NOTICE: EMI: Using DDR3 settings
NOTICE: EMI: Detected DRAM size: 256MB
NOTICE: EMI: complex R/W mem test passed
NOTICE: CPU: MT7981 (1300MHz)
NOTICE: SPI_NAND parses attributes from parameter page.
NOTICE: SPI_NAND Detected ID 0xef
NOTICE: Page size 2048, Block size 131072, size 134217728
NOTICE: Initializing NMBM ...
NOTICE: Signature found at block 1023 [0x07fe0000]
NOTICE: First info table with writecount 0 found in block 960
NOTICE: Second info table with writecount 0 found in block 963
NOTICE: NMBM has been successfully attached in read-only mode
NOTICE: BL2: Booting BL31
INFO: Total CPU count: 2
INFO: MCUSYS: L2C share 256K --> 0K
INFO: Disable NETSYS SRAM remapping
INFO: SPMC: Changed to SPMC mode
NOTICE: BL31: v2.10.0 (release):20240123-47-g93101f0b
NOTICE: BL31: Built : 19:00:38, Sep 15 2024
INFO: GICv3 without legacy support detected.
INFO: ARM GICv3 driver initialized in EL3
INFO: Maximum SPI INTID supported: 671
INFO: BL31: Initializing runtime services
INFO: Secondary bootloader is AArch64
INFO: BL31: Preparing for EL3 exit to normal world
INFO: Entry point address = 0x41e00000
INFO: SPSR = 0x3c9
U-Boot 2022.07 (Sep 15 2024 - 19:00:33 +0800)
CPU: MediaTek MT7981
Model: mt7981-h3c_magic-nx30-pro
DRAM: 256 MiB
Core: 27 devices, 15 uclasses, devicetree: embed
Loading Environment from UBI... spi-nand: spi_nand spi_nand@0: Winbond SPI NAND was found.
spi-nand: spi_nand spi_nand@0: 128 MiB, block size: 128 KiB, page size: 2048, OOB size: 64
UBI: EOF marker found, PEBs from 464 will be erased
Volume ubootenv not found!
** Unable to read env from ubi:ubootenv **
Volume ubootenv2 not found!
** Unable to read redundant env from ubi:ubootenv2 **
*** Error - No Valid Environment Area found
*** Warning - bad env area, using default environment
In: serial@11002000
Out: serial@11002000
Err: serial@11002000
Net:
Warning: ethernet@15100000 (eth0) using random MAC address - 82:f4:dd:11:ab:f2
eth0: ethernet@15100000
*** U-Boot Boot Menu ***
1. Startup system (Default)
2. Upgrade firmware
3. Upgrade ATF BL2
4. Upgrade ATF FIP
5. Upgrade single image
6. Load image
0. U-Boot console
Press UP/DOWN to move, ENTER to select, ESC/CTRL+C to quit
Reading from volume 'kernel' to 0x46000000, size 0x0 ... OK
## Loading kernel from FIT Image at 46000000 ...
Using 'config-1' configuration
Trying 'kernel-1' kernel subimage
Description: ARM64 OpenWrt Linux-6.12.71
Type: Kernel Image
Compression: lzma compressed
Data Start: 0x460000e8
Data Size: 4728901 Bytes = 4.5 MiB
Architecture: AArch64
OS: Linux
Load Address: 0x48000000
Entry Point: 0x48000000
Hash algo: crc32
Hash value: ca6afe5f
Hash algo: sha1
Hash value: 5ce53cf8e5b9efa045b03d05317d191e33144a1b
Verifying Hash Integrity ... crc32+ sha1+ OK
## Loading fdt from FIT Image at 46000000 ...
Using 'config-1' configuration
Trying 'fdt-1' fdt subimage
Description: ARM64 OpenWrt h3c_magic-nx30-pro device tree blob
Type: Flat Device Tree
Compression: uncompressed
Data Start: 0x46482a74
Data Size: 22010 Bytes = 21.5 KiB
Architecture: AArch64
Hash algo: crc32
Hash value: ab6276fa
Hash algo: sha1
Hash value: db15d028777f82105be2c4bc1493df5abe73fb3e
Verifying Hash Integrity ... crc32+ sha1+ OK
Booting using the fdt blob at 0x46482a74
Uncompressing Kernel Image
Loading Device Tree to 000000004f7f2000, end 000000004f7fa5f9 ... OK
Starting kernel ...
[ 0.000000] Booting Linux on physical CPU 0x0000000000 [0x410fd034]
[ 0.000000] Linux version 6.12.71 (runner@runnervm0kj6c) (aarch64-openwrt-linux-musl-gcc (OpenWrt GCC 14.3.0 r32713-f919e7899d) 14.3.0, GNU ld (GNU Binutils) 2.44) #0 SMP Fri Mar 6 16:39:03 2026
[ 0.000000] Machine model: H3C Magic NX30 Pro
[ 0.000000] OF: reserved mem: 0x0000000042ff0000..0x0000000042ffffff (64 KiB) map non-reusable ramoops@42ff0000
[ 0.000000] OF: reserved mem: 0x0000000043000000..0x000000004302ffff (192 KiB) nomap non-reusable secmon@43000000
[ 0.000000] OF: reserved mem: 0x0000000047c80000..0x0000000047d7ffff (1024 KiB) nomap non-reusable wmcpu-reserved@47c80000
[ 0.000000] OF: reserved mem: 0x0000000047d80000..0x0000000047dbffff (256 KiB) nomap non-reusable wo-emi@47d80000
[ 0.000000] OF: reserved mem: 0x0000000047dc0000..0x0000000047ffffff (2304 KiB) nomap non-reusable wo-data@47dc0000
[ 0.000000] Zone ranges:
[ 0.000000] DMA [mem 0x0000000040000000-0x000000004fffffff]
[ 0.000000] DMA32 empty
[ 0.000000] Normal empty
[ 0.000000] Movable zone start for each node
[ 0.000000] Early memory node ranges
[ 0.000000] node 0: [mem 0x0000000040000000-0x0000000042ffffff]
[ 0.000000] node 0: [mem 0x0000000043000000-0x000000004302ffff]
[ 0.000000] node 0: [mem 0x0000000043030000-0x0000000047c7ffff]
[ 0.000000] node 0: [mem 0x0000000047c80000-0x0000000047ffffff]
[ 0.000000] node 0: [mem 0x0000000048000000-0x000000004fffffff]
[ 0.000000] Initmem setup node 0 [mem 0x0000000040000000-0x000000004fffffff]
[ 0.000000] psci: probing for conduit method from DT.
[ 0.000000] psci: PSCIv1.1 detected in firmware.
[ 0.000000] psci: Using standard PSCI v0.2 function IDs
[ 0.000000] psci: MIGRATE_INFO_TYPE not supported.
[ 0.000000] psci: SMC Calling Convention v1.4
[ 0.000000] percpu: Embedded 21 pages/cpu s45784 r8192 d32040 u86016
[ 0.000000] pcpu-alloc: s45784 r8192 d32040 u86016 alloc=21*4096
[ 0.000000] pcpu-alloc: [0] 0 [0] 1
[ 0.000000] Detected VIPT I-cache on CPU0
[ 0.000000] CPU features: detected: GIC system register CPU interface
[ 0.000000] CPU features: kernel page table isolation disabled by kernel configuration
[ 0.000000] alternatives: applying boot alternatives
[ 0.000000] Kernel command line:
[ 0.000000] Dentry cache hash table entries: 32768 (order: 6, 262144 bytes, linear)
[ 0.000000] Inode-cache hash table entries: 16384 (order: 5, 131072 bytes, linear)
[ 0.000000] Built 1 zonelists, mobility grouping on. Total pages: 65536
[ 0.000000] mem auto-init: stack:off, heap alloc:off, heap free:off
[ 0.000000] software IO TLB: SWIOTLB bounce buffer size adjusted to 0MB
[ 0.000000] software IO TLB: area num 2.
[ 0.000000] software IO TLB: SWIOTLB bounce buffer size roundup to 0MB
[ 0.000000] software IO TLB: mapped [mem 0x000000004fe4a000-0x000000004feca000] (0MB)
[ 0.000000] SLUB: HWalign=64, Order=0-3, MinObjects=0, CPUs=2, Nodes=1
[ 0.000000] rcu: Hierarchical RCU implementation.
[ 0.000000] rcu: RCU restricting CPUs from NR_CPUS=4 to nr_cpu_ids=2.
[ 0.000000] Tracing variant of Tasks RCU enabled.
[ 0.000000] rcu: RCU calculated value of scheduler-enlistment delay is 10 jiffies.
[ 0.000000] rcu: Adjusting geometry for rcu_fanout_leaf=16, nr_cpu_ids=2
[ 0.000000] RCU Tasks Trace: Setting shift to 1 and lim to 1 rcu_task_cb_adjust=1 rcu_task_cpu_ids=2.
[ 0.000000] NR_IRQS: 64, nr_irqs: 64, preallocated irqs: 0
[ 0.000000] GICv3: GIC: Using split EOI/Deactivate mode
[ 0.000000] GICv3: 640 SPIs implemented
[ 0.000000] GICv3: 0 Extended SPIs implemented
[ 0.000000] Root IRQ handler: gic_handle_irq
[ 0.000000] GICv3: GICv3 features: 16 PPIs
[ 0.000000] GICv3: GICD_CTRL.DS=0, SCR_EL3.FIQ=0
[ 0.000000] GICv3: CPU0: found redistributor 0 region 0:0x000000000c080000
[ 0.000000] rcu: srcu_init: Setting srcu_struct sizes based on contention.
[ 0.000000] arch_timer: cp15 timer(s) running at 13.00MHz (phys).
[ 0.000000] clocksource: arch_sys_counter: mask: 0xffffffffffffff max_cycles: 0x2ff89eacb, max_idle_ns: 440795202429 ns
[ 0.000000] sched_clock: 56 bits at 13MHz, resolution 76ns, wraps every 4398046511101ns
[ 0.000220] Calibrating delay loop (skipped), value calculated using timer frequency.. 26.00 BogoMIPS (lpj=130000)
[ 0.000229] pid_max: default: 32768 minimum: 301
[ 0.003131] Mount-cache hash table entries: 512 (order: 0, 4096 bytes, linear)
[ 0.003139] Mountpoint-cache hash table entries: 512 (order: 0, 4096 bytes, linear)
[ 0.005293] cacheinfo: Unable to detect cache hierarchy for CPU 0
[ 0.006120] rcu: Hierarchical SRCU implementation.
[ 0.006126] rcu: Max phase no-delay instances is 1000.
[ 0.006327] Timer migration: 1 hierarchy levels; 8 children per group; 1 crossnode level
[ 0.006551] smp: Bringing up secondary CPUs ...
[ 0.006937] Detected VIPT I-cache on CPU1
[ 0.006983] GICv3: CPU1: found redistributor 1 region 0:0x000000000c0a0000
[ 0.007012] CPU1: Booted secondary processor 0x0000000001 [0x410fd034]
[ 0.007099] smp: Brought up 1 node, 2 CPUs
[ 0.007104] SMP: Total of 2 processors activated.
[ 0.007107] CPU: All CPU(s) started at EL2
[ 0.007110] CPU features: detected: 32-bit EL0 Support
[ 0.007114] CPU features: detected: CRC32 instructions
[ 0.007140] alternatives: applying system-wide alternatives
[ 0.007278] CPU features: emulated: Privileged Access Never (PAN) using TTBR0_EL1 switching
[ 0.007402] Memory: 235948K/262144K available (9856K kernel code, 1020K rwdata, 2884K rodata, 512K init, 318K bss, 24496K reserved, 0K cma-reserved)
[ 0.010408] clocksource: jiffies: mask: 0xffffffff max_cycles: 0xffffffff, max_idle_ns: 19112604462750000 ns
[ 0.010424] futex hash table entries: 512 (order: 3, 32768 bytes, linear)
[ 0.010482] 29072 pages in range for non-PLT usage
[ 0.010485] 520592 pages in range for PLT usage
[ 0.011966] pinctrl core: initialized pinctrl subsystem
[ 0.014355] NET: Registered PF_NETLINK/PF_ROUTE protocol family
[ 0.014669] DMA: preallocated 128 KiB GFP_KERNEL pool for atomic allocations
[ 0.014695] DMA: preallocated 128 KiB GFP_KERNEL|GFP_DMA pool for atomic allocations
[ 0.014716] DMA: preallocated 128 KiB GFP_KERNEL|GFP_DMA32 pool for atomic allocations
[ 0.015105] thermal_sys: Registered thermal governor 'fair_share'
[ 0.015109] thermal_sys: Registered thermal governor 'bang_bang'
[ 0.015112] thermal_sys: Registered thermal governor 'step_wise'
[ 0.015114] thermal_sys: Registered thermal governor 'user_space'
[ 0.015164] hw-breakpoint: found 6 breakpoint and 4 watchpoint registers.
[ 0.015228] ASID allocator initialised with 65536 entries
[ 0.016155] pstore: Using crash dump compression: deflate
[ 0.016160] pstore: Registered ramoops as persistent store backend
[ 0.016163] ramoops: using 0x10000@0x42ff0000, ecc: 0
[ 0.017601] /soc/interrupt-controller@c000000: Fixed dependency cycle(s) with /soc/interrupt-controller@c000000
[ 0.028721] HugeTLB: registered 1.00 GiB page size, pre-allocated 0 pages
[ 0.028729] HugeTLB: 0 KiB vmemmap can be freed for a 1.00 GiB page
[ 0.028734] HugeTLB: registered 32.0 MiB page size, pre-allocated 0 pages
[ 0.028736] HugeTLB: 0 KiB vmemmap can be freed for a 32.0 MiB page
[ 0.028740] HugeTLB: registered 2.00 MiB page size, pre-allocated 0 pages
[ 0.028743] HugeTLB: 0 KiB vmemmap can be freed for a 2.00 MiB page
[ 0.028747] HugeTLB: registered 64.0 KiB page size, pre-allocated 0 pages
[ 0.028750] HugeTLB: 0 KiB vmemmap can be freed for a 64.0 KiB page
[ 0.034842] cryptd: max_cpu_qlen set to 1000
[ 0.036330] SCSI subsystem initialized
[ 0.036484] libata version 3.00 loaded.
[ 0.038247] clocksource: Switched to clocksource arch_sys_counter
[ 0.040598] NET: Registered PF_INET protocol family
[ 0.040711] IP idents hash table entries: 4096 (order: 3, 32768 bytes, linear)
[ 0.041994] tcp_listen_portaddr_hash hash table entries: 256 (order: 0, 4096 bytes, linear)
[ 0.042009] Table-perturb hash table entries: 65536 (order: 6, 262144 bytes, linear)
[ 0.042019] TCP established hash table entries: 2048 (order: 2, 16384 bytes, linear)
[ 0.042038] TCP bind hash table entries: 2048 (order: 4, 65536 bytes, linear)
[ 0.042093] TCP: Hash tables configured (established 2048 bind 2048)
[ 0.042384] MPTCP token hash table entries: 256 (order: 1, 6144 bytes, linear)
[ 0.042483] UDP hash table entries: 256 (order: 1, 8192 bytes, linear)
[ 0.042499] UDP-Lite hash table entries: 256 (order: 1, 8192 bytes, linear)
[ 0.042683] NET: Registered PF_UNIX/PF_LOCAL protocol family
[ 0.042704] NET: Registered PF_XDP protocol family
[ 0.042713] PCI: CLS 0 bytes, default 64
[ 0.044147] workingset: timestamp_bits=46 max_order=16 bucket_order=0
[ 0.048821] squashfs: version 4.0 (2009/01/31) Phillip Lougher
[ 0.048829] jffs2: version 2.2 (NAND) (SUMMARY) (LZMA) (RTIME) (CMODE_PRIORITY) (c) 2001-2006 Red Hat, Inc.
[ 0.104982] Block layer SCSI generic (bsg) driver version 0.4 loaded (major 251)
[ 0.116217] Serial: 8250/16550 driver, 16 ports, IRQ sharing enabled
[ 0.119779] printk: legacy console [ttyS0] disabled
[ 0.140155] 11002000.serial: ttyS0 at MMIO 0x11002000 (irq = 72, base_baud = 2500000) is a ST16650V2
[ 0.140198] printk: legacy console [ttyS0] enabled
[ 0.975018] random: crng init done
[ 0.981202] loop: module loaded
[ 0.986297] spi-nand spi0.0: Winbond SPI NAND was found.
[ 0.991641] spi-nand spi0.0: 128 MiB, block size: 128 KiB, page size: 2048, OOB size: 64
[ 1.000145] Signature found at block 1023 [0x07fe0000]
[ 1.005275] NMBM management region starts at block 960 [0x07800000]
[ 1.012357] First info table with writecount 0 found in block 960
[ 1.021082] Second info table with writecount 0 found in block 963
[ 1.027270] NMBM has been successfully attached
[ 1.032061] 9 fixed-partitions partitions found on MTD device spi0.0
[ 1.038686] Creating 9 MTD partitions on "spi0.0":
[ 1.043484] 0x000000000000-0x000000100000 : "BL2"
[ 1.049286] 0x000000100000-0x000000180000 : "u-boot-env"
[ 1.055283] 0x000000180000-0x000000380000 : "Factory"
[ 1.061817] 0x000000380000-0x000000580000 : "FIP"
[ 1.067958] 0x000000580000-0x000004580000 : "ubi"
[ 1.107087] ubi0: default fastmap pool size: 25
[ 1.111646] ubi0: default fastmap WL pool size: 12
[ 1.116428] ubi0: attaching mtd4
[ 1.344054] ubi0: scanning is finished
[ 1.352271] ubi0 warning: ubi_eba_init: cannot reserve enough PEBs for bad PEB handling, reserved 18, need 19
[ 1.362678] ubi0: attached mtd4 (name "ubi", size 64 MiB)
[ 1.368081] ubi0: PEB size: 131072 bytes (128 KiB), LEB size: 126976 bytes
[ 1.374966] ubi0: min./max. I/O unit sizes: 2048/2048, sub-page size 2048
[ 1.381750] ubi0: VID header offset: 2048 (aligned 2048), data offset: 4096
[ 1.388705] ubi0: good PEBs: 512, bad PEBs: 0, corrupted PEBs: 0
[ 1.394699] ubi0: user volume: 3, internal volumes: 1, max. volumes count: 128
[ 1.401914] ubi0: max/mean erase counter: 1/0, WL threshold: 4096, image sequence number: 1772815143
[ 1.411037] ubi0: available PEBs: 0, total reserved PEBs: 512, PEBs reserved for bad PEB handling: 18
[ 1.420255] ubi0: background thread "ubi_bgt0d" started, PID 267
[ 1.420952] block ubiblock0_1: created from ubi0:1(rootfs)
[ 1.431746] ubiblock: device ubiblock0_1 (rootfs) set to be root filesystem
[ 1.438812] 0x000004580000-0x000004b80000 : "pdt_data"
[ 1.447470] 0x000004b80000-0x000005180000 : "pdt_data_1"
[ 1.456775] 0x000005180000-0x000005280000 : "exp"
[ 1.462528] 0x000005280000-0x000007800000 : "plugin"
[ 1.609527] mtk_soc_eth 15100000.ethernet: generated random MAC address 20:08:02:00:00:00
[ 1.617713] mtk_soc_eth 15100000.ethernet: generated random MAC address 20:08:02:00:00:00
[ 1.643000] mtk_soc_eth 15100000.ethernet eth0: mediatek frame engine at 0xffffffc081b00000, irq 75
[ 1.652917] mtk_soc_eth 15100000.ethernet eth1: mediatek frame engine at 0xffffffc081b00000, irq 75
[ 1.662870] i2c_dev: i2c /dev entries driver
[ 1.668825] mtk-wdt 1001c000.watchdog: Watchdog enabled (timeout=31 sec, nowayout=0)
[ 1.677815] NET: Registered PF_INET6 protocol family
[ 1.683660] Segment Routing with IPv6
[ 1.687343] In-situ OAM (IOAM) with IPv6
[ 1.691318] NET: Registered PF_PACKET protocol family
[ 1.696384] bridge: filtering via arp/ip/ip6tables is no longer available by default. Update your scripts to load br_netfilter if you need this.
[ 1.709663] 8021q: 802.1Q VLAN Support v1.8
[ 1.785055] mt7530-mdio mdio-bus:1f: configuring for fixed/2500base-x link mode
[ 1.794056] mt7530-mdio mdio-bus:1f: Link is Up - 2.5Gbps/Full - flow control rx/tx
[ 1.803775] mt7530-mdio mdio-bus:1f lan1 (uninitialized): PHY [mt7530-0:00] driver [MediaTek MT7531 PHY] (irq=79)
[ 1.824955] mt7530-mdio mdio-bus:1f lan2 (uninitialized): PHY [mt7530-0:01] driver [MediaTek MT7531 PHY] (irq=80)
[ 1.845949] mt7530-mdio mdio-bus:1f lan3 (uninitialized): PHY [mt7530-0:02] driver [MediaTek MT7531 PHY] (irq=81)
[ 1.857669] mtk_soc_eth 15100000.ethernet eth0: entered promiscuous mode
[ 1.864423] DSA: tree 0 setup
[ 1.867677] clk: Disabling unused clocks
[ 1.871884] PM: genpd: Disabling unused power domains
[ 1.881340] VFS: Mounted root (squashfs filesystem) readonly on device 254:0.
[ 1.888706] Freeing unused kernel memory: 512K
[ 1.893187] Run /sbin/init as init process
[ 1.897272] with arguments:
[ 1.900245] /sbin/init
[ 1.902940] with environment:
[ 1.906068] HOME=/
[ 1.908421] TERM=linux
[ 2.095802] init: Console is alive
[ 2.099372] init: - watchdog -
[ 2.584729] kmodloader: loading kernel modules from /etc/modules-boot.d/*
[ 2.610210] gpio_button_hotplug: loading out-of-tree module taints kernel.
[ 2.620504] kmodloader: done loading kernel modules from /etc/modules-boot.d/*
[ 2.638033] init: - preinit -
[ 3.148415] mtk_soc_eth 15100000.ethernet eth0: configuring for fixed/2500base-x link mode
[ 3.156877] mtk_soc_eth 15100000.ethernet eth0: Link is Up - 2.5Gbps/Full - flow control rx/tx
[ 3.186127] mt7530-mdio mdio-bus:1f lan1: configuring for phy/gmii link mode
Press the [f] key and hit [enter] to enter failsafe mode
Press the [1], [2], [3] or [4] key and hit [enter] to select the debug level
[ 7.398726] mount_root: loading kmods from internal overlay
[ 7.413806] kmodloader: loading kernel modules from //etc/modules-boot.d/*
[ 7.423192] kmodloader: done loading kernel modules from //etc/modules-boot.d/*
[ 7.556734] block: attempting to load /tmp/overlay/upper/etc/config/fstab
[ 7.564999] block: unable to load configuration (fstab: Entry not found)
[ 7.571814] block: attempting to load /tmp/overlay/etc/config/fstab
[ 7.578142] block: unable to load configuration (fstab: Entry not found)
[ 7.584900] block: attempting to load /etc/config/fstab
[ 7.593116] block: unable to load configuration (fstab: Entry not found)
[ 7.600148] block: no usable configuration
[ 7.613134] UBIFS (ubi0:2): default file-system created
[ 7.618748] UBIFS (ubi0:2): Mounting in unauthenticated mode
[ 7.624501] UBIFS (ubi0:2): background thread "ubifs_bgt0_2" started, PID 777
[ 7.659048] UBIFS (ubi0:2): UBIFS: mounted UBI device 0, volume 2, name "rootfs_data"
[ 7.666879] UBIFS (ubi0:2): LEB size: 126976 bytes (124 KiB), min./max. I/O unit sizes: 2048 bytes/2048 bytes
[ 7.676805] UBIFS (ubi0:2): FS size: 2031616 bytes (1 MiB, 16 LEBs), max 26 LEBs, journal size 1015809 bytes (0 MiB, 6 LEBs)
[ 7.688019] UBIFS (ubi0:2): reserved for root: 95957 bytes (93 KiB)
[ 7.694282] UBIFS (ubi0:2): media format: w5/r0 (latest is w5/r0), UUID FDD9666D-5BB5-444F-98A6-514328F0F870, small LPT model
[ 7.706174] block: attempting to load /tmp/ubifs_cfg/upper/etc/config/fstab
[ 7.713331] block: unable to load configuration (fstab: Entry not found)
[ 7.720098] block: attempting to load /tmp/ubifs_cfg/etc/config/fstab
[ 7.726598] block: unable to load configuration (fstab: Entry not found)
[ 7.733353] block: attempting to load /etc/config/fstab
[ 7.738650] block: unable to load configuration (fstab: Entry not found)
[ 7.745376] block: no usable configuration
[ 7.751917] UBIFS (ubi0:2): un-mount UBI device 0
[ 7.756634] UBIFS (ubi0:2): background thread "ubifs_bgt0_2" stops
[ 7.765836] UBIFS (ubi0:2): Mounting in unauthenticated mode
[ 7.771640] UBIFS (ubi0:2): background thread "ubifs_bgt0_2" started, PID 780
[ 7.806081] UBIFS (ubi0:2): UBIFS: mounted UBI device 0, volume 2, name "rootfs_data"
[ 7.813943] UBIFS (ubi0:2): LEB size: 126976 bytes (124 KiB), min./max. I/O unit sizes: 2048 bytes/2048 bytes
[ 7.823850] UBIFS (ubi0:2): FS size: 2031616 bytes (1 MiB, 16 LEBs), max 26 LEBs, journal size 1015809 bytes (0 MiB, 6 LEBs)
[ 7.835060] UBIFS (ubi0:2): reserved for root: 95957 bytes (93 KiB)
[ 7.841320] UBIFS (ubi0:2): media format: w5/r0 (latest is w5/r0), UUID FDD9666D-5BB5-444F-98A6-514328F0F870, small LPT model
[ 7.899480] block: attempting to load /tmp/overlay/upper/etc/config/fstab
[ 7.906352] block: unable to load configuration (fstab: Entry not found)
[ 7.913119] block: attempting to load /tmp/overlay/etc/config/fstab
[ 7.919466] block: unable to load configuration (fstab: Entry not found)
[ 7.926198] block: attempting to load /etc/config/fstab
[ 7.931505] block: unable to load configuration (fstab: Entry not found)
[ 7.938246] block: no usable configuration
[ 7.944013] block: attempting to load /tmp/ubifs_cfg/upper/etc/config/fstab
[ 7.951102] block: unable to load configuration (fstab: Entry not found)
[ 7.957835] block: attempting to load /tmp/ubifs_cfg/etc/config/fstab
[ 7.964342] block: unable to load configuration (fstab: Entry not found)
[ 7.971083] block: attempting to load /etc/config/fstab
[ 7.976362] block: unable to load configuration (fstab: Entry not found)
[ 7.983102] block: no usable configuration
[ 7.988564] mount_root: overlay filesystem has not been fully initialized yet
[ 7.995961] mount_root: switching to ubifs overlay
[ 8.007535] overlayfs: null uuid detected in lower fs '/', falling back to xino=off,index=off,nfs_export=off.
[ 8.019381] urandom-seed: Seed file not found (/etc/urandom.seed)
[ 8.057277] procd: - early -
[ 8.060279] procd: - watchdog -
[ 8.615527] procd: - watchdog -
[ 8.633713] procd: - ubus -
[ 8.797156] procd: - init -
Please press Enter to activate this console.
[ 9.358908] kmodloader: loading kernel modules from /etc/modules.d/*
[ 9.390960] urngd: v1.0.2 started.
[ 9.559419] NET: Registered PF_ALG protocol family
[ 9.579610] zram: Added device: zram0
[ 9.604737] tun: Universal TUN/TAP device driver, 1.6
[ 9.661480] crypto-safexcel 10320000.crypto: EIP97:230(0,1,4,4)-HIA:270(0,5,5),PE:150/433(alg:7fcdfc00)/0/0/0
[ 9.693893] Loading modules backported from Linux version v6.18.7-0-g5dfbc5357
[ 9.701157] Backport generated by backports.git c8a37ce
[ 9.750834] xt_time: kernel timezone is -0000
[ 10.223616] mt798x-wmac 18000000.wifi: HW/SW Version: 0x8a108a10, Build Time: 20240823161240a
[ 10.223616]
[ 10.545665] mt798x-wmac 18000000.wifi: WM Firmware Version: ____000000, Build Time: 20240823161304
[ 10.679229] mt798x-wmac 18000000.wifi: WA Firmware Version: DEV_000000, Build Time: 20240823161841
[ 10.776886] mt798x-wmac 18000000.wifi: registering led 'mt76-phy0'
[ 10.840297] mt798x-wmac 18000000.wifi: registering led 'mt76-phy1'
[ 10.933447] PPP generic driver version 2.4.2
[ 10.939309] PPP MPPE Compression module registered
[ 10.945235] NET: Registered PF_PPPOX protocol family
[ 10.952712] wireguard: WireGuard 1.0.0 loaded. See www.wireguard.com for information.
[ 10.960589] wireguard: Copyright (C) 2015-2019 Jason A. Donenfeld <Jason@zx2c4.com>. All Rights Reserved.
[ 10.973192] kmodloader: done loading kernel modules from /etc/modules.d/*
教程使用openwrt最新版救砖。如果需要恢复原厂系统可以参考刷机教程。
路由器刷机变砖的主要原因可以归结为以下几类：
1、固件不匹配或错误。2、刷机过程中断电或中断。3.、Bootloader损坏。4、第三方固件不稳定或未经验证。5、未正确清除旧配置或NVRAM损坏。6. 硬件问题（如坏块、电源不稳）7、操作失误
如果是硬件问题或者分区错误。不支持TTL救砖，只能返厂或者编程器刷写闪存救砖。
拆机教程，拆下背面的螺丝。仔细看有卡扣，慢慢贴片撬开。机难度比较大，主要是卡扣太多，每根天线都有卡扣。最好是用撬棒。
![图片[1]-h3c nx30pro救砖教程拆机简易操作版openwrt-勇爱设计Netwrok](https://www.getpicion.com/wp-content/uploads/2026/03/image-12-1024x746.png)
![图片[2]-h3c nx30pro救砖教程拆机简易操作版openwrt-勇爱设计Netwrok](https://www.getpicion.com/wp-content/uploads/2026/03/e24780c0d4def69eb20b97c4213aa82d-1024x771.jpg)
![图片[3]-h3c nx30pro救砖教程拆机简易操作版openwrt-勇爱设计Netwrok](https://www.getpicion.com/wp-content/uploads/2026/03/038a27372098c92654e2c1b003463cf3-1024x771.jpg)
![图片[4]-h3c nx30pro救砖教程拆机简易操作版openwrt-勇爱设计Netwrok](https://www.getpicion.com/wp-content/uploads/2026/03/image-13-1024x792.png)
![图片[5]-h3c nx30pro救砖教程拆机简易操作版openwrt-勇爱设计Netwrok](https://www.getpicion.com/wp-content/uploads/2026/03/d35f01192c065f96107a03f85b36ca69-1024x771.jpg)
![图片[6]-h3c nx30pro救砖教程拆机简易操作版openwrt-勇爱设计Netwrok](https://www.getpicion.com/wp-content/uploads/2026/03/image-14-1024x703.png)
![图片[7]-h3c nx30pro救砖教程拆机简易操作版openwrt-勇爱设计Netwrok](https://www.getpicion.com/wp-content/uploads/2026/03/image-15-1024x568.png)
© 版权声明
文章版权归作者所有，未经允许请勿转载。
THE END
暂无评论内容
