救砖启动记录
Format: Log Type - Time(microsec) - Message - Optional Info
Log Type: B - Since Boot(Power On Reset), D - Delta, S - Statistic
S - QC_IMAGE_VERSION_STRING=BOOT.BF.3.3.1-00147
S - IMAGE_VARIANT_STRING=HAACANAZA
S - OEM_IMAGE_VERSION_STRING=CRM
S - Boot Config, 0x000002e5
B - 201 - PBL, Start
B - 2736 - bootable_media_detect_entry, Start
B - 3444 - bootable_media_detect_success, Start
B - 3448 - elf_loader_entry, Start
B - 6117 - auth_hash_seg_entry, Start
B - 6360 - auth_hash_seg_exit, Start
B - 68590 - elf_segs_hash_verify_entry, Start
B - 131287 - PBL, End
B - 144265 - SBL1, Start
B - 196816 - GCC [RstStat:0x10, RstDbg:0x600000] WDog Stat : 0x4
B - 203374 - pm_device_init, Start
B - 325801 - PM_SET_VAL:Skip
D - 121756 - pm_device_init, Delta
B - 328058 - pm_driver_init, Start
D - 5337 - pm_driver_init, Delta
B - 334493 - clock_init, Start
D - 2135 - clock_init, Delta
B - 338550 - boot_flash_init, Start
D - 12688 - boot_flash_init, Delta
B - 355020 - boot_config_data_table_init, Start
D - 3141 - boot_config_data_table_init, Delta - (575 Bytes)
B - 362462 - Boot Setting : 0x00000618
B - 366488 - CDT version:2,Platform ID:8,Major ID:1,Minor ID:0,Subtype:8
B - 373320 - sbl1_ddr_set_params, Start
B - 377132 - CPR configuration: 0x30c
B - 380579 - cpr_init, Start
B - 383354 - Rail:0 Mode: 5 Voltage: 800000
B - 388570 - CL CPR settled at 752000mV
B - 391406 - Rail:1 Mode: 5 Voltage: 880000
B - 395585 - Rail:1 Mode: 7 Voltage: 896000
D - 16531 - cpr_init, Delta
B - 402478 - Pre_DDR_clock_init, Start
B - 406473 - Pre_DDR_clock_init, End
B - 409767 - DDR Type : PCDDR3
B - 415532 - do ddr sanity test, Start
D - 1067 - do ddr sanity test, Delta
B - 420290 - DDR: Start of HAL DDR Boot Training
B - 425017 - DDR: End of HAL DDR Boot Training
B - 430721 - DDR: Checksum to be stored on flash is -478672533
B - 441121 - Image Load, Start
D - 225273 - QSEE Image Loaded, Delta - (1373936 Bytes)
B - 666486 - Image Load, Start
D - 61 - SEC Image Loaded, Delta - (0 Bytes)
B - 674172 - Image Load, Start
D - 10736 - DEVCFG Image Loaded, Delta - (26004 Bytes)
B - 684999 - Image Load, Start
D - 25285 - RPM Image Loaded, Delta - (105964 Bytes)
B - 710375 - Image Load, Start
D - 102358 - APPSBL Image Loaded, Delta - (627152 Bytes)
B - 812886 - QSEE Execution, Start
D - 61 - QSEE Execution, Delta
B - 818681 - USB D+ check, Start
D - 0 - USB D+ check, Delta
B - 825086 - SBL1, End
D - 683108 -
U-Boot 2016.01 (Mar 13 2020 - 17:34:10 +0800)
version: 0.3.14
DRAM: smem ram ptable found: ver: 1 len: 4
1 GiB
board_devinfo_offset=1060000, board_devinfo_size=20000
board_senv_offset=1040000, board_senv_size=20000
board_kernel_offset=0x1080000, board_fw_size=0x9600000, board_altkernel_offset=0xa680000\nNAND: ONFI device found
ID = 1590acad
Vendor = ad
Device = ac
qpic_nand: changing oobsize to 64 from 128 bytes
SF: Unsupported flash IDs: manuf ff, jedec ffff, ext_jedec ffff
ipq_spi: SPI Flash not found (bus/cs/speed/mode) = (0/0/48000000/0)
512 MiB
MMC: <NULL>: 0
devinfo_import--devinfo_mem_pool.crc=ff0d0154
fun=cmd_init DEVINFO_ITEMS=511
devinfo: data is valid!
read senv success
#### auto_recovery enabled:1, boot_part:1, boot_part_ready:3, boot_count=2
####[boot_count_write] erase:0, auto_recovery->block_offset:0x1040000 offset=0x1041000
Updating boot_count ...
####[boot_count_write] offset:0x1041000 , length:2048
done
PCI Link Intialized
In: serial@78B3000
Out: serial@78B3000
Err: serial@78B3000
machid: 8010008
Card did not respond to voltage select!
eth0 MAC Address from ART is not valid
eth1 MAC Address from ART is not valid
eth2 MAC Address from ART is not valid
eth3 MAC Address from ART is not valid
eth4 MAC Address from ART is not valid
eth5 MAC Address from ART is not valid
auto_recovery_check changes bootcmd: boot from partition 1
Bus 0: i2c@78b6000
Setting bus to 0
Valid chip addresses: 62 68 70
Hit 'Space' or 'Enter' key to stop autoboot: 0
Net:MAC0 addr:0:3:7f:ba:db:ad
PHY ID1: 0x4d
PHY ID2: 0xd0b1
EDMA ver 1 hw init
Num rings - TxDesc:1 (0-0) TxCmpl:1 (7-7)
RxDesc:1 (15-15) RxFill:1 (7-7)
ipq807x_edma_alloc_rings: successfull
ipq807x_edma_setup_ring_resources: successfull
ipq807x_edma_configure_rings: successfull
ipq807x_edma_hw_init: successfull
Disable 50MHz clock...
Erasing NAND...
Erasing at 0x1020000 -- 100% complete.
Writing to NAND... OK
eth0
Warning: eth0 MAC addresses don't match:
Address in SROM is 00:03:7f:ba:db:ad
Address in environment is e8:9f:80:dd:75:1e
IPQ807x#
IPQ807x#
IPQ807x#
IPQ807x#
IPQ807x#
IPQ807x#
IPQ807x#
IPQ807x#
IPQ807x#
IPQ807x#
IPQ807x#
IPQ807x# setenv ipaddr 192.168.1.1
IPQ807x# setenv serverip 192.168.1.10
IPQ807x# tftpboot 0x44000000 immortalwrt-mx5300.itb
ipq807x_eth_halt: done
eth0 PHY0 Down Speed :10 Half duplex
eth0 PHY1 Down Speed :10 Half duplex
eth0 PHY2 up Speed :1000 Full duplex
eth0 PHY3 Down Speed :10 Half duplex
eth0 PHY4 Down Speed :10 Half duplex
10M speed not supported
ipq807x_eth_init: done
Using eth0 device
TFTP from server 192.168.1.10; our IP address is 192.168.1.1
Filename 'immortalwrt-mx5300.itb'.
Load address: 0x44000000
Loading: *
Got TFTP_OACK: TFTP remote port: changes from 69 to 62271
#################################################################
#################################################################
#################################################################
#################################################################
#################################################################
#################################################################
#################################################################
#################################################################
#################################################################
#################################################################
#################################################################
#################################################################
#################################################################
#################################################################
#################################################################
#################################################################
#################################################################
#################################################################
####
2.5 MiB/s
done
Bytes transferred = 17220060 (106c1dc hex)
ipq807x_eth_halt: done
IPQ807x# bootm 0x44000000
## Loading kernel from FIT Image at 44000000 ...
Using 'config@1' configuration
Trying 'kernel-1' kernel subimage
Description: ARM64 OpenWrt Linux-6.6.110
Type: Kernel Image
Compression: gzip compressed
Data Start: 0x440000e8
Data Size: 17170871 Bytes = 16.4 MiB
Architecture: AArch64
OS: Linux
Load Address: 0x41000000
Entry Point: 0x41000000
Hash algo: crc32
Hash value: d8e000e2
Hash algo: sha1
Hash value: 9f3e8626cdf9028c09aa42202fd90504cb65e2ee
Verifying Hash Integrity ... crc32+ sha1+ OK
## Loading fdt from FIT Image at 44000000 ...
Using 'config@1' configuration
Trying 'fdt-1' fdt subimage
Description: ARM64 OpenWrt linksys_mx5300 device tree blob
Type: Flat Device Tree
Compression: uncompressed
Data Start: 0x450603e0
Data Size: 47288 Bytes = 46.2 KiB
Architecture: AArch64
Hash algo: crc32
Hash value: 42a28833
Hash algo: sha1
Hash value: 6078e5cb1acf1b364db1b412897973c6bb954868
Verifying Hash Integrity ... crc32+ sha1+ OK
Booting using the fdt blob at 0x450603e0
Uncompressing Kernel Image ... OK
Loading Device Tree to 4a3f1000, end 4a3ff8b7 ... OK
Using machid 0x8010008 from environment
Starting kernel ...
Jumping to AARCH64 kernel via monitor
[ 0.000000] Booting Linux on physical CPU 0x0000000000 [0x410fd034]
[ 0.000000] Linux version 6.6.110 (buildbot@buildbot.infra.immortalwrt.org) (aarch64-openwrt-linux-musl-gcc (OpenWrt GCC 13.3.0 r33602-e717d133ed6d) 13.3.0, GNU ld (GNU Binutils) 2.42) #0 SMP Mon Oct 27 14:10:17 2025
[ 0.000000] Machine model: Linksys MX5300
[ 0.000000] OF: reserved mem: 0x0000000040000000..0x0000000040ffffff (16384 KiB) nomap non-reusable nss@40000000
[ 0.000000] OF: reserved mem: 0x000000004a400000..0x000000004a5fffff (2048 KiB) nomap non-reusable tzapp@4a400000
[ 0.000000] OF: reserved mem: 0x000000004a600000..0x000000004a9fffff (4096 KiB) nomap non-reusable bootloader@4a600000
[ 0.000000] OF: reserved mem: 0x000000004aa00000..0x000000004aafffff (1024 KiB) nomap non-reusable sbl@4aa00000
[ 0.000000] OF: reserved mem: 0x000000004ab00000..0x000000004abfffff (1024 KiB) nomap non-reusable smem@4ab00000
[ 0.000000] OF: reserved mem: 0x000000004ac00000..0x000000004affffff (4096 KiB) nomap non-reusable memory@4ac00000
[ 0.000000] OF: reserved mem: 0x000000004b000000..0x0000000050efffff (97280 KiB) nomap non-reusable wcnss@4b000000
[ 0.000000] OF: reserved mem: 0x0000000050f00000..0x0000000050ffffff (1024 KiB) nomap non-reusable q6_etr_dump@50f00000
[ 0.000000] OF: reserved mem: 0x0000000051000000..0x00000000510fffff (1024 KiB) nomap non-reusable m3_dump@51000000
[ 0.000000] Zone ranges:
[ 0.000000] DMA [mem 0x0000000040000000-0x000000007fffffff]
[ 0.000000] DMA32 empty
[ 0.000000] Normal empty
[ 0.000000] Movable zone start for each node
[ 0.000000] Early memory node ranges
[ 0.000000] node 0: [mem 0x0000000040000000-0x0000000040ffffff]
[ 0.000000] node 0: [mem 0x0000000041000000-0x000000004a3fffff]
[ 0.000000] node 0: [mem 0x000000004a400000-0x00000000510fffff]
[ 0.000000] node 0: [mem 0x0000000051100000-0x000000007fffffff]
[ 0.000000] Initmem setup node 0 [mem 0x0000000040000000-0x000000007fffffff]
[ 0.000000] psci: probing for conduit method from DT.
[ 0.000000] psci: PSCIv1.0 detected in firmware.
[ 0.000000] psci: Using standard PSCI v0.2 function IDs
[ 0.000000] psci: MIGRATE_INFO_TYPE not supported.
[ 0.000000] psci: SMC Calling Convention v1.0
[ 0.000000] psci: OSI mode supported.
[ 0.000000] psci: [Firmware Bug]: failed to set PC mode: -1
[ 0.000000] percpu: Embedded 18 pages/cpu s36136 r8192 d29400 u73728
[ 0.000000] Detected VIPT I-cache on CPU0
[ 0.000000] alternatives: applying boot alternatives
[ 0.000000] Kernel command line: console=ttyMSM0,115200n8 root=/dev/ubiblock0_0 rootfstype=squashfs ro
[ 0.000000] Dentry cache hash table entries: 131072 (order: 8, 1048576 bytes, linear)
[ 0.000000] Inode-cache hash table entries: 65536 (order: 7, 524288 bytes, linear)
[ 0.000000] Built 1 zonelists, mobility grouping on. Total pages: 258048
[ 0.000000] mem auto-init: stack:off, heap alloc:off, heap free:off
[ 0.000000] software IO TLB: SWIOTLB bounce buffer size adjusted to 1MB
[ 0.000000] software IO TLB: area num 4.
[ 0.000000] software IO TLB: mapped [mem 0x000000007eb00000-0x000000007ec00000] (1MB)
[ 0.000000] Memory: 873600K/1048576K available (8640K kernel code, 922K rwdata, 2580K rodata, 12992K init, 293K bss, 174976K reserved, 0K cma-reserved)
[ 0.000000] SLUB: HWalign=64, Order=0-3, MinObjects=0, CPUs=4, Nodes=1
[ 0.000000] rcu: Hierarchical RCU implementation.
[ 0.000000] Tracing variant of Tasks RCU enabled.
[ 0.000000] rcu: RCU calculated value of scheduler-enlistment delay is 10 jiffies.
[ 0.000000] NR_IRQS: 64, nr_irqs: 64, preallocated irqs: 0
[ 0.000000] Root IRQ handler: gic_handle_irq
[ 0.000000] GICv2m: range[mem 0x0b00a000-0x0b00affc], SPI[448:479]
[ 0.000000] rcu: srcu_init: Setting srcu_struct sizes based on contention.
[ 0.000000] arch_timer: cp15 and mmio timer(s) running at 19.20MHz (virt/virt).
[ 0.000000] clocksource: arch_sys_counter: mask: 0xffffffffffffff max_cycles: 0x46d987e47, max_idle_ns: 440795202767 ns
[ 0.000000] sched_clock: 56 bits at 19MHz, resolution 52ns, wraps every 4398046511078ns
[ 0.000113] Calibrating delay loop (skipped), value calculated using timer frequency.. 38.40 BogoMIPS (lpj=192000)
[ 0.000127] pid_max: default: 32768 minimum: 301
[ 0.005166] Mount-cache hash table entries: 2048 (order: 2, 16384 bytes, linear)
[ 0.005180] Mountpoint-cache hash table entries: 2048 (order: 2, 16384 bytes, linear)
[ 0.009490] RCU Tasks Trace: Setting shift to 2 and lim to 1 rcu_task_cb_adjust=1 rcu_task_cpu_ids=4.
[ 0.009717] rcu: Hierarchical SRCU implementation.
[ 0.009722] rcu: Max phase no-delay instances is 1000.
[ 0.010651] smp: Bringing up secondary CPUs ...
[ 0.011321] Detected VIPT I-cache on CPU1
[ 0.011425] CPU1: Booted secondary processor 0x0000000001 [0x410fd034]
[ 0.012099] Detected VIPT I-cache on CPU2
[ 0.012171] CPU2: Booted secondary processor 0x0000000002 [0x410fd034]
[ 0.012831] Detected VIPT I-cache on CPU3
[ 0.012897] CPU3: Booted secondary processor 0x0000000003 [0x410fd034]
[ 0.012966] smp: Brought up 1 node, 4 CPUs
[ 0.012975] SMP: Total of 4 processors activated.
[ 0.012980] CPU features: detected: 32-bit EL0 Support
[ 0.012984] CPU features: detected: CRC32 instructions
[ 0.013044] CPU features: emulated: Privileged Access Never (PAN) using TTBR0_EL1 switching
[ 0.013050] CPU: All CPU(s) started at EL1
[ 0.013053] alternatives: applying system-wide alternatives
[ 0.024242] clocksource: jiffies: mask: 0xffffffff max_cycles: 0xffffffff, max_idle_ns: 19112604462750000 ns
[ 0.024270] futex hash table entries: 1024 (order: 4, 65536 bytes, linear)
[ 0.026050] pinctrl core: initialized pinctrl subsystem
[ 0.028145] NET: Registered PF_NETLINK/PF_ROUTE protocol family
[ 0.028741] DMA: preallocated 128 KiB GFP_KERNEL pool for atomic allocations
[ 0.028780] DMA: preallocated 128 KiB GFP_KERNEL|GFP_DMA pool for atomic allocations
[ 0.028814] DMA: preallocated 128 KiB GFP_KERNEL|GFP_DMA32 pool for atomic allocations
[ 0.029226] thermal_sys: Registered thermal governor 'step_wise'
[ 0.029287] cpuidle: using governor menu
[ 0.029493] ASID allocator initialised with 65536 entries
[ 0.036817] /soc@0/phy@8e000/phy@8e200: Fixed dependency cycle(s) with /soc@0/gcc@1800000
[ 0.036890] /soc@0/gcc@1800000: Fixed dependency cycle(s) with /soc@0/phy@8e000/phy@8e200
[ 0.037553] /soc@0/phy@8e000: Fixed dependency cycle(s) with /soc@0/gcc@1800000
[ 0.037569] /soc@0/phy@8e000/phy@8e200: Fixed dependency cycle(s) with /soc@0/gcc@1800000
[ 0.039727] /soc@0/phy@8e000/phy@8e200: Fixed dependency cycle(s) with /soc@0/gcc@1800000
[ 0.039797] /soc@0/phy@8e000: Fixed dependency cycle(s) with /soc@0/gcc@1800000
[ 0.039939] /soc@0/gcc@1800000: Fixed dependency cycle(s) with /soc@0/phy@8e000/phy@8e200
[ 0.086719] qcom,cpr4-apss-regulator b018000.cpr4-ctrl: CPR valid fuse count: 4
[ 0.088759] Modules: 26368 pages in range for non-PLT usage
[ 0.088766] Modules: 517888 pages in range for PLT usage
[ 0.092586] SCSI subsystem initialized
[ 0.092817] usbcore: registered new interface driver usbfs
[ 0.092861] usbcore: registered new interface driver hub
[ 0.092912] usbcore: registered new device driver usb
[ 0.093365] qcom_scm: convention: smc arm 64
[ 0.095093] clocksource: Switched to clocksource arch_sys_counter
[ 0.099067] NET: Registered PF_INET protocol family
[ 0.099235] IP idents hash table entries: 16384 (order: 5, 131072 bytes, linear)
[ 0.102144] tcp_listen_portaddr_hash hash table entries: 512 (order: 1, 8192 bytes, linear)
[ 0.102168] Table-perturb hash table entries: 65536 (order: 6, 262144 bytes, linear)
[ 0.102184] TCP established hash table entries: 8192 (order: 4, 65536 bytes, linear)
[ 0.102269] TCP bind hash table entries: 8192 (order: 6, 262144 bytes, linear)
[ 0.102541] TCP: Hash tables configured (established 8192 bind 8192)
[ 0.103052] MPTCP token hash table entries: 1024 (order: 2, 24576 bytes, linear)
[ 0.103237] UDP hash table entries: 512 (order: 2, 16384 bytes, linear)
[ 0.103275] UDP-Lite hash table entries: 512 (order: 2, 16384 bytes, linear)
[ 0.103592] NET: Registered PF_UNIX/PF_LOCAL protocol family
[ 0.103628] PCI: CLS 0 bytes, default 64
[ 0.105220] workingset: timestamp_bits=46 max_order=18 bucket_order=0
[ 0.105969] squashfs: version 4.0 (2009/01/31) Phillip Lougher
[ 0.105977] jffs2: version 2.2 (NAND) (SUMMARY) (LZMA) (RTIME) (CMODE_PRIORITY) (c) 2001-2006 Red Hat, Inc.
[ 0.109915] Block layer SCSI generic (bsg) driver version 0.4 loaded (major 248)
[ 0.115754] qcom-qmp-usb-phy 78000.phy: supply vdda-phy not found, using dummy regulator
[ 0.115953] qcom-qmp-usb-phy 78000.phy: supply vdda-pll not found, using dummy regulator
[ 0.117935] qcom-qusb2-phy 79000.phy: supply vdd not found, using dummy regulator
[ 0.118082] qcom-qusb2-phy 79000.phy: supply vdda-pll not found, using dummy regulator
[ 0.118139] qcom-qusb2-phy 79000.phy: supply vdda-phy-dpdm not found, using dummy regulator
[ 0.118326] qcom-qusb2-phy 79000.phy: Registered Qcom-QUSB2 phy
[ 0.128128] Serial: 8250/16550 driver, 16 ports, IRQ sharing enabled
[ 0.131763] msm_serial 78b3000.serial: msm_serial: detected port #0
[ 0.131808] msm_serial 78b3000.serial: uartclk = 3686400
[ 0.132141] 78b3000.serial: ttyMSM0 at MMIO 0x78b3000 (irq = 20, base_baud = 230400) is a MSM
[ 0.132172] msm_serial: console setup on port #0
[ 0.132213] printk: console [ttyMSM0] enabled
[ 0.135697] qcom-pcie 10000000.pci: host bridge /soc@0/pci@10000000 ranges:
[ 0.137833] msm_serial: driver initialized
[ 0.156811] qcom-pcie 10000000.pci: IO 0x0010200000..0x001020ffff -> 0x0000000000
[ 0.991237] qcom-pcie 10000000.pci: MEM 0x0010220000..0x001fffffff -> 0x0010220000
[ 1.006622] loop: module loaded
[ 1.008493] nand: device found, Manufacturer ID: 0xad, Chip ID: 0xac
[ 1.060559] qcom-pcie 10000000.pci: Read DBI address failed
[ 1.065959] nand: Hynix H27S4G8F2EDA-BC
[ 1.071226] nand: 512 MiB, SLC, erase size: 128 KiB, page size: 2048, OOB size: 128
[ 1.090217] 29 fixed-partitions partitions found on MTD device qcom_nand.0
[ 1.090281] Creating 29 MTD partitions on "qcom_nand.0":
[ 1.096017] 0x000000000000-0x000000100000 : "0:sbl1"
[ 1.103141] 0x000000100000-0x000000200000 : "0:mibib"
[ 1.107936] 0x000000200000-0x000000280000 : "0:bootconfig"
[ 1.112354] 0x000000280000-0x000000300000 : "0:bootconfig1"
[ 1.118190] 0x000000300000-0x000000600000 : "0:qsee"
[ 1.125630] 0x000000600000-0x000000900000 : "0:qsee_1"
[ 1.130797] 0x000000900000-0x000000980000 : "0:devcfg"
[ 1.133383] 0x000000980000-0x000000a00000 : "0:devcfg_1"
[ 1.138540] 0x000000a00000-0x000000a80000 : "0:apdp"
[ 1.143942] 0x000000a80000-0x000000b00000 : "0:apdp_1"
[ 1.148945] 0x000000b00000-0x000000b80000 : "0:rpm"
[ 1.153829] 0x000000b80000-0x000000c00000 : "0:rpm_1"
[ 1.158711] 0x000000c00000-0x000000c80000 : "0:cdt"
[ 1.163882] 0x000000c80000-0x000000d00000 : "0:cdt_1"
[ 1.168533] 0x000000d00000-0x000000d80000 : "0:appsblenv"
[ 1.173737] 0x000000d80000-0x000000e80000 : "0:appsbl"
[ 1.179645] 0x000000e80000-0x000000f80000 : "0:appsbl_1"
[ 1.179768] qcom-pcie 10000000.pci: iATU: unroll F, 32 ob, 8 ib, align 4K, limit 4G
[ 1.184650] 0x000000f80000-0x000001000000 : "0:art"
[ 1.188661] qcom-pcie 10000000.pci: Invalid eDMA IRQs found
[ 1.197451] 0x000001000000-0x000001040000 : "u_env"
[ 1.207248] 0x000001040000-0x000001060000 : "s_env"
[ 1.211914] 0x000001060000-0x000001080000 : "devinfo"
[ 1.216840] 0x000001080000-0x00000a680000 : "kernel"
[ 1.295101] qcom-pcie 10000000.pci: PCIe Gen.2 x1 link up
[ 1.295536] qcom-pcie 10000000.pci: PCI host bridge to bus 0001:00
[ 1.299487] pci_bus 0001:00: root bus resource [bus 00-ff]
[ 1.305608] pci_bus 0001:00: root bus resource [io 0x0000-0xffff]
[ 1.311029] pci_bus 0001:00: root bus resource [mem 0x10220000-0x1fffffff]
[ 1.317236] pci 0001:00:00.0: [17cb:0302] type 01 class 0x060400
[ 1.324060] pci 0001:00:00.0: reg 0x10: [mem 0x00000000-0x00000fff]
[ 1.330280] pci 0001:00:00.0: PME# supported from D0 D3hot D3cold
[ 1.339906] pci 0001:01:00.0: [168c:0046] type 00 class 0x028000
[ 1.342598] pci 0001:01:00.0: reg 0x10: [mem 0x00000000-0x001fffff 64bit]
[ 1.349317] pci 0001:01:00.0: supports D1
[ 1.355219] pci 0001:01:00.0: PME# supported from D0 D1 D3hot D3cold
[ 1.364885] 0x000001680000-0x00000a680000 : "rootfs"
[ 1.385295] pci 0001:00:00.0: BAR 8: assigned [mem 0x10400000-0x105fffff]
[ 1.385334] pci 0001:00:00.0: BAR 0: assigned [mem 0x10220000-0x10220fff]
[ 1.391075] pci 0001:01:00.0: BAR 0: assigned [mem 0x10400000-0x105fffff 64bit]
[ 1.397924] pci 0001:00:00.0: PCI bridge to [bus 01-ff]
[ 1.404953] pci 0001:00:00.0: bridge window [mem 0x10400000-0x105fffff]
[ 1.412976] pcieport 0001:00:00.0: PME: Signaling with IRQ 22
[ 1.417482] pcieport 0001:00:00.0: AER: enabled with IRQ 22
[ 1.500739] mtd: setting mtd22 (rootfs) as root device
[ 1.501109] mtdsplit: no squashfs found in "rootfs"
[ 1.504793] 0x00000a680000-0x000013c80000 : "alt_kernel"
[ 1.651837] 0x00000ac80000-0x000013c80000 : "alt_rootfs"
[ 1.789886] 0x000013c80000-0x000013e80000 : "sysdiag"
[ 1.792300] 0x000013e80000-0x000013f00000 : "0:ethphyfw"
[ 1.794868] 0x000013f00000-0x00001f700000 : "syscfg"
[ 1.974997] 0x00001f700000-0x000020000000 : "0:wififw"
[ 1.994907] spmi spmi-0: PMIC arbiter version v2 (0x20010000)
[ 2.086119] i2c_dev: i2c /dev entries driver
[ 2.093531] sdhci: Secure Digital Host Controller Interface driver
[ 2.093574] sdhci: Copyright(c) Pierre Ossman
[ 2.098660] sdhci-pltfm: SDHCI platform and OF driver helper
[ 2.104914] remoteproc remoteproc0: releasing cd00000.q6v5_wcss
[ 2.111996] NET: Registered PF_INET6 protocol family
[ 2.115390] Segment Routing with IPv6
[ 2.119643] In-situ OAM (IOAM) with IPv6
[ 2.123248] NET: Registered PF_PACKET protocol family
[ 2.127248] bridge: filtering via arp/ip/ip6tables is no longer available by default. Update your scripts to load br_netfilter if you need this.
[ 2.132332] 8021q: 802.1Q VLAN Support v1.8
[ 2.174136] qcom,cpr4-apss-regulator b018000.cpr4-ctrl: CPR valid fuse count: 4
[ 2.174462] cpr4_ipq807x_apss_read_fuse_data: apc_corner: speed bin = 0
[ 2.180293] cpr4_ipq807x_apss_read_fuse_data: apc_corner: CPR fusing revision = 1
[ 2.186894] cpr4_ipq807x_apss_read_fuse_data: apc_corner: CPR misc fuse value = 0
[ 2.194526] cpr4_ipq807x_apss_read_fuse_data: apc_corner: Voltage boost fuse config = 0 boost = disable
[ 2.202068] cpr3_mem_acc_init: apc: not using memory accelerator regulator
[ 2.211194] cpr4_ipq807x_apss_calculate_open_loop_voltages: apc_corner: fused SVS: open-loop= 704000 uV
[ 2.218148] cpr4_ipq807x_apss_calculate_open_loop_voltages: apc_corner: fused NOM: open-loop= 824000 uV
[ 2.228125] cpr4_ipq807x_apss_calculate_open_loop_voltages: apc_corner: fused TURBO: open-loop= 888000 uV
[ 2.237933] cpr4_ipq807x_apss_calculate_open_loop_voltages: apc_corner: fused STURBO: open-loop= 976000 uV
[ 2.247793] cpr4_ipq807x_apss_calculate_target_quotients: apc_corner: fused SVS: quot[ 7]= 720, quot_offset[ 7]= 0
[ 2.257553] cpr4_ipq807x_apss_calculate_target_quotients: apc_corner: fused NOM: quot[ 7]= 946, quot_offset[ 7]= 225
[ 2.268401] cpr4_ipq807x_apss_calculate_target_quotients: apc_corner: fused TURBO: quot[ 7]=1053, quot_offset[ 7]= 105
[ 2.279341] cpr4_ipq807x_apss_calculate_target_quotients: apc_corner: fused STURBO: quot[ 7]=1209, quot_offset[ 7]= 155
[ 2.290490] cpr3_regulator_init_ctrl: apc: Default CPR mode = closed-loop
[ 2.293577] cpufreq: cpufreq_online: CPU0: Running at unlisted initial frequency: 800000 KHz, changing to: 1017600 KHz
[ 2.309833] remoteproc remoteproc0: cd00000.q6v5_wcss is available
[ 2.319014] clk: Disabling unused clocks
[ 2.325168] ------------[ cut here ]------------
[ 2.328781] gcc_usb1_master_clk status stuck at 'on'
[ 2.328807] WARNING: CPU: 0 PID: 1 at drivers/clk/qcom/clk-branch.c:86 clk_branch_wait+0x114/0x124
[ 2.338339] Modules linked in:
[ 2.347097] CPU: 0 PID: 1 Comm: swapper/0 Not tainted 6.6.110 #0
[ 2.350139] Hardware name: Linksys MX5300 (DT)
[ 2.356299] pstate: 604000c5 (nZCv daIF +PAN -UAO -TCO -DIT -SSBS BTYPE=--)
[ 2.360557] pc : clk_branch_wait+0x114/0x124
[ 2.367410] lr : clk_branch_wait+0x114/0x124
[ 2.371922] sp : ffffffc08191bc70
[ 2.376174] x29: ffffffc08191bc70 x28: ffffffc080b100b0 x27: ffffffc080ab8870
[ 2.379393] x26: ffffffc080b022c0 x25: 0000000000000046 x24: ffffffc080b66078
[ 2.386512] x23: ffffffc080a71a58 x22: 0000000000000000 x21: ffffffc08044bda0
[ 2.393630] x20: 0000000000000000 x19: ffffffc081869630 x18: 00000000000000e0
[ 2.400748] x17: ffffffc081872190 x16: ffffffc081872120 x15: ffffffc0817dbeb8
[ 2.407865] x14: 00000000000002a0 x13: 00000000000000e0 x12: 00000000ffffffea
[ 2.414985] x11: 00000000ffffefff x10: ffffffc081833eb8 x9 : ffffffc0817dbe60
[ 2.422103] x8 : 0000000000017fe8 x7 : c0000000ffffefff x6 : 0000000000057fa8
[ 2.429220] x5 : 0000000000000fff x4 : 0000000000000000 x3 : ffffffc08191ba70
[ 2.436337] x2 : ffffffc0817dbdf8 x1 : ffffffc0817dbdf8 x0 : 0000000000000028
[ 2.443456] Call trace:
[ 2.450566] clk_branch_wait+0x114/0x124
[ 2.452825] clk_branch2_disable+0x2c/0x3c
[ 2.456992] clk_disable_unused_subtree+0x98/0xfc
[ 2.460900] clk_disable_unused_subtree+0x2c/0xfc
[ 2.465674] clk_disable_unused_subtree+0x2c/0xfc
[ 2.470361] clk_disable_unused_subtree+0x2c/0xfc
[ 2.475049] clk_disable_unused_subtree+0x2c/0xfc
[ 2.479736] clk_disable_unused+0x64/0x148
[ 2.484422] do_one_initcall+0x6c/0x1fc
[ 2.488414] kernel_init_freeable+0x204/0x2e4
[ 2.492149] kernel_init+0x28/0x1e0
[ 2.496661] ret_from_fork+0x10/0x20
[ 2.499960] ---[ end trace 0000000000000000 ]---
[ 2.504125] ------------[ cut here ]------------
[ 2.508382] gcc_usb0_master_clk status stuck at 'on'
[ 2.508395] WARNING: CPU: 0 PID: 1 at drivers/clk/qcom/clk-branch.c:86 clk_branch_wait+0x114/0x124
[ 2.517939] Modules linked in:
[ 2.526694] CPU: 0 PID: 1 Comm: swapper/0 Tainted: G W 6.6.110 #0
[ 2.529742] Hardware name: Linksys MX5300 (DT)
[ 2.537287] pstate: 604000c5 (nZCv daIF +PAN -UAO -TCO -DIT -SSBS BTYPE=--)
[ 2.541633] pc : clk_branch_wait+0x114/0x124
[ 2.548485] lr : clk_branch_wait+0x114/0x124
[ 2.553000] sp : ffffffc08191bc70
[ 2.557251] x29: ffffffc08191bc70 x28: ffffffc080b100b0 x27: ffffffc080ab8870
[ 2.560469] x26: ffffffc080b022c0 x25: 0000000000000046 x24: ffffffc080b66078
[ 2.567588] x23: ffffffc080a71b10 x22: 0000000000000000 x21: ffffffc08044bda0
[ 2.574707] x20: 0000000000000000 x19: ffffffc0818699b0 x18: 0000000000000102
[ 2.581825] x17: ffffffc081872190 x16: ffffffc081872120 x15: ffffffc0817dbeb8
[ 2.588943] x14: 0000000000000306 x13: 0000000000000102 x12: 00000000ffffffea
[ 2.596060] x11: 00000000ffffefff x10: ffffffc081833eb8 x9 : ffffffc0817dbe60
[ 2.603179] x8 : 0000000000017fe8 x7 : c0000000ffffefff x6 : 0000000000057fa8
[ 2.610296] x5 : 0000000000000fff x4 : 0000000000000000 x3 : ffffffc08191ba70
[ 2.617414] x2 : ffffffc0817dbdf8 x1 : ffffffc0817dbdf8 x0 : 0000000000000028
[ 2.624533] Call trace:
[ 2.631641] clk_branch_wait+0x114/0x124
[ 2.633902] clk_branch2_disable+0x2c/0x3c
[ 2.638067] clk_disable_unused_subtree+0x98/0xfc
[ 2.641976] clk_disable_unused_subtree+0x2c/0xfc
[ 2.646749] clk_disable_unused_subtree+0x2c/0xfc
[ 2.651438] clk_disable_unused_subtree+0x2c/0xfc
[ 2.656125] clk_disable_unused_subtree+0x2c/0xfc
[ 2.660813] clk_disable_unused+0x64/0x148
[ 2.665498] do_one_initcall+0x6c/0x1fc
[ 2.669491] kernel_init_freeable+0x204/0x2e4
[ 2.673226] kernel_init+0x28/0x1e0
[ 2.677736] ret_from_fork+0x10/0x�[ 2.689279] Freeing unused kernel memory: 12992K
[ 2.689384] Run /init as init process
[ 2.894258] init: Console is alive
[ 2.894386] init: - watchdog -
[ 2.902654] kmodloader: loading kernel modules from /etc/modules-boot.d/*
[ 2.919275] gpio_button_hotplug: loading out-of-tree module taints kernel.
[ 2.931914] ssdk_dt_parse_interrupt[941]:INFO:intr-gpio does not exist
[ 3.361271] regi_init[2525]:INFO:Initializing HPPE Done!!
[ 3.361396] regi_init[2574]:INFO:qca-ssdk module init succeeded!
[ 3.367730] EDMA ver 1 hw init
[ 3.371955] EDMA HW Reset completed succesfully
[ 3.374630] Num rings - TxDesc:1 (23-23) TxCmpl:1 (7-7)
[ 3.379052] RxDesc:1 (15-15) RxFill:1 (7-7)
[ 3.384611] dp1: ppe offload disabled: 0 for macid 1
[ 3.388412] dp1: Switch attached to macid 1 status: 0
[ 3.555872] Qualcomm QCA8075 90000.mdio-1:00: attached PHY driver (mii_bus:phy_addr=90000.mdio-1:00, irq=POLL)
[ 3.556771] dp2: ppe offload disabled: 0 for macid 2
[ 3.564778] dp2: Switch attached to macid 2 status: 0
[ 3.655468] Qualcomm QCA8075 90000.mdio-1:01: attached PHY driver (mii_bus:phy_addr=90000.mdio-1:01, irq=POLL)
[ 3.656318] dp3: ppe offload disabled: 0 for macid 3
[ 3.664358] dp3: Switch attached to macid 3 status: 0
[ 3.745463] Qualcomm QCA8075 90000.mdio-1:02: attached PHY driver (mii_bus:phy_addr=90000.mdio-1:02, irq=POLL)
[ 3.746347] dp4: ppe offload disabled: 0 for macid 4
[ 3.754352] dp4: Switch attached to macid 4 status: 0
[ 3.835448] Qualcomm QCA8075 90000.mdio-1:03: attached PHY driver (mii_bus:phy_addr=90000.mdio-1:03, irq=POLL)
[ 3.836340] dp5: ppe offload disabled: 0 for macid 5
[ 3.844337] dp5: Switch attached to macid 5 status: 0
[ 3.925449] Qualcomm QCA8075 90000.mdio-1:04: attached PHY driver (mii_bus:phy_addr=90000.mdio-1:04, irq=POLL)
[ 3.926305] **********************************************************
[ 3.934342] * NSS Data Plane driver
[ 3.940866] **********************************************************
[ 3.956359] xhci-hcd xhci-hcd.1.auto: xHCI Host Controller
[ 3.956411] xhci-hcd xhci-hcd.1.auto: new USB bus registered, assigned bus number 1
[ 3.960873] xhci-hcd xhci-hcd.1.auto: hcc params 0x0220fe65 hci version 0x110 quirks 0x0000008002000010
[ 3.968362] xhci-hcd xhci-hcd.1.auto: irq 40, io mem 0x08a00000
[ 3.977760] xhci-hcd xhci-hcd.1.auto: xHCI Host Controller
[ 3.983576] xhci-hcd xhci-hcd.1.auto: new USB bus registered, assigned bus number 2
[ 3.989139] xhci-hcd xhci-hcd.1.auto: Host supports USB 3.0 SuperSpeed
[ 3.997070] hub 1-0:1.0: USB hub found
[ 4.003296] hub 1-0:1.0: 1 port detected
[ 4.007421] usb usb2: We don't know the algorithms for LPM for this host, disabling LPM.
[ 4.011366] hub 2-0:1.0: USB hub found
[ 4.019263] hub 2-0:1.0: 1 port detected
[ 4.027834] usbcore: registered new interface driver usb-storage
[ 4.029097] usbcore: registered new interface driver uas
[ 4.033199] kmodloader: done loading kernel modules from /etc/modules-boot.d/*
[ 4.048491] init: - preinit -
[ 6.775089] random: crng init done
Cannot parse config file '/etc/fw_env.config': No such file or directory
Failed to find NVMEM device
Press the [f] key and hit [enter] to enter failsafe mode
Press the [1], [2], [3] or [4] key and hit [enter] to select the debug level
[ 11.108333] procd: - early -
[ 11.108424] procd: - watchdog -
[ 11.165867] mtdblock: MTD device 'rootfs' is NAND, please consider using UBI block devices instead.
[ 11.201444] mtdblock: MTD device 'rootfs' is NAND, please consider using UBI block devices instead.
[ 11.235535] mtdblock: MTD device 'rootfs' is NAND, please consider using UBI block devices instead.
[ 11.268057] mtdblock: MTD device 'rootfs' is NAND, please consider using UBI block devices instead.
[ 11.302772] mtdblock: MTD device 'rootfs' is NAND, please consider using UBI block devices instead.
[ 11.338832] mtdblock: MTD device 'rootfs' is NAND, please consider using UBI block devices instead.
[ 11.372910] mtdblock: MTD device 'rootfs' is NAND, please consider using UBI block devices instead.
[ 11.409470] mtdblock: MTD device 'rootfs' is NAND, please consider using UBI block devices instead.
[ 11.445972] mtdblock: MTD device 'rootfs' is NAND, please consider using UBI block devices instead.
[ 11.480567] mtdblock: MTD device 'rootfs' is NAND, please consider using UBI block devices instead.
[ 11.643340] procd: - watchdog -
[ 11.643517] procd: - ubus -
[ 11.796369] procd: - init -
Please press Enter to activate this console.
[ 11.936070] kmodloader: loading kernel modules from /etc/modules.d/*
[ 12.022628] NET: Registered PF_ALG protocol family
[ 12.032730] ntfs3: Enabled Linux POSIX ACLs support
[ 12.034935] Loading modules backported from Linux version v6.12.52-0-g2b2cbdcede38
[ 12.036442] Backport generated by backports.git v6.1.110-1-35-g410656ef
[ 12.051293] NET: Registered PF_QIPCRTR protocol family
[ 12.053535] rtc-ds1307 0-0068: registered as rtc0
[ 12.056093] rtc-ds1307 0-0068: setting system clock to 2026-02-11T09:17:25 UTC (1770801445)
[ 12.064524] usbcore: registered new interface driver ums-alauda
[ 12.070168] usbcore: registered new interface driver ums-cypress
[ 12.075548] usbcore: registered new interface driver ums-datafab
[ 12.081758] usbcore: registered new interface driver ums-freecom
[ 12.088467] usbcore: registered new interface driver ums-isd200
[ 12.093564] urngd: v1.0.2 started.
[ 12.098776] usbcore: registered new interface driver ums-jumpshot
[ 12.102808] usbcore: registered new interface driver ums-karma
[ 12.108887] usbcore: registered new interface driver ums-sddr09
[ 12.114470] usbcore: registered new interface driver ums-sddr55
[ 12.120342] usbcore: registered new interface driver ums-usbat
[ 12.186454] PPP generic driver version 2.4.2
[ 12.187591] PPP MPPE Compression module registered
[ 12.190650] NET: Registered PF_PPPOX protocol family
[ 12.204141] ath10k 6.10 driver, optimized for CT firmware, probing pci device: 0x46.
[ 12.204601] ath10k_pci 0001:01:00.0: enabling device (0000 -> 0002)
[ 12.211722] ath10k_pci 0001:01:00.0: pci irq msi oper_irq_mode 2 irq_mode 0 reset_mode 0
[ 12.890572] ath10k_pci 0001:01:00.0: qca9984/qca9994 hw1.0 target 0x01000000 chip_id 0x00000000 sub 168c:cafe
[ 12.890629] ath10k_pci 0001:01:00.0: kconfig debug 0 debugfs 1 tracing 0 dfs 1 testmode 0
[ 12.900013] ath10k_pci 0001:01:00.0: firmware ver 10.4b-ct-9984-fW-13-5ae337bb1 api 5 features mfp,peer-flow-ctrl,txstatus-noack,wmi-10.x-CT,ratemask-CT,regdump-CT,txrate-CT,flush-all-CT,pingpong-CT,ch-regs-CT,nop-CT,set-special-CT,tx-rc-CT,cust-stats-CT,txrate2-CT,beacon-cb-CT,wmi-block-ack-CT,wmi-bcn-rc-CT crc32 7ea63dc5
[ 15.219201] ath10k_pci 0001:01:00.0: board_file api 2 bmi_id 0:6 crc32 55b5e590
[ 18.730186] ath10k_pci 0001:01:00.0: 10.4 wmi init: vdevs: 16 peers: 48 tid: 96
[ 18.730252] ath10k_pci 0001:01:00.0: msdu-desc: 2500 skid: 32
[ 18.813371] ath10k_pci 0001:01:00.0: wmi print 'P 48/48 V 16 K 144 PH 176 T 186 msdu-desc: 2500 sw-crypt: 0 ct-sta: 0'
[ 18.814175] ath10k_pci 0001:01:00.0: wmi print 'free: 84920 iram: 13156 sram: 11224'
[ 19.102887] ath10k_pci 0001:01:00.0: htt-ver 2.2 wmi-op 6 htt-op 4 cal pre-cal-nvmem max-sta 32 raw 0 hwcrypto 1
[ 19.235597] ath11k c000000.wifi: ipq8074 hw2.0
[ 19.235636] ath11k c000000.wifi: FW memory mode: 0
[ 19.289050] remoteproc remoteproc0: powering up cd00000.q6v5_wcss
[ 19.289163] remoteproc remoteproc0: Booting fw image IPQ8074/q6_fw.mdt, size 668
[ 19.641374] remoteproc remoteproc0: remote processor cd00000.q6v5_wcss is now up
[ 19.685043] ath11k c000000.wifi: qmi ignore invalid mem req type 3
[ 19.692492] ath11k c000000.wifi: chip_id 0x0 chip_family 0x0 board_id 0xff soc_id 0xffffffff
[ 19.692529] ath11k c000000.wifi: fw_version 0x290b84a5 fw_build_timestamp 2024-09-23 11:32 fw_build_id WLAN.HK.2.9.0.1-02146-QCAHKSWPL_SILICONZ-1
[ 22.587505] remoteproc remoteproc0: stopped remote processor cd00000.q6v5_wcss
[ 22.587547] remoteproc remoteproc0: powering up cd00000.q6v5_wcss
[ 22.593691] remoteproc remoteproc0: Booting fw image IPQ8074/q6_fw.mdt, size 668
[ 22.943806] remoteproc remoteproc0: remote processor cd00000.q6v5_wcss is now up
[ 22.946712] kmodloader: done loading kernel modules from /etc/modules.d/*
[ 22.990868] ath11k c000000.wifi: qmi ignore invalid mem req type 3
[ 22.998306] ath11k c000000.wifi: chip_id 0x0 chip_family 0x0 board_id 0xff soc_id 0xffffffff
[ 22.998343] ath11k c000000.wifi: fw_version 0x290b84a5 fw_build_timestamp 2024-09-23 11:32 fw_build_id WLAN.HK.2.9.0.1-02146-QCAHKSWPL_SILICONZ-1
[ 23.296654] ath11k c000000.wifi: htt event 48 not handled
[ 24.929070] mtdblock_open: 27 callbacks suppressed
[ 24.929083] mtdblock: MTD device 'rootfs' is NAND, please consider using UBI block devices instead.
[ 28.005837] br-lan: port 1(lan1) entered blocking state
[ 28.005880] br-lan: port 1(lan1) entered disabled state
[ 28.009920] nss-dp 3a001000.dp1 lan1: entered allmulticast mode
[ 28.015405] nss-dp 3a001000.dp1 lan1: entered promiscuous mode
[ 28.027320] br-lan: port 2(lan2) entered blocking state
[ 28.027365] br-lan: port 2(lan2) entered disabled state
[ 28.032047] nss-dp 3a001200.dp2 lan2: entered allmulticast mode
[ 28.037545] nss-dp 3a001200.dp2 lan2: entered promiscuous mode
[ 28.048388] br-lan: port 3(lan3) entered blocking state
[ 28.049032] br-lan: port 3(lan3) entered disabled state
[ 28.054186] nss-dp 3a001400.dp3 lan3: entered allmulticast mode
[ 28.059663] nss-dp 3a001400.dp3 lan3: entered promiscuous mode
[ 28.069118] br-lan: port 4(lan4) entered blocking state
[ 28.071164] br-lan: port 4(lan4) entered disabled state
[ 28.076409] nss-dp 3a001600.dp4 lan4: entered allmulticast mode
[ 28.081736] nss-dp 3a001600.dp4 lan4: entered promiscuous mode
[ 31.205463] nss-dp 3a001400.dp3 lan3: PHY Link up speed: 1000
[ 33.125155] l11: disabling
[ 35.480499] ath10k_pci 0001:01:00.0: 10.4 wmi init: vdevs: 16 peers: 48 tid: 96
[ 35.480550] ath10k_pci 0001:01:00.0: msdu-desc: 2500 skid: 32
[ 35.563599] ath10k_pci 0001:01:00.0: wmi print 'P 48/48 V 16 K 144 PH 176 T 186 msdu-desc: 2500 sw-crypt: 0 ct-sta: 0'
[ 35.564406] ath10k_pci 0001:01:00.0: wmi print 'free: 84920 iram: 13156 sram: 11224'
[ 35.947963] ath10k_pci 0001:01:00.0: rts threshold -1
[ 35.948218] ath10k_pci 0001:01:00.0: Firmware lacks feature flag indicating a retry limit of > 2 is OK, requested limit: 4
[ 35.952341] br-lan: port 3(lan3) entered blocking state
[ 35.962944] br-lan: port 3(lan3) entered forwarding state
[ 35.969128] br-lan: port 5(phy0-ap0) entered blocking state
[ 35.973617] br-lan: port 5(phy0-ap0) entered disabled state
[ 35.979064] ath10k_pci 0001:01:00.0 phy0-ap0: entered allmulticast mode
[ 35.984719] ath10k_pci 0001:01:00.0 phy0-ap0: entered promiscuous mode
[ 35.992872] ath10k_pci 0001:01:00.0 phy0-ap0: left allmulticast mode
[ 35.997780] ath10k_pci 0001:01:00.0 phy0-ap0: left promiscuous mode
[ 36.004324] br-lan: port 5(phy0-ap0) entered disabled state
[ 36.135497] ath10k_pci 0001:01:00.0: NOTE: Firmware DBGLOG output disabled in debug_mask: 0x10000000
[ 36.135594] ath10k_pci 0001:01:00.0: peer-unmap-event: unknown peer id 0
[ 36.301264] br-lan: port 5(phy2-ap0) entered blocking state
[ 36.301310] br-lan: port 5(phy2-ap0) entered disabled state
[ 36.305735] ath11k c000000.wifi phy2-ap0: entered allmulticast mode
[ 36.311416] ath11k c000000.wifi phy2-ap0: entered promiscuous mode
[ 36.317613] br-lan: port 5(phy2-ap0) entered blocking state
[ 36.323709] br-lan: port 5(phy2-ap0) entered forwarding state
[ 36.498582] br-lan: port 6(phy1-ap0) entered blocking state
[ 36.498619] br-lan: port 6(phy1-ap0) entered disabled state
[ 36.503006] ath11k c000000.wifi phy1-ap0: entered allmulticast mode
[ 36.508821] ath11k c000000.wifi phy1-ap0: entered promiscuous mode
[ 36.515047] br-lan: port 6(phy1-ap0) entered blocking state
[ 36.521065] br-lan: port 6(phy1-ap0) entered forwarding state
[ 36.955173] br-lan: port 6(phy1-ap0) entered disabled state
[ 36.981741] br-lan: port 6(phy1-ap0) entered blocking state
[ 36.981779] br-lan: port 6(phy1-ap0) entered forwarding state
BusyBox v1.36.1 (2025-10-27 14:10:17 UTC) built-in shell (ash)
.___ __ .__
| | _____ _____ ____________/ |______ | |
| |/ \ / \ / _ \_ __ \ __\__ \ | |
| | Y Y \ Y Y ( <_> ) | \/| | / __ \| |__
|___|__|_| /__|_| /\____/|__| |__| (____ /____/
\/ \/ BE FREE AND UNAFRAID \/
-----------------------------------------------------
ImmortalWrt 24.10.4, r33602-e717d133ed6d
-----------------------------------------------------
=== WARNING! =====================================
There is no root password defined on this device!
Use the "passwd" command to set up a new password
in order to prevent unauthorized SSH logins.
--------------------------------------------------
root@ImmortalWrt:~# tftp -g -r immortalwrt-24.10.4-qualcommax-ipq807x-linksys_mx成功救砖启动记录
root@ImmortalWrt:~# [ 195.502289] ath11k c000000.wifi phy2-ap0: left allmulticast mode
[ 195.502341] ath11k c000000.wifi phy2-ap0: left promiscuous mode
[ 195.507455] br-lan: port 5(phy2-ap0) entered disabled state
Watchdog handover: fd=3
- watchdog -
Watchdog did not previously reset the system
Wed Feb 11 17:20:29 CST 2026 upgrade: Sending TERM to remaining processes ...
Wed Feb 11 17:20:29 CST 2026 upgrade: Sending signal TERM to hostapd (3078)
Wed Feb 11 17:20:29 CST 2026 upgrade: Sending signal TERM to hostapd (3136)
Wed Feb 11 17:20:29 CST 2026 upgrade: Sending signal TERM to sleep (5332)
[ 195.906308] ath11k c000000.wifi phy1-ap0: left allmulticast mode
[ 195.906360] ath11k c000000.wifi phy1-ap0: left promiscuous mode
[ 195.911522] br-lan: port 6(phy1-ap0) entered disabled state
Wed Feb 11 17:20:33 CST 2026 upgrade: Sending KILL to remaining processes ...
[ 206.008939] stage2 (5380): drop_caches: 3
Wed Feb 11 17:20:39 CST 2026 upgrade: Switching to ramdisk...
Wed Feb 11 09:20:40 UTC 2026 upgrade: Performing system upgrade...
[ 207.382949] ubi0: attaching mtd24
[ 208.209420] ubi0: scanning is finished
[ 208.217639] ubi0: attached mtd24 (name "alt_rootfs", size 144 MiB)
[ 208.217684] ubi0: PEB size: 131072 bytes (128 KiB), LEB size: 126976 bytes
[ 208.222734] ubi0: min./max. I/O unit sizes: 2048/2048, sub-page size 2048
[ 208.229601] ubi0: VID header offset: 2048 (aligned 2048), data offset: 4096
[ 208.236446] ubi0: good PEBs: 1152, bad PEBs: 0, corrupted PEBs: 0
[ 208.243208] ubi0: user volume: 1, internal volumes: 1, max. volumes count: 128
[ 208.249475] ubi0: max/mean erase counter: 1/0, WL threshold: 4096, image sequence number: 1038325328
[ 208.256591] ubi0: available PEBs: 0, total reserved PEBs: 1152, PEBs reserved for bad PEB handling: 80
[ 208.265891] ubi0: background thread "ubi_bgt0d" started, PID 6172
UBI device number 0, total 1152 LEBs (146276352 bytes, 139.5 MiB), available 0 LEBs (0 bytes), LEB size 126976 bytes (124.0 KiB)
verifying sysupgrade tar file integrity
Unlocking alt_kernel ...
Writing from <stdin> to alt_kernel ...
[ 209.306922] block ubiblock0_0: created from ubi0:0(rootfs)
Volume ID 0, size 87 LEBs (11046912 bytes, 10.5 MiB), LEB size 126976 bytes (124.0 KiB), dynamic, name "rootfs", alignment 1
Set volume size to 124563456
Volume ID 1, size 981 LEBs (124563456 bytes, 118.7 MiB), LEB size 126976 bytes (124.0 KiB), dynamic, name "rootfs_data", alignment 1
Unlocking alt_kernel ...
Writing from <stdin> to alt_kernel ...
sysupgrade successful
umount: can't unmount /dev: Resource busy
umount: can't unmount /tmp: Resource busy
[ 214.018697] remoteproc remoteproc0: stopped remote processor cd00000.q6v5_wcss
[ 214.515336] reboot: Restarting system
Format: Log Type - Time(microsec) - Message - Optional Info
Log Type: B - Since Boot(Power On Reset), D - Delta, S - Statistic
S - QC_IMAGE_VERSION_STRING=BOOT.BF.3.3.1-00147
S - IMAGE_VARIANT_STRING=HAACANAZA
S - OEM_IMAGE_VERSION_STRING=CRM
S - Boot Config, 0x000002e5
B - 201 - PBL, Start
B - 2735 - bootable_media_detect_entry, Start
B - 3442 - bootable_media_detect_success, Start
B - 3447 - elf_loader_entry, Start
B - 6110 - auth_hash_seg_entry, Start
B - 6353 - auth_hash_seg_exit, Start
B - 68464 - elf_segs_hash_verify_entry, Start
B - 131160 - PBL, End
B - 217678 - SBL1, Start
B - 297009 - GCC [RstStat:0x10, RstDbg:0x600000] WDog Stat : 0x4
B - 306921 - pm_device_init, Start
B - 488823 - PM_SET_VAL:Skip
D - 179828 - pm_device_init, Delta
B - 491080 - pm_driver_init, Start
D - 5337 - pm_driver_init, Delta
B - 497607 - clock_init, Start
D - 2135 - clock_init, Delta
B - 501572 - boot_flash_init, Start
D - 12688 - boot_flash_init, Delta
B - 518042 - boot_config_data_table_init, Start
D - 3141 - boot_config_data_table_init, Delta - (575 Bytes)
B - 525484 - Boot Setting : 0x00000618
B - 529510 - CDT version:2,Platform ID:8,Major ID:1,Minor ID:0,Subtype:8
B - 536342 - sbl1_ddr_set_params, Start
B - 540155 - CPR configuration: 0x30c
B - 543601 - cpr_init, Start
B - 546377 - Rail:0 Mode: 5 Voltage: 800000
B - 551592 - CL CPR settled at 752000mV
B - 554398 - Rail:1 Mode: 5 Voltage: 880000
B - 558577 - Rail:1 Mode: 7 Voltage: 896000
D - 16500 - cpr_init, Delta
B - 565470 - Pre_DDR_clock_init, Start
B - 569496 - Pre_DDR_clock_init, End
B - 572881 - DDR Type : PCDDR3
B - 578524 - do ddr sanity test, Start
D - 1067 - do ddr sanity test, Delta
B - 583373 - DDR: Start of HAL DDR Boot Training
B - 588040 - DDR: End of HAL DDR Boot Training
B - 593804 - DDR: Checksum to be stored on flash is -478672533
B - 604113 - Image Load, Start
D - 225334 - QSEE Image Loaded, Delta - (1373936 Bytes)
B - 829539 - Image Load, Start
D - 61 - SEC Image Loaded, Delta - (0 Bytes)
B - 837225 - Image Load, Start
D - 10736 - DEVCFG Image Loaded, Delta - (26004 Bytes)
B - 848052 - Image Load, Start
D - 25285 - RPM Image Loaded, Delta - (105964 Bytes)
B - 873428 - Image Load, Start
D - 102358 - APPSBL Image Loaded, Delta - (627152 Bytes)
B - 975939 - QSEE Execution, Start
D - 61 - QSEE Execution, Delta
B - 981734 - USB D+ check, Start
D - 0 - USB D+ check, Delta
B - 988139 - SBL1, End
D - 772748 - SBL1, Delta
S - Flash Throughput, 6701 KB/s (2134303 Bytes, 318471 us)
S - DDR Frequency, 466 MHz
S - Core 0 Frequency, 1651 MHz
U-Boot 2016.01 (Mar 13 2020 - 17:34:10 +0800)
version: 0.3.14
DRAM: smem ram ptable found: ver: 1 len: 4
1 GiB
board_devinfo_offset=1060000, board_devinfo_size=20000
board_senv_offset=1040000, board_senv_size=20000
board_kernel_offset=0x1080000, board_fw_size=0x9600000, board_altkernel_offset=0xa680000\nNAND: ONFI device found
ID = 1590acad
Vendor = ad
Device = ac
qpic_nand: changing oobsize to 64 from 128 bytes
SF: Unsupported flash IDs: manuf ff, jedec ffff, ext_jedec ffff
ipq_spi: SPI Flash not found (bus/cs/speed/mode) = (0/0/48000000/0)
512 MiB
MMC: <NULL>: 0
devinfo_import--devinfo_mem_pool.crc=ff0d0154
fun=cmd_init DEVINFO_ITEMS=511
devinfo: data is valid!
read senv success
#### auto_recovery enabled:1, boot_part:2, boot_part_ready:3, boot_count=0
####[boot_count_write] erase:0, auto_recovery->block_offset:0x1040000 offset=0x1042000
Updating boot_count ...
####[boot_count_write] offset:0x1042000 , length:2048
done
PCI Link Intialized
In: serial@78B3000
Out: serial@78B3000
Err: serial@78B3000
machid: 8010008
Card did not respond to voltage select!
eth0 MAC Address from ART is not valid
eth1 MAC Address from ART is not valid
eth2 MAC Address from ART is not valid
eth3 MAC Address from ART is not valid
eth4 MAC Address from ART is not valid
eth5 MAC Address from ART is not valid
auto_recovery_check changes bootcmd: boot from partition 2
Bus 0: i2c@78b6000
Setting bus to 0
Valid chip addresses: 62 68
Hit 'Space' or 'Enter' key to stop autoboot: 0
Normal boot
NAND read: device 0 offset 0x13e80000, size 0x80000
524288 bytes read: OK
Erasing NAND...
Erasing at 0x1020000 -- 100% complete.
Writing to NAND... OK
PHY::Scratchpad Read/Write test fail
Disable 50MHz clock...
Erasing NAND...
Erasing at 0x1020000 -- 100% complete.
Writing to NAND... OK
NAND read: device 0 offset 0xa680000, size 0x600000
6291456 bytes read: OK
## Loading kernel from FIT Image at 44000000 ...
Using 'config@1' configuration
Trying 'kernel-1' kernel subimage
Description: ARM64 OpenWrt Linux-6.6.110
Type: Kernel Image
Compression: gzip compressed
Data Start: 0x440000e8
Data Size: 5500806 Bytes = 5.2 MiB
Architecture: AArch64
OS: Linux
Load Address: 0x41000000
Entry Point: 0x41000000
Hash algo: crc32
Hash value: a8f3c0e0
Hash algo: sha1
Hash value: 57d66c7b850a1166594936e9414caee12da75b35
Verifying Hash Integrity ... crc32+ sha1+ OK
## Loading fdt from FIT Image at 44000000 ...
Using 'config@1' configuration
Trying 'fdt-1' fdt subimage
Description: ARM64 OpenWrt linksys_mx5300 device tree blob
Type: Flat Device Tree
Compression: uncompressed
Data Start: 0x4453f1b0
Data Size: 47288 Bytes = 46.2 KiB
Architecture: AArch64
Hash algo: crc32
Hash value: 42a28833
Hash algo: sha1
Hash value: 6078e5cb1acf1b364db1b412897973c6bb954868
Verifying Hash Integrity ... crc32+ sha1+ OK
Booting using the fdt blob at 0x4453f1b0
Uncompressing Kernel Image ... OK
Loading Device Tree to 4a3f1000, end 4a3ff8b7 ... OK
Using machid 0x8010008 from environment
Starting kernel ...
Jumping to AARCH64 kernel via monitor
[ 0.000000] Booting Linux on physical CPU 0x0000000000 [0x410fd034]
[ 0.000000] Linux version 6.6.110 (buildbot@buildbot.infra.immortalwrt.org) (aarch64-openwrt-linux-musl-gcc (OpenWrt GCC 13.3.0 r33602-e717d133ed6d) 13.3.0, GNU ld (GNU Binutils) 2.42) #0 SMP Mon Oct 27 14:10:17 2025
[ 0.000000] Machine model: Linksys MX5300
[ 0.000000] OF: reserved mem: 0x0000000040000000..0x0000000040ffffff (16384 KiB) nomap non-reusable nss@40000000
[ 0.000000] OF: reserved mem: 0x000000004a400000..0x000000004a5fffff (2048 KiB) nomap non-reusable tzapp@4a400000
[ 0.000000] OF: reserved mem: 0x000000004a600000..0x000000004a9fffff (4096 KiB) nomap non-reusable bootloader@4a600000
[ 0.000000] OF: reserved mem: 0x000000004aa00000..0x000000004aafffff (1024 KiB) nomap non-reusable sbl@4aa00000
[ 0.000000] OF: reserved mem: 0x000000004ab00000..0x000000004abfffff (1024 KiB) nomap non-reusable smem@4ab00000
[ 0.000000] OF: reserved mem: 0x000000004ac00000..0x000000004affffff (4096 KiB) nomap non-reusable memory@4ac00000
[ 0.000000] OF: reserved mem: 0x000000004b000000..0x0000000050efffff (97280 KiB) nomap non-reusable wcnss@4b000000
[ 0.000000] OF: reserved mem: 0x0000000050f00000..0x0000000050ffffff (1024 KiB) nomap non-reusable q6_etr_dump@50f00000
[ 0.000000] OF: reserved mem: 0x0000000051000000..0x00000000510fffff (1024 KiB) nomap non-reusable m3_dump@51000000
[ 0.000000] Zone ranges:
[ 0.000000] DMA [mem 0x0000000040000000-0x000000007fffffff]
[ 0.000000] DMA32 empty
[ 0.000000] Normal empty
[ 0.000000] Movable zone start for each node
[ 0.000000] Early memory node ranges
[ 0.000000] node 0: [mem 0x0000000040000000-0x0000000040ffffff]
[ 0.000000] node 0: [mem 0x0000000041000000-0x000000004a3fffff]
[ 0.000000] node 0: [mem 0x000000004a400000-0x00000000510fffff]
[ 0.000000] node 0: [mem 0x0000000051100000-0x000000007fffffff]
[ 0.000000] Initmem setup node 0 [mem 0x0000000040000000-0x000000007fffffff]
[ 0.000000] psci: probing for conduit method from DT.
[ 0.000000] psci: PSCIv1.0 detected in firmware.
[ 0.000000] psci: Using standard PSCI v0.2 function IDs
[ 0.000000] psci: MIGRATE_INFO_TYPE not supported.
[ 0.000000] psci: SMC Calling Convention v1.0
[ 0.000000] psci: OSI mode supported.
[ 0.000000] psci: [Firmware Bug]: failed to set PC mode: -1
[ 0.000000] percpu: Embedded 18 pages/cpu s36136 r8192 d29400 u73728
[ 0.000000] Detected VIPT I-cache on CPU0
[ 0.000000] alternatives: applying boot alternatives
[ 0.000000] Kernel command line: console=ttyMSM0,115200n8 ubi.mtd=alt_rootfs root=ubi0:ubifs rootfstype=ubifs rootwait swiotlb=1 root=/dev/ubiblock0_0 rootfstype=squashfs ro
[ 0.000000] Dentry cache hash table entries: 131072 (order: 8, 1048576 bytes, linear)
[ 0.000000] Inode-cache hash table entries: 65536 (order: 7, 524288 bytes, linear)
[ 0.000000] Built 1 zonelists, mobility grouping on. Total pages: 258048
[ 0.000000] mem auto-init: stack:off, heap alloc:off, heap free:off
[ 0.000000] software IO TLB: area num 4.
[ 0.000000] software IO TLB: SWIOTLB bounce buffer size roundup to 1MB
[ 0.000000] software IO TLB: mapped [mem 0x000000007eb00000-0x000000007ec00000] (1MB)
[ 0.000000] Memory: 885000K/1048576K available (8640K kernel code, 922K rwdata, 2580K rodata, 1600K init, 293K bss, 163576K reserved, 0K cma-reserved)
[ 0.000000] SLUB: HWalign=64, Order=0-3, MinObjects=0, CPUs=4, Nodes=1
[ 0.000000] rcu: Hierarchical RCU implementation.
[ 0.000000] Tracing variant of Tasks RCU enabled.
[ 0.000000] rcu: RCU calculated value of scheduler-enlistment delay is 10 jiffies.
[ 0.000000] NR_IRQS: 64, nr_irqs: 64, preallocated irqs: 0
[ 0.000000] Root IRQ handler: gic_handle_irq
[ 0.000000] GICv2m: range[mem 0x0b00a000-0x0b00affc], SPI[448:479]
[ 0.000000] rcu: srcu_init: Setting srcu_struct sizes based on contention.
[ 0.000000] arch_timer: cp15 and mmio timer(s) running at 19.20MHz (virt/virt).
[ 0.000000] clocksource: arch_sys_counter: mask: 0xffffffffffffff max_cycles: 0x46d987e47, max_idle_ns: 440795202767 ns
[ 0.000000] sched_clock: 56 bits at 19MHz, resolution 52ns, wraps every 4398046511078ns
[ 0.000111] Calibrating delay loop (skipped), value calculated using timer frequency.. 38.40 BogoMIPS (lpj=192000)
[ 0.000125] pid_max: default: 32768 minimum: 301
[ 0.005159] Mount-cache hash table entries: 2048 (order: 2, 16384 bytes, linear)
[ 0.005173] Mountpoint-cache hash table entries: 2048 (order: 2, 16384 bytes, linear)
[ 0.009488] RCU Tasks Trace: Setting shift to 2 and lim to 1 rcu_task_cb_adjust=1 rcu_task_cpu_ids=4.
[ 0.009716] rcu: Hierarchical SRCU implementation.
[ 0.009720] rcu: Max phase no-delay instances is 1000.
[ 0.010653] smp: Bringing up secondary CPUs ...
[ 0.011321] Detected VIPT I-cache on CPU1
[ 0.011428] CPU1: Booted secondary processor 0x0000000001 [0x410fd034]
[ 0.012100] Detected VIPT I-cache on CPU2
[ 0.012169] CPU2: Booted secondary processor 0x0000000002 [0x410fd034]
[ 0.012829] Detected VIPT I-cache on CPU3
[ 0.012894] CPU3: Booted secondary processor 0x0000000003 [0x410fd034]
[ 0.012964] smp: Brought up 1 node, 4 CPUs
[ 0.012972] SMP: Total of 4 processors activated.
[ 0.012977] CPU features: detected: 32-bit EL0 Support
[ 0.012982] CPU features: detected: CRC32 instructions
[ 0.013042] CPU features: emulated: Privileged Access Never (PAN) using TTBR0_EL1 switching
[ 0.013048] CPU: All CPU(s) started at EL1
[ 0.013051] alternatives: applying system-wide alternatives
[ 0.024310] clocksource: jiffies: mask: 0xffffffff max_cycles: 0xffffffff, max_idle_ns: 19112604462750000 ns
[ 0.024337] futex hash table entries: 1024 (order: 4, 65536 bytes, linear)
[ 0.026117] pinctrl core: initialized pinctrl subsystem
[ 0.028223] NET: Registered PF_NETLINK/PF_ROUTE protocol family
[ 0.028861] DMA: preallocated 128 KiB GFP_KERNEL pool for atomic allocations
[ 0.028899] DMA: preallocated 128 KiB GFP_KERNEL|GFP_DMA pool for atomic allocations
[ 0.028933] DMA: preallocated 128 KiB GFP_KERNEL|GFP_DMA32 pool for atomic allocations
[ 0.029344] thermal_sys: Registered thermal governor 'step_wise'
[ 0.029407] cpuidle: using governor menu
[ 0.029655] ASID allocator initialised with 65536 entries
[ 0.037006] /soc@0/phy@8e000/phy@8e200: Fixed dependency cycle(s) with /soc@0/gcc@1800000
[ 0.037081] /soc@0/gcc@1800000: Fixed dependency cycle(s) with /soc@0/phy@8e000/phy@8e200
[ 0.037748] /soc@0/phy@8e000: Fixed dependency cycle(s) with /soc@0/gcc@1800000
[ 0.037764] /soc@0/phy@8e000/phy@8e200: Fixed dependency cycle(s) with /soc@0/gcc@1800000
[ 0.039925] /soc@0/phy@8e000/phy@8e200: Fixed dependency cycle(s) with /soc@0/gcc@1800000
[ 0.039995] /soc@0/phy@8e000: Fixed dependency cycle(s) with /soc@0/gcc@1800000
[ 0.040137] /soc@0/gcc@1800000: Fixed dependency cycle(s) with /soc@0/phy@8e000/phy@8e200
[ 0.086716] qcom,cpr4-apss-regulator b018000.cpr4-ctrl: CPR valid fuse count: 4
[ 0.088814] Modules: 29216 pages in range for non-PLT usage
[ 0.088821] Modules: 520736 pages in range for PLT usage
[ 0.092504] SCSI subsystem initialized
[ 0.092735] usbcore: registered new interface driver usbfs
[ 0.092777] usbcore: registered new interface driver hub
[ 0.092827] usbcore: registered new device driver usb
[ 0.093280] qcom_scm: convention: smc arm 64
[ 0.095075] clocksource: Switched to clocksource arch_sys_counter
[ 0.099043] NET: Registered PF_INET protocol family
[ 0.099209] IP idents hash table entries: 16384 (order: 5, 131072 bytes, linear)
[ 0.102119] tcp_listen_portaddr_hash hash table entries: 512 (order: 1, 8192 bytes, linear)
[ 0.102144] Table-perturb hash table entries: 65536 (order: 6, 262144 bytes, linear)
[ 0.102159] TCP established hash table entries: 8192 (order: 4, 65536 bytes, linear)
[ 0.102246] TCP bind hash table entries: 8192 (order: 6, 262144 bytes, linear)
[ 0.102516] TCP: Hash tables configured (established 8192 bind 8192)
[ 0.103031] MPTCP token hash table entries: 1024 (order: 2, 24576 bytes, linear)
[ 0.103218] UDP hash table entries: 512 (order: 2, 16384 bytes, linear)
[ 0.103256] UDP-Lite hash table entries: 512 (order: 2, 16384 bytes, linear)
[ 0.103572] NET: Registered PF_UNIX/PF_LOCAL protocol family
[ 0.103609] PCI: CLS 0 bytes, default 64
[ 0.105498] workingset: timestamp_bits=46 max_order=18 bucket_order=0
[ 0.106253] squashfs: version 4.0 (2009/01/31) Phillip Lougher
[ 0.106260] jffs2: version 2.2 (NAND) (SUMMARY) (LZMA) (RTIME) (CMODE_PRIORITY) (c) 2001-2006 Red Hat, Inc.
[ 0.110145] Block layer SCSI generic (bsg) driver version 0.4 loaded (major 248)
[ 0.114152] qcom-qmp-usb-phy 78000.phy: supply vdda-phy not found, using dummy regulator
[ 0.114306] qcom-qmp-usb-phy 78000.phy: supply vdda-pll not found, using dummy regulator
[ 0.116157] qcom-qusb2-phy 79000.phy: supply vdd not found, using dummy regulator
[ 0.116344] qcom-qusb2-phy 79000.phy: supply vdda-pll not found, using dummy regulator
[ 0.116386] qcom-qusb2-phy 79000.phy: supply vdda-phy-dpdm not found, using dummy regulator
[ 0.116567] qcom-qusb2-phy 79000.phy: Registered Qcom-QUSB2 phy
[ 0.119454] qcom-pcie 10000000.pci: host bridge /soc@0/pci@10000000 ranges:
[ 0.119530] qcom-pcie 10000000.pci: IO 0x0010200000..0x001020ffff -> 0x0000000000
[ 0.119556] qcom-pcie 10000000.pci: MEM 0x0010220000..0x001fffffff -> 0x0010220000
[ 0.126605] Serial: 8250/16550 driver, 16 ports, IRQ sharing enabled
[ 0.179923] qcom-pcie 10000000.pci: Read DBI address failed
[ 0.179972] msm_serial 78b3000.serial: msm_serial: detected port #0
[ 0.180014] msm_serial 78b3000.serial: uartclk = 3686400
[ 0.180382] 78b3000.serial: ttyMSM0 at MMIO 0x78b3000 (irq = 20, base_baud = 230400) is a MSM
[ 0.180417] msm_serial: console setup on port #0
[ 0.180463] printk: console [ttyMSM0] enabled
[ 0.306700] qcom-pcie 10000000.pci: iATU: unroll F, 32 ob, 8 ib, align 4K, limit 4G
[ 0.311092] msm_serial: driver initialized
[ 0.313667] qcom-pcie 10000000.pci: Invalid eDMA IRQs found
[ 1.079783] loop: module loaded
[ 1.081429] nand: device found, Manufacturer ID: 0xad, Chip ID: 0xac
[ 1.083194] nand: Hynix H27S4G8F2EDA-BC
[ 1.090024] nand: 512 MiB, SLC, erase size: 128 KiB, page size: 2048, OOB size: 128
[ 1.093827] 29 fixed-partitions partitions found on MTD device qcom_nand.0
[ 1.101026] Creating 29 MTD partitions on "qcom_nand.0":
[ 1.107945] 0x000000000000-0x000000100000 : "0:sbl1"
[ 1.114926] 0x000000100000-0x000000200000 : "0:mibib"
[ 1.119789] 0x000000200000-0x000000280000 : "0:bootconfig"
[ 1.124265] 0x000000280000-0x000000300000 : "0:bootconfig1"
[ 1.129753] 0x000000300000-0x000000600000 : "0:qsee"
[ 1.137482] 0x000000600000-0x000000900000 : "0:qsee_1"
[ 1.142617] 0x000000900000-0x000000980000 : "0:devcfg"
[ 1.145319] 0x000000980000-0x000000a00000 : "0:devcfg_1"
[ 1.150399] 0x000000a00000-0x000000a80000 : "0:apdp"
[ 1.155859] 0x000000a80000-0x000000b00000 : "0:apdp_1"
[ 1.160836] 0x000000b00000-0x000000b80000 : "0:rpm"
[ 1.165097] qcom-pcie 10000000.pci: PCIe Gen.2 x1 link up
[ 1.165925] 0x000000b80000-0x000000c00000 : "0:rpm_1"
[ 1.169991] qcom-pcie 10000000.pci: PCI host bridge to bus 0001:00
[ 1.176189] 0x000000c00000-0x000000c80000 : "0:cdt"
[ 1.180160] pci_bus 0001:00: root bus resource [bus 00-ff]
[ 1.187266] 0x000000c80000-0x000000d00000 : "0:cdt_1"
[ 1.191005] pci_bus 0001:00: root bus resource [io 0x0000-0xffff]
[ 1.197613] 0x000000d00000-0x000000d80000 : "0:appsblenv"
[ 1.201682] pci_bus 0001:00: root bus resource [mem 0x10220000-0x1fffffff]
[ 1.208777] 0x000000d80000-0x000000e80000 : "0:appsbl"
[ 1.213280] pci 0001:00:00.0: [17cb:0302] type 01 class 0x060400
[ 1.221512] 0x000000e80000-0x000000f80000 : "0:appsbl_1"
[ 1.225140] pci 0001:00:00.0: reg 0x10: [mem 0x00000000-0x00000fff]
[ 1.232755] 0x000000f80000-0x000001000000 : "0:art"
[ 1.236649] pci 0001:00:00.0: PME# supported from D0 D3hot D3cold
[ 1.243947] 0x000001000000-0x000001040000 : "u_env"
[ 1.251198] pci 0001:01:00.0: [168c:0046] type 00 class 0x028000
[ 1.254531] 0x000001040000-0x000001060000 : "s_env"
[ 1.258542] pci 0001:01:00.0: reg 0x10: [mem 0x00000000-0x001fffff 64bit]
[ 1.265293] 0x000001060000-0x000001080000 : "devinfo"
[ 1.270084] pci 0001:01:00.0: supports D1
[ 1.276820] 0x000001080000-0x00000a680000 : "kernel"
[ 1.281192] pci 0001:01:00.0: PME# supported from D0 D1 D3hot D3cold
[ 1.325248] pci 0001:00:00.0: BAR 8: assigned [mem 0x10400000-0x105fffff]
[ 1.325290] pci 0001:00:00.0: BAR 0: assigned [mem 0x10220000-0x10220fff]
[ 1.331027] pci 0001:01:00.0: BAR 0: assigned [mem 0x10400000-0x105fffff 64bit]
[ 1.337976] pci 0001:00:00.0: PCI bridge to [bus 01-ff]
[ 1.344907] pci 0001:00:00.0: bridge window [mem 0x10400000-0x105fffff]
[ 1.352986] pcieport 0001:00:00.0: PME: Signaling with IRQ 22
[ 1.357443] pcieport 0001:00:00.0: AER: enabled with IRQ 22
[ 1.425763] 0x000001680000-0x00000a680000 : "rootfs"
[ 1.560018] mtd: setting mtd22 (rootfs) as root device
[ 1.560379] mtdsplit: no squashfs found in "rootfs"
[ 1.564079] 0x00000a680000-0x000013c80000 : "alt_kernel"
[ 1.709750] 0x00000ac80000-0x000013c80000 : "alt_rootfs"
[ 1.844804] 0x000013c80000-0x000013e80000 : "sysdiag"
[ 1.847210] 0x000013e80000-0x000013f00000 : "0:ethphyfw"
[ 1.849745] 0x000013f00000-0x00001f700000 : "syscfg"
[ 2.026970] 0x00001f700000-0x000020000000 : "0:wififw"
[ 2.046794] spmi spmi-0: PMIC arbiter version v2 (0x20010000)
[ 2.066707] i2c_dev: i2c /dev entries driver
[ 2.074304] sdhci: Secure Digital Host Controller Interface driver
[ 2.074352] sdhci: Copyright(c) Pierre Ossman
[ 2.079436] sdhci-pltfm: SDHCI platform and OF driver helper
[ 2.085762] remoteproc remoteproc0: releasing cd00000.q6v5_wcss
[ 2.092225] NET: Registered PF_INET6 protocol family
[ 2.096663] Segment Routing with IPv6
[ 2.100420] In-situ OAM (IOAM) with IPv6
[ 2.104027] NET: Registered PF_PACKET protocol family
[ 2.108288] bridge: filtering via arp/ip/ip6tables is no longer available by default. Update your scripts to load br_netfilter if you need this.
[ 2.113117] 8021q: 802.1Q VLAN Support v1.8
[ 2.155288] qcom,cpr4-apss-regulator b018000.cpr4-ctrl: CPR valid fuse count: 4
[ 2.155710] cpr4_ipq807x_apss_read_fuse_data: apc_corner: speed bin = 0
[ 2.161420] cpr4_ipq807x_apss_read_fuse_data: apc_corner: CPR fusing revision = 1
[ 2.168107] cpr4_ipq807x_apss_read_fuse_data: apc_corner: CPR misc fuse value = 0
[ 2.175710] cpr4_ipq807x_apss_read_fuse_data: apc_corner: Voltage boost fuse config = 0 boost = disable
[ 2.183190] cpr3_mem_acc_init: apc: not using memory accelerator regulator
[ 2.192373] cpr4_ipq807x_apss_calculate_open_loop_voltages: apc_corner: fused SVS: open-loop= 704000 uV
[ 2.199294] cpr4_ipq807x_apss_calculate_open_loop_voltages: apc_corner: fused NOM: open-loop= 824000 uV
[ 2.209283] cpr4_ipq807x_apss_calculate_open_loop_voltages: apc_corner: fused TURBO: open-loop= 888000 uV
[ 2.219088] cpr4_ipq807x_apss_calculate_open_loop_voltages: apc_corner: fused STURBO: open-loop= 976000 uV
[ 2.228943] cpr4_ipq807x_apss_calculate_target_quotients: apc_corner: fused SVS: quot[ 7]= 720, quot_offset[ 7]= 0
[ 2.238707] cpr4_ipq807x_apss_calculate_target_quotients: apc_corner: fused NOM: quot[ 7]= 946, quot_offset[ 7]= 225
[ 2.249555] cpr4_ipq807x_apss_calculate_target_quotients: apc_corner: fused TURBO: quot[ 7]=1053, quot_offset[ 7]= 105
[ 2.260495] cpr4_ipq807x_apss_calculate_target_quotients: apc_corner: fused STURBO: quot[ 7]=1209, quot_offset[ 7]= 155
[ 2.271658] cpr3_regulator_init_ctrl: apc: Default CPR mode = closed-loop
[ 2.274821] cpufreq: cpufreq_online: CPU0: Running at unlisted initial frequency: 800000 KHz, changing to: 1017600 KHz
[ 2.290985] remoteproc remoteproc0: cd00000.q6v5_wcss is available
[ 2.300073] ubi0: attaching mtd24
[ 2.575077] random: crng init done
[ 3.133069] ubi0: scanning is finished
[ 3.141055] ubi0: attached mtd24 (name "alt_rootfs", size 144 MiB)
[ 3.141098] ubi0: PEB size: 131072 bytes (128 KiB), LEB size: 126976 bytes
[ 3.146175] ubi0: min./max. I/O unit sizes: 2048/2048, sub-page size 2048
[ 3.152994] ubi0: VID header offset: 2048 (aligned 2048), data offset: 4096
[ 3.159862] ubi0: good PEBs: 1152, bad PEBs: 0, corrupted PEBs: 0
[ 3.166626] ubi0: user volume: 2, internal volumes: 1, max. volumes count: 128
[ 3.172873] ubi0: max/mean erase counter: 2/1, WL threshold: 4096, image sequence number: 1038325328
[ 3.179999] ubi0: available PEBs: 0, total reserved PEBs: 1152, PEBs reserved for bad PEB handling: 80
[ 3.189294] ubi0: background thread "ubi_bgt0d" started, PID 723
[ 3.198892] block ubiblock0_0: created from ubi0:0(rootfs)
[ 3.204663] clk: Disabling unused clocks
[ 3.210343] ------------[ cut here ]------------
[ 3.213928] gcc_usb1_master_clk status stuck at 'on'
[ 3.213954] WARNING: CPU: 3 PID: 1 at drivers/clk/qcom/clk-branch.c:86 clk_branch_wait+0x114/0x124
[ 3.223485] Modules linked in:
[ 3.232243] CPU: 3 PID: 1 Comm: swapper/0 Not tainted 6.6.110 #0
[ 3.235285] Hardware name: Linksys MX5300 (DT)
[ 3.241446] pstate: 604000c5 (nZCv daIF +PAN -UAO -TCO -DIT -SSBS BTYPE=--)
[ 3.245703] pc : clk_branch_wait+0x114/0x124
[ 3.252555] lr : clk_branch_wait+0x114/0x124
[ 3.257069] sp : ffffffc080dfbc70
[ 3.261320] x29: ffffffc080dfbc70 x28: ffffffc080b100b0 x27: ffffffc080ab8630
[ 3.264540] x26: ffffffc080b02080 x25: 000000000000008d x24: ffffffc080b66078
[ 3.271659] x23: ffffffc080a71a28 x22: 0000000000000000 x21: ffffffc08044bda0
[ 3.278776] x20: 0000000000000000 x19: ffffffc080d49630 x18: 00000000000000ed
[ 3.285895] x17: ffffffc080d52190 x16: ffffffc080d52120 x15: ffffffc080cbbeb8
[ 3.293013] x14: 00000000000002c7 x13: 00000000000000ed x12: 00000000ffffffea
[ 3.300131] x11: 00000000ffffefff x10: ffffffc080d13eb8 x9 : ffffffc080cbbe60
[ 3.307248] x8 : 0000000000017fe8 x7 : c0000000ffffefff x6 : 0000000000057fa8
[ 3.314367] x5 : 0000000000000fff x4 : 0000000000000000 x3 : ffffffc080dfba70
[ 3.321485] x2 : ffffffc080cbbdf8 x1 : ffffffc080cbbdf8 x0 : 0000000000000028
[ 3.328604] Call trace:
[ 3.335712] clk_branch_wait+0x114/0x124
[ 3.337971] clk_branch2_disable+0x2c/0x3c
[ 3.342137] clk_disable_unused_subtree+0x98/0xfc
[ 3.346046] clk_disable_unused_subtree+0x2c/0xfc
[ 3.350820] clk_disable_unused_subtree+0x2c/0xfc
[ 3.355508] clk_disable_unused_subtree+0x2c/0xfc
[ 3.360195] clk_disable_unused_subtree+0x2c/0xfc
[ 3.364882] clk_disable_unused+0x64/0x148
[ 3.369569] do_one_initcall+0x6c/0x1fc
[ 3.373562] kernel_init_freeable+0x204/0x2e4
[ 3.377295] kernel_init+0x28/0x1e0
[ 3.381808] ret_from_fork+0x10/0x20
[ 3.385107] ---[ end trace 0000000000000000 ]---
[ 3.389253] ------------[ cut here ]------------
[ 3.393529] gcc_usb0_master_clk status stuck at 'on'
[ 3.393545] WARNING: CPU: 3 PID: 1 at drivers/clk/qcom/clk-branch.c:86 clk_branch_wait+0x114/0x124
[ 3.403085] Modules linked in:
[ 3.411841] CPU: 3 PID: 1 Comm: swapper/0 Tainted: G W 6.6.110 #0
[ 3.414889] Hardware name: Linksys MX5300 (DT)
[ 3.422435] pstate: 604000c5 (nZCv daIF +PAN -UAO -TCO -DIT -SSBS BTYPE=--)
[ 3.426780] pc : clk_branch_wait+0x114/0x124
[ 3.433631] lr : clk_branch_wait+0x114/0x124
[ 3.438146] sp : ffffffc080dfbc70
[ 3.442398] x29: ffffffc080dfbc70 x28: ffffffc080b100b0 x27: ffffffc080ab8630
[ 3.445618] x26: ffffffc080b02080 x25: 000000000000008d x24: ffffffc080b66078
[ 3.452735] x23: ffffffc080a71ae0 x22: 0000000000000000 x21: ffffffc08044bda0
[ 3.459852] x20: 0000000000000000 x19: ffffffc080d499b0 x18: 000000000000010f
[ 3.466971] x17: ffffffc080d52190 x16: ffffffc080d52120 x15: ffffffc080cbbeb8
[ 3.474090] x14: 000000000000032d x13: 000000000000010f x12: 00000000ffffffea
[ 3.481207] x11: 00000000ffffefff x10: ffffffc080d13eb8 x9 : ffffffc080cbbe60
[ 3.488326] x8 : 0000000000017fe8 x7 : c0000000ffffefff x6 : 0000000000057fa8
[ 3.495443] x5 : 0000000000000fff x4 : 0000000000000000 x3 : ffffffc080dfba70
[ 3.502562] x2 : ffffffc080cbbdf8 x1 : ffffffc080cbbdf8 x0 : 0000000000000028
[ 3.509680] Call trace:
[ 3.516788] clk_branch_wait+0x114/0x124
[ 3.519048] clk_branch2_disable+0x2c/0x3c
[ 3.523214] clk_disable_unused_subtree+0x98/0xfc
[ 3.527122] clk_disable_unused_subtree+0x2c/0xfc
[ 3.531896] clk_disable_unused_subtree+0x2c/0xfc
[ 3.536583] clk_disable_unused_subtree+0x2c/0xfc
[ 3.541271] clk_disable_unused_subtree+0x2c/0xfc
[ 3.545959] clk_disable_unused+0x64/0x148
[ 3.550645] do_one_initcall+0x6c/0x1fc
[ 3.554638] kernel_init_freeable+0x204/0x2e4
[ 3.558371] kernel_init+0x28/0x1e0
[ 3.562883] ret_from_fork+0x10/0x�[ 3.573381] VFS: Mounted root (squashfs filesystem) readonly on device 254:0.
[ 3.573901] Freeing unused kernel memory: 1600K
[ 3.579663] Run /sbin/init as init process
[ 3.744439] init: Console is alive
[ 3.744564] init: - watchdog -
[ 4.504204] kmodloader: loading kernel modules from /etc/modules-boot.d/*
[ 4.539193] gpio_button_hotplug: loading out-of-tree module taints kernel.
[ 4.572820] ssdk_dt_parse_interrupt[941]:INFO:intr-gpio does not exist
[ 4.991225] regi_init[2525]:INFO:Initializing HPPE Done!!
[ 4.991355] regi_init[2574]:INFO:qca-ssdk module init succeeded!
[ 4.998028] EDMA ver 1 hw init
[ 5.001910] EDMA HW Reset completed succesfully
[ 5.004581] Num rings - TxDesc:1 (23-23) TxCmpl:1 (7-7)
[ 5.008999] RxDesc:1 (15-15) RxFill:1 (7-7)
[ 5.014541] dp1: ppe offload disabled: 0 for macid 1
[ 5.018365] dp1: Switch attached to macid 1 status: 0
[ 5.195817] Qualcomm QCA8075 90000.mdio-1:00: attached PHY driver (mii_bus:phy_addr=90000.mdio-1:00, irq=POLL)
[ 5.196820] dp2: ppe offload disabled: 0 for macid 2
[ 5.204711] dp2: Switch attached to macid 2 status: 0
[ 5.285428] Qualcomm QCA8075 90000.mdio-1:01: attached PHY driver (mii_bus:phy_addr=90000.mdio-1:01, irq=POLL)
[ 5.286393] dp3: ppe offload disabled: 0 for macid 3
[ 5.294319] dp3: Switch attached to macid 3 status: 0
[ 5.375431] Qualcomm QCA8075 90000.mdio-1:02: attached PHY driver (mii_bus:phy_addr=90000.mdio-1:02, irq=POLL)
[ 5.376407] dp4: ppe offload disabled: 0 for macid 4
[ 5.384321] dp4: Switch attached to macid 4 status: 0
[ 5.465431] Qualcomm QCA8075 90000.mdio-1:03: attached PHY driver (mii_bus:phy_addr=90000.mdio-1:03, irq=POLL)
[ 5.466404] dp5: ppe offload disabled: 0 for macid 5
[ 5.474322] dp5: Switch attached to macid 5 status: 0
[ 5.555435] Qualcomm QCA8075 90000.mdio-1:04: attached PHY driver (mii_bus:phy_addr=90000.mdio-1:04, irq=POLL)
[ 5.556380] **********************************************************
[ 5.564327] * NSS Data Plane driver
[ 5.570850] **********************************************************
[ 5.588414] xhci-hcd xhci-hcd.1.auto: xHCI Host Controller
[ 5.588468] xhci-hcd xhci-hcd.1.auto: new USB bus registered, assigned bus number 1
[ 5.592938] xhci-hcd xhci-hcd.1.auto: hcc params 0x0220fe65 hci version 0x110 quirks 0x0000008002000010
[ 5.600422] xhci-hcd xhci-hcd.1.auto: irq 40, io mem 0x08a00000
[ 5.609842] xhci-hcd xhci-hcd.1.auto: xHCI Host Controller
[ 5.615639] xhci-hcd xhci-hcd.1.auto: new USB bus registered, assigned bus number 2
[ 5.621193] xhci-hcd xhci-hcd.1.auto: Host supports USB 3.0 SuperSpeed
[ 5.629359] hub 1-0:1.0: USB hub found
[ 5.635388] hub 1-0:1.0: 1 port detected
[ 5.639350] usb usb2: We don't know the algorithms for LPM for this host, disabling LPM.
[ 5.643446] hub 2-0:1.0: USB hub found
[ 5.651285] hub 2-0:1.0: 1 port detected
[ 5.659362] usbcore: registered new interface driver usb-storage
[ 5.660337] usbcore: registered new interface driver uas
[ 5.665166] kmodloader: done loading kernel modules from /etc/modules-boot.d/*
[ 5.675184] init: - preinit -
Cannot parse config file '/etc/fw_env.config': No such file or directory
Failed to find NVMEM device
Press the [f] key and hit [enter] to enter failsafe mode
Press the [1], [2], [3] or [4] key and hit [enter] to select the debug level
[ 10.526762] mount_root: loading kmods from internal overlay
[ 10.536815] kmodloader: loading kernel modules from //etc/modules-boot.d/*
[ 10.539763] kmodloader: done loading kernel modules from //etc/modules-boot.d/*
[ 10.578988] mtdblock: MTD device 'rootfs' is NAND, please consider using UBI block devices instead.
[ 10.644990] block: attempting to load /tmp/overlay/upper/etc/config/fstab
[ 10.645150] block: unable to load configuration (fstab: Entry not found)
[ 10.650805] block: attempting to load /tmp/overlay/etc/config/fstab
[ 10.657691] block: unable to load configuration (fstab: Entry not found)
[ 10.663560] block: attempting to load /etc/config/fstab
[ 10.671547] block: unable to load configuration (fstab: Entry not found)
[ 10.675463] block: no usable configuration
[ 10.693105] UBIFS (ubi0:1): default file-system created
[ 10.693713] UBIFS (ubi0:1): Mounting in unauthenticated mode
[ 10.697308] UBIFS (ubi0:1): background thread "ubifs_bgt0_1" started, PID 1005
[ 10.757464] UBIFS (ubi0:1): UBIFS: mounted UBI device 0, volume 1, name "rootfs_data"
[ 10.757503] UBIFS (ubi0:1): LEB size: 126976 bytes (124 KiB), min./max. I/O unit sizes: 2048 bytes/2048 bytes
[ 10.764283] UBIFS (ubi0:1): FS size: 123166720 bytes (117 MiB, 970 LEBs), max 981 LEBs, journal size 6221824 bytes (5 MiB, 49 LEBs)
[ 10.774199] UBIFS (ubi0:1): reserved for root: 4952683 bytes (4836 KiB)
[ 10.785820] UBIFS (ubi0:1): media format: w5/r0 (latest is w5/r0), UUID 68E307E5-CBF0-4F5D-831B-EC074B130359, small LPT model
[ 10.793248] block: attempting to load /tmp/ubifs_cfg/upper/etc/config/fstab
[ 10.804019] block: unable to load configuration (fstab: Entry not found)
[ 10.810688] block: attempting to load /tmp/ubifs_cfg/etc/config/fstab
[ 10.817649] block: unable to load configuration (fstab: Entry not found)
[ 10.823953] block: attempting to load /etc/config/fstab
[ 10.830857] block: unable to load configuration (fstab: Entry not found)
[ 10.835673] block: no usable configuration
[ 10.845474] UBIFS (ubi0:1): un-mount UBI device 0
[ 10.846493] UBIFS (ubi0:1): background thread "ubifs_bgt0_1" stops
[ 10.854777] UBIFS (ubi0:1): Mounting in unauthenticated mode
[ 10.857428] UBIFS (ubi0:1): background thread "ubifs_bgt0_1" started, PID 1008
[ 10.917317] UBIFS (ubi0:1): UBIFS: mounted UBI device 0, volume 1, name "rootfs_data"
[ 10.917360] UBIFS (ubi0:1): LEB size: 126976 bytes (124 KiB), min./max. I/O unit sizes: 2048 bytes/2048 bytes
[ 10.924140] UBIFS (ubi0:1): FS size: 123166720 bytes (117 MiB, 970 LEBs), max 981 LEBs, journal size 6221824 bytes (5 MiB, 49 LEBs)
[ 10.934058] UBIFS (ubi0:1): reserved for root: 4952683 bytes (4836 KiB)
[ 10.945669] UBIFS (ubi0:1): media format: w5/r0 (latest is w5/r0), UUID 68E307E5-CBF0-4F5D-831B-EC074B130359, small LPT model
[ 10.958213] mtdblock: MTD device 'rootfs' is NAND, please consider using UBI block devices instead.
[ 10.985675] block: attempting to load /tmp/overlay/upper/etc/config/fstab
[ 10.985805] block: unable to load configuration (fstab: Entry not found)
[ 10.991499] block: attempting to load /tmp/overlay/etc/config/fstab
[ 10.998391] block: unable to load configuration (fstab: Entry not found)
[ 11.004245] block: attempting to load /etc/config/fstab
[ 11.011421] block: unable to load configuration (fstab: Entry not found)
[ 11.016134] block: no usable configuration
[ 11.024125] block: attempting to load /tmp/ubifs_cfg/upper/etc/config/fstab
[ 11.027058] block: unable to load configuration (fstab: Entry not found)
[ 11.033851] block: attempting to load /tmp/ubifs_cfg/etc/config/fstab
[ 11.040809] block: unable to load configuration (fstab: Entry not found)
[ 11.047132] block: attempting to load /etc/config/fstab
[ 11.053907] block: unable to load configuration (fstab: Entry not found)
[ 11.058849] block: no usable configuration
[ 11.066956] mount_root: overlay filesystem has not been fully initialized yet
[ 11.069827] mount_root: switching to ubifs overlay
[ 11.082352] overlayfs: null uuid detected in lower fs '/', falling back to xino=off,index=off,nfs_export=off.
[ 11.084648] urandom-seed: Seed file not found (/etc/urandom.seed)
[ 11.114642] procd: - early -
[ 11.114726] procd: - watchdog -
[ 11.192168] mtdblock: MTD device 'rootfs' is NAND, please consider using UBI block devices instead.
[ 11.235941] mtdblock: MTD device 'rootfs' is NAND, please consider using UBI block devices instead.
[ 11.280653] mtdblock: MTD device 'rootfs' is NAND, please consider using UBI block devices instead.
[ 11.324197] mtdblock: MTD device 'rootfs' is NAND, please consider using UBI block devices instead.
[ 11.368521] mtdblock: MTD device 'rootfs' is NAND, please consider using UBI block devices instead.
[ 11.412215] mtdblock: MTD device 'rootfs' is NAND, please consider using UBI block devices instead.
[ 11.455502] mtdblock: MTD device 'rootfs' is NAND, please consider using UBI block devices instead.
[ 11.498232] mtdblock: MTD device 'rootfs' is NAND, please consider using UBI block devices instead.
[ 11.662533] procd: - watchdog -
[ 11.711462] procd: - ubus -
[ 11.865716] procd: - init -
Please press Enter to activate this console.
[ 12.149636] kmodloader: loading kernel modules from /etc/modules.d/*
[ 12.252885] urngd: v1.0.2 started.
[ 12.258185] NET: Registered PF_ALG protocol family
[ 12.269815] ntfs3: Enabled Linux POSIX ACLs support
[ 12.277016] Loading modules backported from Linux version v6.12.52-0-g2b2cbdcede38
[ 12.277058] Back UTC (1770801668)
[ 12.302926] usbcore: registered new interface driver ums-alauda
[ 12.309263] usbcore: registered new interface driver ums-cypress
[ 12.314963] usbcore: registered new interface driver ums-datafab
[ 12.321344] usbcore: registered new interface driver ums-freecom
[ 12.327687] usbcore: registered new interface driver ums-isd200
[ 12.334532] usbcore: registered new interface driver ums-jumpshot
[ 12.338761] usbcore: registered new interface driver ums-karma
[ 12.345305] usbcore: registered new interface driver ums-sddr09
[ 12.350846] usbcore: registered new interface driver ums-sddr55
[ 12.356601] usbcore: registered new interface driver ums-usbat
[ 12.447966] PPP generic driver version 2.4.2
[ 12.448801] PPP MPPE Compression module registered
[ 12.452054] NET: Registered PF_PPPOX protocol family
[ 12.465867] ath10k 6.10 driver, optimized for CT firmware, probing pci device: 0x46.
[ 12.466324] ath10k_pci 0001:01:00.0: enabling device (0000 -> 0002)
[ 12.473259] ath10k_pci 0001:01:00.0: pci irq msi oper_irq_mode 2 irq_mode 0 reset_mode 0
[ 13.536186] ath10k_pci 0001:01:00.0: qca9984/qca9994 hw1.0 target 0x01000000 chip_id 0x00000000 sub 168c:cafe
[ 13.536240] ath10k_pci 0001:01:00.0: kconfig debug 0 debugfs 1 tracing 0 dfs 1 testmode 0
[ 13.545448] ath10k_pci 0001:01:00.0: firmware ver 10.4b-ct-9984-fW-13-5ae337bb1 api 5 features mfp,peer-flow-ctrl,txstatus-noack,wmi-10.x-CT,ratemask-CT,regdump-CT,txrate-CT,flush-all-CT,pingpong-CT,ch-regs-CT,nop-CT,set-special-CT,tx-rc-CT,cust-stats-CT,txrate2-CT,beacon-cb-CT,wmi-block-ack-CT,wmi-bcn-rc-CT crc32 7ea63dc5
[ 15.864537] ath10k_pci 0001:01:00.0: board_file api 2 bmi_id 0:6 crc32 55b5e590
[ 19.375312] ath10k_pci 0001:01:00.0: 10.4 wmi init: vdevs: 16 peers: 48 tid: 96
[ 19.375363] ath10k_pci 0001:01:00.0: msdu-desc: 2500 skid: 32
[ 19.458281] ath10k_pci 0001:01:00.0: wmi print 'P 48/48 V 16 K 144 PH 176 T 186 msdu-desc: 2500 sw-crypt: 0 ct-sta: 0'
[ 19.459082] ath10k_pci 0001:01:00.0: wmi print 'free: 84920 iram: 13156 sram: 11224'
[ 19.747675] ath10k_pci 0001:01:00.0: htt-ver 2.2 wmi-op 6 htt-op 4 cal pre-cal-nvmem max-sta 32 raw 0 hwcrypto 1
[ 19.876129] ath11k c000000.wifi: ipq8074 hw2.0
[ 19.876165] ath11k c000000.wifi: FW memory mode: 0
[ 19.936156] remoteproc remoteproc0: powering up cd00000.q6v5_wcss
[ 19.936627] remoteproc remoteproc0: Booting fw image IPQ8074/q6_fw.mdt, size 668
[ 21.164687] remoteproc remoteproc0: remote processor cd00000.q6v5_wcss is now up
[ 21.208607] ath11k c000000.wifi: qmi ignore invalid mem req type 3
[ 21.216078] ath11k c000000.wifi: chip_id 0x0 chip_family 0x0 board_id 0xff soc_id 0xffffffff
[ 21.216114] ath11k c000000.wifi: fw_version 0x290b84a5 fw_build_timestamp 2024-09-23 11:32 fw_build_id WLAN.HK.2.9.0.1-02146-QCAHKSWPL_SILICONZ-1
[ 24.117071] remoteproc remoteproc0: stopped remote processor cd00000.q6v5_wcss
[ 24.117113] remoteproc remoteproc0: powering up cd00000.q6v5_wcss
[ 24.123271] remoteproc remoteproc0: Booting fw image IPQ8074/q6_fw.mdt, size 668
[ 24.473119] remoteproc remoteproc0: remote processor cd00000.q6v5_wcss is now up
[ 24.476297] kmodloader: done loading kernel modules from /etc/modules.d/*
[ 24.517222] ath11k c000000.wifi: qmi ignore invalid mem req type 3
[ 24.524651] ath11k c000000.wifi: chip_id 0x0 chip_family 0x0 board_id 0xff soc_id 0xffffffff
[ 24.524685] ath11k c000000.wifi: fw_version 0x290b84a5 fw_build_timestamp 2024-09-23 11:32 fw_build_id WLAN.HK.2.9.0.1-02146-QCAHKSWPL_SILICONZ-1
[ 24.822615] ath11k c000000.wifi: htt event 48 not handled
[ 27.193069] mtdblock_open: 30 callbacks suppressed
[ 27.193082] mtdblock: MTD device 'rootfs' is NAND, please consider using UBI block devices instead.
[ 32.121692] br-lan: port 1(lan1) entered blocking state
[ 32.121734] br-lan: port 1(lan1) entered disabled state
[ 32.125834] nss-dp 3a001000.dp1 lan1: entered allmulticast mode
[ 32.131176] nss-dp 3a001000.dp1 lan1: entered promiscuous mode
[ 32.142710] br-lan: port 2(lan2) entered blocking state
[ 32.142752] br-lan: port 2(lan2) entered disabled state
[ 32.147990] nss-dp 3a001200.dp2 lan2: entered allmulticast mode
[ 32.153305] nss-dp 3a001200.dp2 lan2: entered promiscuous mode
[ 32.162834] br-lan: port 3(lan3) entered blocking state
[ 32.164885] br-lan: port 3(lan3) entered disabled state
[ 32.170135] nss-dp 3a001400.dp3 lan3: entered allmulticast mode
[ 32.175475] nss-dp 3a001400.dp3 lan3: entered promiscuous mode
[ 32.185142] br-lan: port 4(lan4) entered blocking state
[ 32.187020] br-lan: port 4(lan4) entered disabled state
[ 32.192168] nss-dp 3a001600.dp4 lan4: entered allmulticast mode
[ 32.197695] nss-dp 3a001600.dp4 lan4: entered promiscuous mode
[ 33.765140] l11: disabling
[ 35.285433] nss-dp 3a001400.dp3 lan3: PHY Link up speed: 1000
[ 39.650892] ath10k_pci 0001:01:00.0: 10.4 wmi init: vdevs: 16 peers: 48 tid: 96
[ 39.650944] ath10k_pci 0001:01:00.0: msdu-desc: 2500 skid: 32
[ 39.733919] ath10k_pci 0001:01:00.0: wmi print 'P 48/48 V 16 K 144 PH 176 T 186 msdu-desc: 2500 sw-crypt: 0 ct-sta: 0'
[ 39.734723] ath10k_pci 0001:01:00.0: wmi print 'free: 84920 iram: 13156 sram: 11224'
[ 40.118422] ath10k_pci 0001:01:00.0: rts threshold -1
[ 40.118677] ath10k_pci 0001:01:00.0: Firmware lacks feature flag indicating a retry limit of > 2 is OK, requested limit: 4
[ 40.122826] br-lan: port 3(lan3) entered blocking state
[ 40.133404] br-lan: port 3(lan3) entered forwarding state
[ 40.139017] br-lan: port 5(phy0-ap0) entered blocking state
[ 40.144068] br-lan: port 5(phy0-ap0) entered disabled state
[ 40.149501] ath10k_pci 0001:01:00.0 phy0-ap0: entered allmulticast mode
[ 40.155159] ath10k_pci 0001:01:00.0 phy0-ap0: entered promiscuous mode
[ 40.163276] ath10k_pci 0001:01:00.0 phy0-ap0: left allmulticast mode
[ 40.168249] ath10k_pci 0001:01:00.0 phy0-ap0: left promiscuous mode
[ 40.174768] br-lan: port 5(phy0-ap0) entered disabled state
[ 40.265519] ath10k_pci 0001:01:00.0: NOTE: Firmware DBGLOG output disabled in debug_mask: 0x10000000
[ 40.265639] ath10k_pci 0001:01:00.0: peer-unmap-event: unknown peer id 0
[ 40.437978] br-lan: port 5(phy2-ap0) entered blocking state
[ 40.438025] br-lan: port 5(phy2-ap0) entered disabled state
[ 40.442407] ath11k c000000.wifi phy2-ap0: entered allmulticast mode
[ 40.448131] ath11k c000000.wifi phy2-ap0: entered promiscuous mode
[ 40.454245] br-lan: port 5(phy2-ap0) entered blocking state
[ 40.460432] br-lan: port 5(phy2-ap0) entered forwarding state
[ 40.660469] br-lan: port 6(phy1-ap0) entered blocking state
[ 40.660510] br-lan: port 6(phy1-ap0) entered disabled state
[ 40.664897] ath11k c000000.wifi phy1-ap0: entered allmulticast mode
[ 40.670895] ath11k c000000.wifi phy1-ap0: entered promiscuous mode
[ 40.676824] br-lan: port 6(phy1-ap0) entered blocking state
[ 40.682910] br-lan: port 6(phy1-ap0) entered forwarding state
[ 41.125167] br-lan: port 6(phy1-ap0) entered disabled state
[ 41.141754] br-lan: port 6(phy1-ap0) entered blocking state
[ 41.141799] br-lan: port 6(phy1-ap0) entered forwarding state
[ 194.405390] nss-dp 3a001400.dp3 lan3: PHY Link is down
[ 194.405646] br-lan: port 3(lan3) entered disabled state
启动记录，是不是刷成功了© 版权声明
文章版权归作者所有，未经允许请勿转载。
THE END
暂无评论内容
